Eaton Magnum DS Instruction Booklet page 2

Instruction Booklet IB01900001E
Effective August 2017
Read and understand these instructions before attempting to
unpack, assemble, operate or maintain this type equipment.
ALL POSSIBLE CONTINGENCIES WHICH MAY ARISE DURING
INSTALLATION, OPERATION OR MAINTENANCE, AND ALL DETAILS AND
VARIATIONS OF THIS EQUIPMENT DO NOT PURPORT TO BE COVERED BY
THESE INSTRUCTIONS.
If further information is desired by purchaser regarding the particular
installation, operation or maintenance of particular equipment, con-
tact the local Eaton representative.
WARNING
METAL-ENCLOSED LOW-VOLTAGE ARC-RESISTANT SWITCHGEAR
ASSEMBLIES COVERED BY THESE INSTRUCTIONS ARE DESIGNED AND
TESTED TO OPERATE WITHIN THEIR NAMEPLATE RATINGS. OPERATION
OUTSIDE OF THESE RATINGS MAY CAUSE THE EQUIPMENT TO FAIL
RESULTING IN DEATH, SERIOUS INJURY AND/OR PROPERTY DAMAGE.
ALL RESPONSIBLE PERSONNEL SHOULD LOCATE THE EQUIPMENT RATING
NAMEPLATE AND BE FAMILIAR WITH THE INFORMATION PROVIDED
THEREON.
Purpose
This instruction manual is expressly intended to cover the installa-
tion, operation and maintenance of Magnum DS® Metal-Enclosed
Low-Voltage Arc Resistant Switchgear used with Magnum DS®
Power Circuit Breakers.
THIS INSTRUCTION MANUAL IS INTENDED TO EMPHASIZE THE FEATURES
AND ENHANCEMENTS UNIQUE TO MAGNUM DS ARC RESISTANT
SWITCHGEAR. IT IS NOT INTENDED TO BE A COMPLETE MANUAL FOR
THE INSTALLATION, OPERATION AND MAINTENANCE OF MAGNUM DS
METAL-ENCLOSED LOW-VOLTAGE ASSEMBLIES, BUT IS SUPPLEMENTAL
IN NATURE; AND APPENDS THE ORIGINAL ONLY AS DESCRIBED HEREIN.
FOR COMPLETE INSTRUCTIONS CONCERNING MAGNUM DS METAL-
ENCLOSED LOW-VOLTAGE ASSEMBLIES, SEE IB01901001E.
For application information consult applicable descriptive bulletins,
application publications and/or the applicable industry standards.
For installation, operation and maintenance of Low-Voltage Power
Circuit Breakers see separate instruction book listed in Section 4.
2
EATON www.eaton.com
NOTICE
NOTICE
Instructions for Magnum DS Metal-Enclosed
Low-Voltage ARC Resistant Switchgear Assemblies
CAUTION
ALL APPLICABLE SAFETY CODES, SAFETY STANDARDS, AND SAFETY
REGULATIONS MUST BE STRICTLY ADHERED TO WHEN INSTALLING,
OPERATING, OR MAINTAINING THIS EQUIPMENT.
THE DANGER, WARNING AND CAUTION MESSAGES INCLUDED AS PART
OF THE PROCEDURAL STEPS IN THIS MANUAL ARE FOR PERSONNEL
SAFETY AND PROTECTION OF EQUIPMENT FROM DAMAGE. AN
EXAMPLE OF A TYPICAL WARNING LABEL HEADING IS SHOWN ABOVE
THIS PARAGRAPH TO FAMILIARIZE PERSONNEL WITH THE TYPE OF
PRESENTATION. THIS WILL HELP TO ASSURE THAT PERSONNEL ARE
ALERT TO THESE MESSAGES. IN ADDITION, THESE MESSAGES ARE ALL
UPPER CASE AND BOLDFACE.
NOTICE
