USER GUIDE AND SPECIFICATIONS
NI WSN-3202
NI Wireless Sensor Network 4-Channel, 16-Bit Analog Input Node
This user guide describes how to use the NI WSN-3202 analog input node and lists its specifications.
Figure 1 shows the NI WSN system components.
1
NI WSN-32 xx Nodes
1
2
NI 9792 WSN Real-Time Gateway
The NI WSN-3202 is a four-channel, low-power, wireless voltage input device that works with other
NI WSN-32xx nodes and gateways to form a wireless sensor network. The NI WSN system consists of
one or more NI WSN gateways, up to 36 NI WSN-32xx nodes per gateway, and multiple PCs or
Programmable Automation Controllers (PACs) to receive and analyze the distributed sensor data. For
more information about PACs, visit
2
Or
1
3
NI WSN-9791 Ethernet Gateway
4
PC Running NI Software
Figure 1. NI WSN System Components
.
ni.com
4
3
