Aolait AL1019PWZ Manual

LED Par light with zoom instructions

1. The Display section

A B C D
Operating instructions: It will show 12 different function effect when press the function keys, first two digits
represent the current function (referring to menu), last two digits represent function value: such as address code
or speed. Press B or C to change value and press D to confirm.

2. Background display window function

save and exit.)
Serial display
number
1 R235
2 G235
3 B235
4 o235
5 n000
6 U128
7 J128
8 T005

3. LED display functional table

Serial display
number
1 A001
A．Function keys
B．+ Key
C．- Key
D. Enter key
E.LED display window
(Press A in D001 into the background setting, press D to
Function description
Red current， （020—255） default 235
B, C key to modify current
green current， （020—255） default 235
B, C key to modify current
blue current， （020—255） default 235
B, C key to modify current
white current， （020—255） default 235
B, C key to modify current
electrical machine vigor， （000—008） default 0
B, C key to modify electrical machine vigor
electrical machine route， （000—255） default 128
B, C key to modify electrical route
electrical machine revise， （000—255） default 128
B, C key to modify electrical revise
electrical machine speed， （000—028） default 5
B, C key to modify electrical speed
Function description
Address code， （001—512）
