REPLACEMENT PARTS FOR CT SERIES BOILERS

150 PSI w/ Panel Box with Pressure Controls & Warrick LWCO/Pump Control
REF. No.†
1 BURNER – CONSULT FACTORY
2 BOILER BLOWDOWN 1" Y-VALVE
BOILER BLOWDOWN 1-1/4" Y-VALVE
3 BOILER BLOWDOWN 1" BALL VALVE
BOILER BLOWDOWN 1-1/4" BALL VALVE
4 CONTROL PANEL-BOX (SEE DWG. CT-546)
CONTROL PANEL-BOX (SEE DWG. CT-546)
4A SWITCH, "POWER" ON-OFF
4B SWITCH "PUSHBUTTON, "PROBE RESET"
4C LAMP ASSEMBLY "PROBE ON" (RED)
4D LAMP ASSEMBLY "LOW WATER" (RED)
4E LAMP ASSEMBLY "PUMP ON" (AMBER)
4F TERMINALS (SUPPLIED IN 3-TERMINAL UNITS)
4G TERMINAL BLOCK MOUNTING END
4H WARRICK DUAL FUNCTION CONTROL MODULE
4J WARRICK PROBE LWCO MODULE, 26C1C0-C
4K MOTOR CONTACTOR
4M MOTOR STARTER, 3-PHASE
5 WARRICK LWCO & PUMP CONTROL
5A HIGH PROBE, "PUMP OFF", 8"
5B LOW PROBE, "PUMP ON", 9-1/2"
5C PRIMARY LOW WATER CUT-OFF PROBE, 11"
6 WATER GAUGE SET
6A 5/8" X 10-1/4" GAUGE GLASS
6B TRI-COCKS (3) – (OPTIONAL)
6C GAUGE GLASS PROTECTOR, LEXAN
7 LWCO BLOWDOWN VALVE, 1" BALL VALVE
8 PRESSURE CONTROLS
8A SAFETY LIMIT W/ MANUAL RESET
8B OPERATING LIMIT, KP36
8C HIGH FIRE, KP36
9 STEAM PRESSURE GAUGE, 0-300 PSI
10 SECONDARY LOW WATER CUT-OFF PROBE ASSY.
w/MANUAL RESET, WARRICK
10A SECONDARY LWCO PROBE PLUG
DESCRIPTION BOILER MODEL
ALL SEE PARTS LIST
ALL X/C CT-50
CT-50
ALL X/C CT-50
CT-50
CT-6 THRU CT-25
CT-35, CT-50
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
CT-35, CT-50
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
CT-35 & CT-50 oil only
ALL
ALL (ALSO SEE "4J")
ALL
ITEM NUMBER
579005
579006
570118
570132
558850
558854
558858
558904
558860
558860
558862
558864
558866
558800
558885
558885
901716
558840
571020
571090
571080
966044
570118
553615
553610
553610
559305
558920
