Using The Help Program; Key To File Names - Extron electronics MLS 100 A User Manual

Follow the on-screen instructions.
8.
NOTE:
When you recycle power, power off the switcher for at least four seconds, then restore power.
When the firmware uploading is complete, a dialog box appears and asks you to:
9.
•
Exit the firmware update utility program if the new firmware loaded correctly (if the correct firmware version is
displayed in the program window, as shown in the example below)
or
•
Run the utility again if the firmware did not load correctly.
Follow the on-screen directions to complete the process.
10.

Using the Help Program

For information on program features, press the <F1> computer key, or click on the Help menu within the MediaLink control
program, or double-click on the MediaLnk Help icon in the Extron group or folder.
For explanations of buttons or functions, click on the tabs in the help screen to reach the desired screen. Use a mouse or the
<Tab> and <Enter> keys to select a button/function. A description and tips on using the program appear on screen.

Key to File Names

Filename Description
________.MLK User‑saved MLC/MLC‑MLS/MLS configuration file. This includes adjustments/ settings. If the MLS is connected
to an MLC 206, the file also contains whatever driver (if any) was installed in the MLC 206 at the time the file was
saved. See the MLS 206 User Manual for details.
_______.s19 This is an Extron‑supplied firmware update file. When the firmware is replaced, the switcher is also automatically
reset to factory default settings.
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the
Extron Safety and Regulatory Compliance Guide
