Summary of Contents for xDEEP ZEOS 28
- Page 1 ZEOS 28 ZEOS 38 HYDROS 40 HYDROS 50 User manual English...
- Page 2 Ul.Ogrodników 3, 43-227 Góra Poland Phone: +48 12 44 66 998 e-mail: biuro@xdeep.pl Important! This manual includes two types of designation, which you should pay special attention to. They indicate warnings or other information which may be crucial for health and life of the user or other people. You should...
- Page 3 785 01 Šternberk Czech Republic ZEOS 38, ZEOS 28, HYDROS 50 and HYDOS 40 buoyancy compensators has been certified as compatible with 89/686/EWG directive, as far as it contains air compatible with EN 12021 norm. Regarding the lack of EN norms...
-
Page 4: Safety Rules
3 Safety rules Danger! xDEEP BCDs are designed to provide the user with safety and comfort. Improper use may result in an accident, therefore it is necessary to comply with ALL of the following rules. 1. Before every dive, carefully inspect all elements of the equipment, including the BC. For further information on the subject, read: “Pre-dive inspection”. - Page 5 4 BC Elements 1/2 Thanks to its modular design, a xDEEP BC can be adjusted to every type of diving, starting with simple recreational diving with the use of a single tank and finishing with deep technical diving which requires configuration with a double tank set and stages.
- Page 6 5 BC Elements 2/2 K-type Power Inflator A K-type inflator is a reliable device made of shock- proof technopolymer which resistant 2 2 2 2 environmental conditions. The inflator valve is made of metal, which makes the inflator more resistant to freezing and it can be operated much longer than inflators made entirely of plastic.
- Page 7 5 BC Adjustment When you order a complete BC system, you get all elements connected and ready for use. For improved comfort and safety of use you should, however, make some final adjustments of the harness straps. The adjustment description below applies to the most basic model of harness, consisting of steel or aluminium plate and one piece of webbing, which is popular among technical divers.
- Page 8 6 Connecting the LP hose To allow for proper operation of the inflator it must be connected to the LP port of the 1st stage of the regulator using the LP hose supplied with the BC. Danger! LP hose connection using the 1 stage of the regulator must be made to the low pressure (LP) port only.
- Page 9 Therefore the tank connection has to be inspected closely. Connecting the single SCUBA tank to ZEOS 38 and ZEOS 28 compensators In order to connect the tank with the BC in a reliable and safe manner you should connect the webbing as indicated in the pictures below: Fig.
- Page 10 8 Connecting the Scuba Tank 2/2 Connecting the double SCUBA tanks to HYDROS 50 and HYDROS 40 compensators In order to connect the double scuba tank in proper and safe way, read and understand the user manual delivered with the double set. To install the BC on double tank set: 1.
-
Page 11: Pre-Dive Inspection
9 Pre-dive Inspection Before every dive it is necessary to follow the inspection procedures for checking the correct operation of all BC elements. Even if on a given day you have already dived using your BC, before diving again make sure that all of its elements are working correctly. -
Page 12: Operation
10 Operation Buoyancy on the surface In order to ensure maximum buoyancy on the surface, before getting into the water (or directly after ascending) inflate the BC using inflator button. Stop inflating the BC when the automatic dump valve activates. Danger! Before jumping into deep water from a boat or a bank inflate the BC using the inflator button. -
Page 13: Post-Dive Maintenance
11 Post-dive maintenance Disconnecting After diving, take out the weight from the weight pockets (if applicable), disconnect the LP hose from the inflator, and then disconnect the tank. Draining Inflate the BC orally using the purge button of the inflator. Next turn the BC to keep the automatic dump valve at the lowest point of the BC. -
Page 14: Repair And Maintenance
12 Repair and maintenance xDEEP BCDs does not contain any elements which can be repaired by the user, and so all repairs (including lubrication or replacement of worn-out elements) should be performed only by trained technicians holding certificates issued by the producer (authorized service center). -
Page 15: Specification
“K” type Supply pressure Between 6 bar and 17.23 bar (250 PSI) Permissible tank parameters ZEOS 28 and ZEOS 38: single tank only Tank type HYDROS 40 and HYDROS 50: double cylinder set ZEOS 28: 15 L ZEOS 38: 18 L... - Page 16 WRECKANDREEF Piotr Czernik Ul.Ogrodników 3 43-227 Góra Polska Tel: +48 12 44 66 998 e-mail: biuro@xdeep.pl...
