Summary of Contents for ELTEX RG-34-Wac
- Page 1 RG-34-Wac User manual, version 1.6 (02.2017) Subscriber router IP-address: http://192.168.1.1 User name: admin password: password...
- Page 2 2.2 Features of the device 2.6 Reset of the device and factory reset Added: 4.2 Application of configuration and cancellation of changes 4.3 Device control panel Version 1.0 28.10.2015 First issue Software version Software version: 1.10.0-b8 Web interface version: 1.0.3 ____________________________________________________________________________________ Subscriber router RG-34-Wac...
-
Page 3: Table Of Contents
4.3.7 ‘Quality of Service (QoS)’ menu ......................37 4.3.8 ‘Routing Setup’ menu ........................... 38 4.3.9 ‘USB settings’ menu ..........................39 4.3.9.1 ‘USB storage’ menu ........................... 39 4.3.9.2 ‘FTP server’ submenu ........................39 4.3.10 ‘Management’ menu .......................... 40 ____________________________________________________________________________________ Subscriber router RG-34-Wac... - Page 4 4.3.10.4 ‘Port configuration’ submenu ......................42 4.3.10.5 ‘Access management’ submenu ......................44 4.3.10.6 ‘Denial-of-Service’ submenu ......................45 4.3.10.7 ‘Log’ submenu ............................ 47 4.3.10.8 ‘Upgrade Firmware’ submenu ......................48 4.3.10.9 ‘Save/Load settings’ submenu ......................49 4.3.10.10 ‘TR-069 config’ submenu ......................... 49 ____________________________________________________________________________________ Subscriber router RG-34-Wac...
-
Page 5: Introduction
RG-34-Wac device is a WI-FI Access Point with integrated router. Main intended purpose of RG-34-Wac is installation of access point inside of buildings to various sources via wired and wireless networks of data transmission. -
Page 6: Description Of The Device
The subscriber router RG-34-Wac (“device”) is intended for provision of users’ access for high-speed, safe network of data transfer. RG-34-Wac device is a single point of access to modern interactive services via wired and wireless data transfer networks: Internet and Full HD IPTV. - Page 7 Support of IPTV functions (IGMP-proxy, UDP-to-HTTP proxy); Software update via web-interface; TR-069; Remote monitoring, configuration and setting: Web-interface, Telnet. Please see the RG-34-Wac application flowchart on the figure 1. Figure 1 – RG-34-Wac application flowchart ____________________________________________________________________________________ Subscriber router RG-34-Wac...
-
Page 8: Main Technical Parameters
Power adaptor 5V DC, 2,5 А. Not more than 4 W Power consumption Range of working temperatures from +5 to +40°С Relative humidity at 25°С Up to 80% Overall dimensions 430x159x43,6 mm Weight Not more than 0,2 kg. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 9: Form Factor
The appearance of RG-34-Wac front panel is represented on Figure 2 Figure 2 – Appearance of RG-34-Wac front panel Following light indicators are located on the upper panel of RG-34-Wac, see Table 2. Table 2 – Description of upper panel indicators... -
Page 10: Back Panel Of The Device
Appearance of RG-34-Wac back panel is represented on Figure 3. Figure 3 – Appearance of RG-34-Wac back panel Following plugs and controls are located on RG-34-Wac back panel, see Table 3. Table 3 – Description of indicators and controls on RG2400 back panel... -
Page 11: Reset Of The Device And Factory Reset
____________________________________________________________________________________ Current status of the device is represented by means of indicators paced on the upper panel. The indicator statuses are listed in the Table 5. Table 5 – Light indication of RG-34-Wac status Indicator Indicator status Ddevice status Wi-Fi-network is active in the range of 2,4 GHz... -
Page 12: Scope Of Supply
____________________________________________________________________________________ 2.8 Scope of supply The basic scope of supply of RG-34-Wac includes: – Subscriber router; – Power adaptor 220/5В 2,5 А; – User manual. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 13: Installation
1. Connect network Ethernet cable of your Internet provider to WAN RG-34-Wac plug, see figure 3. 2. If RG-34-Wac will be used as home cable router, connect network Ethernet cable to LAN RG-34- Wac plugs of the router and your network device (PC, printer, set-top box etc). -
Page 14: Operation Of The Device Via Web-Configurator
The changes are cancelled only before clicking on ‘Apply’. In this case the parameters changed on the page will be updated by current values, recorded in the memory of the device. No return to previous settings is possible after clicking on ‘Apply changes’. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 15: Device Control Panel
1. Buttons of configuration application, device reload and change of WEB-interface language. 2. Tab tree for settings. 3. Main field of settings of the device, corresponding to selected tab from the field 2. 4. Buttons of configuration changes save and cancellation of changes to previous unsaved values. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 16: Setting Wizard' Menu
WAN-interface parameters (Internet); Wi-Fi parameters of networks of 2.4 GHz and 5 GHz. After completion of all settings in the wizard, the device will reboot for application of new configuration. 4.3.3 ‘Operation mode’ menu ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 17: Wireless Network' Menu
In ‘Wireless network’ menu wireless Wi-Fi network settings are performed. The settings are performed for Wi-Fi network at frequency of 2.4GHz or 5 GHz. The device supports the work in both frequency ranges simultaneously. 4.3.4.1 ‘Main settings’ submenu ____________________________________________________________________________________ Subscriber router RG-34-Wac... - Page 18 — Show Active Clients – opens a table with list of all clients connected to Wi-Fi network in a new window; — MultipleAP – allows you to configure one or several open visited networks with access restriction to speed and network resources ____________________________________________________________________________________ Subscriber router RG-34-Wac...
-
Page 19: Advanced Settings' Submenu
Takes values from 20 to 1024; — IAPP – IAPP protocol (Inter-Access Point Protocol) allows to use roaming of clients between multiple access points within one network segment; ____________________________________________________________________________________ Subscriber router RG-34-Wac... - Page 20 — Multicast to Unicast – allows to transmit a Unicast stream to wireless Multicast devices, provided that UDP2HTTP option in WAN interface settings is switched on; — RF Output Power – adjustment of access point signal strength in per cents from maximal level. ____________________________________________________________________________________ Subscriber router RG-34-Wac...
-
Page 21: Security' Submenu
It is permitted to use only following characters: a-z, A-Z, 0-9, ~!@#$%^&*()_- +=;:\\|/?.,<>”`’ or space. It is advisable to use WPA and WPA2 encryption modes as the most safe now. It is advisable to use WPA-Mixed and WPA2 encryption modes as the most safe. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 22: Wi-Fi Access Control' Submenu
(selectively) and required (mandatory). If you choose capable the section is available to activate hashing according to SHA256 algorithm. 4.3.4.4 ‘Wi-Fi access control’ submenu Access filtering according to Wi-Fi and MAC-address of the client is performed in ‘Wi-Fi access control’ submenu. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 23: Network Overview' Submenu
Use the ‘Network overview’ submenu to launch searching of the other Wi-Fi networks in specified frequency range with the aim of less loaded channel determination in case of network fine tuning. Also you can perform connection to provider’s wireless network in the WISP operation mode. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 24: Wps' Submenu
WPS – standard of semi-automated generation of Wi-Fi wireless network. The purpose of WPS protocol is simplification of wireless network setting. WPS assigns the name of the network automatically and assigns encryption for protection from unsanctioned access to the network, there is no need to assign all parameters manually. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 25: Schedule' Submenu
Wireless interface operation intervals in various hours and week days are generated in this menu. Wireless network by activated function will be inaccessible in the time which is not included into the schedule. The schedule function is deactivated by default. ____________________________________________________________________________________ Subscriber router RG-34-Wac... - Page 26 ____________________________________________________________________________________ – Enable Wireless Schedule – when the flag is set, Wi-Fi network in the selected range is working in accordance with specified schedule. ____________________________________________________________________________________ Subscriber router RG-34-Wac...
-
Page 27: Air Time Fairness' Submenu
— Comments – field for comments on the entry to the list, e.g. Wi-Fi client name. 4.3.5 ‘TCP/IP settings’ menu LAN and WAN interfaces of the device are accessible for configuration. 4.3.5.1 ‘LAN Interface’ submenu The parameters of local interfaces of the device and DHCP-server are in ‘LAN Interface’ submenu. ____________________________________________________________________________________ Subscriber router RG-34-Wac... - Page 28 — DHCP Lease Time – time of lease in minutes upon expiry of which the client shall either make the address free or prolong it for the same time interval; — Set Static DHCP – allows to assign static IP-addresses to connected clients; — Domain Name – DHCP-server domain name. ____________________________________________________________________________________ Subscriber router RG-34-Wac...
-
Page 29: Wan Interface' Submenu
‘PPPoE’ following parameters will be available for adjustment: – User name – user name for authorization in PPPoE-server; – Password – password for authorization; – Service Name – Service Name tag value in PADI message (field is optional to complete); ____________________________________________________________________________________ Subscriber router RG-34-Wac... - Page 30 MTU size defines size of Ethernet frames transmitted via WAN-port; – DNS setting – addresses of used DNS-servers may be received both on DHCP automatically, and specified manually; – Local DNS allows to assign domain name for definite IP address within local network; ____________________________________________________________________________________ Subscriber router RG-34-Wac...
- Page 31 PPTP can be applied in IP-networks only, and separate TCP connection is necessary for it for creation and use of the tunnel. ____________________________________________________________________________________ Subscriber router RG-34-Wac...
-
Page 32: Firewall' Menu
— Port Range – number of ports are entered, the traffic from which you want to restrict; — Protocol – selection of protocol type of TCP traffic, UDP or both of them; — Comment – field for comments for filters. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 33: Ip Filtering' Submenu
— Local IP Address – IP-address of the device is entered, which is intended to have limited access; — Protocol – selection of protocol type of TCP traffic, UDP or both of them; — Comment – field for comments for filters. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 34: Mac Filtering' Submenu
— Enable MAC Filtering – when the flag is set, the filter is switched on; — МАС Aaddress – МАС-address of the device is entered, which is intended to have limited access; — Comment – the field for comments for filters. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 35: Port Forwarding' Submenu
— Protocol – selection of protocol type of TCP traffic, UDP or both of them; — Port Range Input – range of forwarded ports on WAN interface is specified; — Source port — source port of the device getting traffic in LAN; — Comment – field for comments for filters. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 36: Url Filtering' Submenu
DMZ-host usually contains services such as Web-server, FTP-server, DNS-server and others. — Enable DMZ – when the flag is set, DMZ is on; — DMZ Host IP Address– client’s IP-address in LAN-network, which shall be removed to DMZ. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 37: Quality Of Service (Qos)' Menu
— Local IP Address – is assigned by selected type of client’s IP address; — Local МАС Address is assigned for selected address type of МАС client; — Mode – allows you to choose between two options: ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 38: Routing Setup' Menu
— Enable Dynamic Route – when the flag is set, function of dynamic routing is active; — NAT – use by dynamic routing; — Transmit/Receive – selection of used dynamic routing protocol of RIP1 or RIP2 for respective option. Static routing ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 39: Usb Settings' Menu
You can perform various actions on files by the submenu: – Download files to a USB storage; – Download files to computer memory; – Delete files from a USB storage. 4.3.9.2 ‘FTP server’ submenu This submenu displays parameters of the integrated FTP server. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 40: Management' Menu
4.3.10.1 ‘Status’ submenu This submenu shows information about the device and main settings such as: — System parameters (time and version of the firmware); — Wireless interfaces parameters; — LAN-network settings; — WAN-port settings. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 41: Statistics' Submenu
____________________________________________________________________________________ 4.3.10.2 ‘Statistics’ submenu This menu contains the data about transferred and received packets via each interface. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 42: Time Zone Settings' Submenu
— Manual Address Setting – you may select the server from the proposed list or enter it manually. 4.3.10.4 ‘Port configuration’ submenu Use this submenu to configure parameters of LAN ports. By default, Auto value is assigned. You can change only parameters for active interfaces. ____________________________________________________________________________________ Subscriber router RG-34-Wac... - Page 43 ____________________________________________________________________________________ ____________________________________________________________________________________ Subscriber router RG-34-Wac...
-
Page 44: Access Management' Submenu
Enable IP Access – allows you to configure access to Web interface of the device from the WAN, only for the device with IP addresses from the list; – IP Address – field for entering IP address. You can add to the list up to 5 IP addresses. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 45: Denial-Of-Service' Submenu
To prevent from DoS-attacks recognition algorithms of suspicious packet activities incoming to WAN-port, different types of traffic are activated by default in the device which, if necessary deny packet processing from a certain source or a certain (suspicious) type of packets that may come from different addresses. ____________________________________________________________________________________ Subscriber router RG-34-Wac... - Page 46 — Enable Source IP Blocking – if the flag is set, when the source of attack is detected, blocking it for specified time. Upon expiry of the timer, blocking is cancelled, but can be activated again, if the attack does not stop. ____________________________________________________________________________________ Subscriber router RG-34-Wac...
-
Page 47: Log' Submenu
DoS – information about performance of protection from DoS-attacks. — Enable Remote Log – when the flag is set, corrective information will be sent to remote server on syslog protocol. Its address will be assigned in the field of ‘Remote server IP-address’. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 48: Upgrade Firmware' Submenu
— Available version – software version which is available for update in server. To check if actual firmware version is available in server, push the button ‘Check updates’. Internet access is necessary to check the update. ____________________________________________________________________________________ Subscriber router RG-34-Wac... -
Page 49: Save/Load Settings' Submenu
– Reset Settings to Default – push ‘Reset’ for factory reset of the device. 4.3.10.10 ‘TR-069 config’ submenu TR-069 subscriber devices automated configuration protocol is set in the ‘TR-069 config’ submenu. ____________________________________________________________________________________ Subscriber router RG-34-Wac... - Page 50 User name, password – user name and password for cleint’s access to ACS-server. Connection Request: – User name, Password – user name and password for ACS-server access to TR-069 client; – Path– the path in file system of the server; – Port – port used for connection. ____________________________________________________________________________________ Subscriber router RG-34-Wac...
- Page 51 E-mail: techsupp@eltex.nsk.ru Technical documentation and software for equipment produced by Eltex LLC are available at official webpage of the company. You may consult the knowledge base, file an interactive application for support and consult Service Center staff at technical forum: http://www.eltex.nsk.ru/...
