Connecting to the System Board
Plug the internal USB cable from the HP Media Card Reader
directly into an available 2x5 USB connector on the system
board.
CAUTION: Some system boards do not have an available USB connector.
Ä
If you unplug the USB cable that is connected to the system board to free
up a connector for the HP Media Card Reader, the front USB ports on the
computer will not function.

Reassembling the Computer

After installing the HP Media Card Reader and, if necessary, the
PCI card:
1. Replace the front bezel.
2. Replace the computer cover or access panel.
3. Plug in and power on the computer.
The HP Media Card Reader should now be ready for use. If you
encounter problems, refer to the
Installation Guide
HP Media Card Reader with PCI Card
"Troubleshooting"
www.hp.com
section.
9
