Technical specifications
8.5 Hardware description
Line Out interface, headset, X60 top
Pin no.
5
6
7
8
9
USB 3.0 port
Pin no.
1
2
3
4
5
6
7
8
9
144
Short name Meaning
M Logic ground
Left Left channel
7M Analog ground
Sense Switch contact for device identification
Right Right channel
Short name
VBUS
D-
D+
GND
RX-
RX+
GND
TX-
TX+
Meaning
+ 5 V (fused)
Data channel USB2
Data channel USB2
Ground
Data channel USB3
Data channel USB3
Ground
Data channel USB3
Data channel USB3
Operating Instructions, 01/2014, A5E32997454-AA
Input / output
Output
Output
Output
Input
Output
Input / output
Output
Input / output
Input / output
–
Input
Input
–
Output
Output
SIMATIC IPC847D
