- Page 1 5R/7R Beam Moving Head User Manual...
- Page 2 Preface Anyone undertake the installation, operation and maintenance of light fixture, should be required: -------professional qualification & experience -------Operating strictly under the instruction of this manual -------Keeping the manual until never use -------Making full notes in the manual after repair or fix. When unpacking and before disposing of the carton, check there is no transportation damage before using the projector.
- Page 3 At least use 2 safety ropes to install light (height almost 100cm), and ropes must be able to carry tenfold weight of light. Child & non-professional do not touch light fixture! Professional should watch over light when it using. This light could not maintained by user, except bulb & protective tube, repairing & maintaining must follow authorized dealer.
-
Page 4: Dmx Channel Table
Specification Voltage: 100—240V AC，50-60Hz。 Power: 400W Lamp: 5R/7R 200W/230W Lamp Color：14colors+white Gobo：17gobos+white Prism： 8-facet circular prism/ 16-facet circular prism/linear prism Dimmer：0—100% linear dimmer Strobe：1-13 flash/second X/Y: 540° /270° Channels:16 chs IP rating: IP20 Operating temperature：-20℃--40℃ DMX CHANNEL TABLE DMX 1:COLOR Wheel 0-3:White 4-7:White/COLOR1 8-11:COLOR1... - Page 5 115-118:COLOR13/COLOR14 119-122:COLOR14 123-127:COLOR14/White 128-191: Change Colours rotation left (fast to slow) 128-255: Change Colours rotation right(slow to fast) DMX 2:SHUTTER 0-3:Close 4-7:Open 8-97:Strobe slow to fast 98-101:Close 102-126:Open Jump strobe slow to fast 127-151:Close Jump strobe slow to fast 152-155:Open 156-180:Random open Jump strobe slow to fast 181-205:Random close Jump strobe slow to fast 206-209:Open...
- Page 6 160-165:Gogo1 shake,slow-fast speed 166-171:Gogo2 shake,slow-fast speed 172-178:Gogo3 shake,slow-fast speed 179-184:Gogo4 shake,slow-fast speed 185-191:Gogo5shake,slow-fast speed 192-197:Gogo6 shake,slow-fast speed 198-203:Gogo7 shake,slow-fast speed 204-210:Gogo8 shake,slow-fast speed 211-216:Gogo9 shake,slow-fast speed 217-222:Gogo10 shake,slow-fast speed 223-239:Gogo11 shake,slow-fast speed 240-245:Gogo12 shake,slow-fast speed 246-251:Gogo13 shake,slow-fast speed 252-255:Gogo14 shake,slow-fast speed DMX 5:PRISM 0-127:No 128-255:Prism...
- Page 7 0-255: DMX 13:TILT FINE 0-255: DMX 14:XY SPEED 0-255:FAST TO SLOW DMX 15:FUNCTION 0-13:UNUSED RANGE 14-24:PAN TILT MOVES,BLACKOUT 25-35:CHANGE GOBOS,BLACKOUT 36-46:CHANGE COLORS,BLACKOUT 47-57:CHOOSE PRISMS,BLACKOUT 58-68:CHOOSE FROST,BLACK OUT 69-79:PAN-TILT,GOBO,Colour,FROST,CHANGING, BLACKOUT 80-90:GOBO,Colour,FROST,FUNCTION,CHANGES, BLACKOUT 91-123:UNUSED RANGE 124-134:Reversal Display(5 sec) 135-145:Dispaly Back(5 sec) 146-156:UNUSED RANGE 157-167:HEAD MOTOR RESET 168-178:PAN-TILT RESET 179-189:WHOLE MACHINE RESET...
- Page 8 Invert Pan Invert Tilt Display Reversal BackLight Open Auto Close(15s) Information System Version DISP: V1.02 MOTOR: Fixture Hours Total:0000(hrs) Cur.:0000(hrs) Lamp Hours Total:0000(hrs) Cur.:0000(hrs) Time Clear Clear PWRON Time Clear LAMP Time DMX Monitor 1.Color (000) 2.Strobe (000) 3.Dimmer (000) 4.Gobo (000) 5.PrismIns.(000) 6.PrismRot.(000)
- Page 9 Reset System Reset Pan/Tilt Reset Effect Reset Factory default Input: 0000 Cleaning and Maintenance Note should cut off the power before to clean and maintaining of the projector. Do not use the projector if the lens is damaged, such as crack or scratch and so on, make sure to keep its normal functions Users should keep taking a full testing for the light security &...
