- Page 1 Handheld Thermography Camera User Manual UD13441B 0504061090125 COPYRIGHT © 2019 Hikvision. ALL RIGHTS RESERVED...
- Page 2 PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURIMicro SDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
- Page 3 compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Warnings Follow Cautions Follow these these safeguards to precautions to prevent serious injury prevent potential or death. injury or material damage. Warnings The device should be used in compliance with local laws and electrical safety regulations. Refer to the appropriate documentation for detailed information.
- Page 5 Before enabling the Light Supplement function, make sure no human or inflammable substances are in front of the laser lens. Manufacture address : Qianmo No.555 Road, Binjiang District, Hangzhou 310052, China Hangzhou Hikvision Digital Technology Co.,Ltd SAVE THIS MANUAL FOR FUTURE REFERENCE...
-
Page 6: Box Content
1 Introduction 1.1 Box Content Handheld Thermal Camera (×1) Power USB Cable Wrist Strap Adapter (×1) (×1) (x1) Manual (×1) Disk (×1) Note: The Handheld Thermography Camera includes one battery and one Micro SD card. 1.2 Product Introduction The handheld Thermography camera is a camera with thermal images. - Page 7 2 Appearance 2.1 Dimensions 59mm(2.32") 78mm(3.07") The dimension may vary according to different camera model. 2.2 Interfaces Screen Charging Indicator Back On/OK/Menu Navigation Hold: Power On/Off Press: Display menu or confirm operation Exit the menu or return to previous menu. Navigation Button Press the ▽, △button to select parameters.
-
Page 8: Basic Operations
Cover USB Interface Micro SD Slot Laser Tripod IR Lens Interface Trigger Charging When the device is charging, Indicator the LED indicator is red. When the device is fully charged, the LED indicator is green. Charge the battery and export Interface snapshots with the USB cable. -
Page 9: Interface Description
3.2 Interface Description Unit Status Icons Max. Temperature Display Real-time Center Temperature Color- Center Temperature Temperature Display Scale Real-time Temperature Min. Temperature Display Emissivity 3.3 Format Micro SD Card Before you start: Confirm the Micro SD card is properly installed before use. -
Page 10: Export File
3.6 Export File Purpose: Connect the handheld Thermography camera to your PC with USB cable, you can export the captured snapshots. Steps: Open the USB cover. Connect the camera to your PC with USB cable and open the detected disk. Select and copy the snapshots to PC and view the files. -
Page 11: Other Configurations
Emissivity: Set the emissivity of your target as the effectiveness in emitting energy as thermal radiation. Note: Refer to the 6.1 Common Material Emissivity Reference for emissivity values. Temperature: Set the average temperature of the environment. Distance (m/feet): Set the straight-line ... -
Page 12: Common Material Emissivity Reference
6 Appendix 6.1 Common Material Emissivity Reference Material Emissivity Human Skin 0.98 0.91 Cement Concrete 0.95 Ceramics 0.92 Rubber 0.95 Paint 0.93 Wood 0.85 Asphalt 0.96 Brick 0.95 Sand 0.90 Soil 0.92 Cotton 0.98 Cardboard 0.90 White Paper 0.90 Water 0.96 6.2 Frequently Asked Questions (FAQ)
