Figure F-11 Switching frequency filter inductor (Type 3)
100
A1
H
A2
Figure F-12 Switching frequency filter inductor (Type 4)
160
H
320 fixing centres
L
480
52
100
B1 C1
B2 C2
204
L
300
160
4 OFF 14 HOLES
IN EACH FLAG
4 OFF 11
FIXING HOLE
www.controltechniques.com
200
4 OFF S
10mm W
133
D
163
S
240 fixing centres
D
280
