Overview
1.1 Product description
Basic variant
Motherboard
Bus board
Processor
RAM expansion
Drives
Hard disks
Optical drive
Operating system
memory expansions ≥4 GB can only be used in combination with 64-bit operating systems.
1
Optional accessories
PROFIBUS/MPI
PROFINET
Drives
DVD burner
Hard disks 3.5" (SATA)
Solid State Drive 2.5" (SATA)
Graphics cards
14
Motherboard without fieldbus, Intel® DH82C226 Express Chipset
PCI, PCIe x4, PCIe x16, 2 variants
Intel® Xeon™ E3-1268L v3 2.3 (3.3) GHz, 4 cores, GT2, 8 MB SLC,
•
HT
Intel® Core™ i5-4570TE 2.7 (3.3) GHz, 2 cores, GT2, 4 MB SLC, AMT
•
Intel® Core™ i3-4330TE 2.4 GHz, 2 cores, GT2, 3 MB SLC, AMT
•
up to 32 GB SDRAM DDR3 1600MT/s
4 DIMM socket without or with ECC
3.5" SAS 6 Gbps, 500 / 1000 GB
Slimline SATA
without
12 Mbps (isolated potential, compatible to CP 5622)
10/100 Mbps (CP 1616 onboard, three RJ45)
Read:
DVD ROM: Single Layer8x, Dual Layer 6x
DVD-R/+R: Single Layer8x, Dual Layer 6x
DVD-RW/+RW 8x, DVD-RAM 5x
CD-ROM/CD-R Read 24x, CD-RW 24x
Write:
DVD+R 8x, DVD+RW 8x, DVD-R 8x, DVD-RW 6x
DVD+R (DL) 6x, DVD-R DL 2x
CD-R 24x, CD-RW 24x
Installation in internal drive cage (fixed or vibration-damping)
500 / 1000 GB (SATA)
•
2 × 1000 GB (SATA)
•
RAID1: 1000 GB (2 × 1000 GB, SATA)
Installation in the front drive cage of the removable drive bay
500 GB (SATA)
•
1000 GB (SATA)
•
2 × 1000 GB (SATA)
•
RAID1**: 1000 GB (2 × 1000 GB, SATA)
•
RAID5**: 2TB (3 × 1000 GB, SATA)
•
** An additional hot-spare drive or additive SSD drive can be
ordered as an option.
240 GB MLC
•
PCIe x16 graphics card, dual head (2 × VGA or 2 × DVI-D)
1
