Page 1: Quick Start Guide
Thermal+Optical Bi-spectrum Network Speed Dome Quick Start Guide UD.6L0201B2060A01... - Page 2 Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to Thermal+Optical Bi-spectrum Network Speed Dome. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
-
Page 3: Regulatory Information
Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
- Page 5 Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can cause fire danger). Do not aim the speed dome at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a malfunction however), and affecting the endurance of sensor at the same time.
-
Page 6: Table Of Contents
Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Table of Contents 1 Overview ...................... 1 2 Installation ....................2 3 Setting the Dome over the LAN ..............7 3.1 Wiring ........................7 3.2 Activating the Speed Dome ..................7 3.2.1 Activation via Web Browser ................7 3.2.2 Activation via SADP Software ................ -
Page 7: Overview
Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide 1 Overview Please turn the power off before connect the cables. The overview of the network speed dome is shown as follows. The cables are distinguished by different colors. The labels attached on the cables are for identification. -
Page 8: Installation
Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide 2 Installation Before you start: 1. Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. 2. Please turn off the power of the speed dome before connecting the cables. Do not drag the speed dome with its waterproof cables as shown in Figure 2-1, otherwise the waterproof performance is affected. - Page 9 Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Steps: 1. Remove the protective sticker as shown in Figure 2-2. Protective Sticker Figure 2-2 Remove Protective Sticker 2. Remove the cover on the back of the speed dome. Insert the SD card to the SD card slot and install the cover back.
- Page 10 Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Figure 2-5 Secure the Head Cover 5. Buckle the handle to the safety rope. Figure 2-6 Buckle the Handle 6. Hook the two ends of the safety rope to the back box of the speed dome and the bracket respectively.
- Page 11 Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide 8. Route the cables through the head cover and bracket. Figure 2-8 Route the Cables 9. Align the back box of the speed dome with the head cover. Use an L-wrench to tighten the lock screws to secure the speed dome and the bracket.
- Page 12 Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Pendant Adapter Lock Screw Figure 2-10 Pendent Adapter...
-
Page 13: Setting The Dome Over The Lan
Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide 3 Setting the Dome over the LAN 3.1 Wiring To view and configure the speed dome via LAN (Local Area Network), you need to connect the network speed dome in the same subnet with your PC. Then, install the SADP or client software to search and change the IP of network speed dome. -
Page 14: Activation Via Sadp Software
Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Figure 3-2 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. -
Page 15: Modifying The Ip Address
Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Figure 3-3 SADP Interface 3. Create a password and input the password in the password field, and confirm the password. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. - Page 16 Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide Please refer to section 3.2 to activate the speed dome if it is inactive. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-4 Modify the IP Address 4.
-
Page 17: Accessing Via Web Browser
Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide 4 Accessing via Web browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 7.0 and above version, Apple Safari 5.02 and above... - Page 18 Thermal+Optical Bi-spectrum Network Speed Dome·Quick Start Guide You may have to close the web browser to finish the installation of the plug-in. Figure 4-2 Download Plug-in Figure 4-3 Install Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login.
