F.3

Switching frequency filter capacitors

F.3.1 3-phase capacitors (size 1 and 2)
Figure F-6 Dimensions
Before protection
device operation
11.8 ±0.5
L +2-0
Table F-4 Specifications
CN
Drive size
(µF)
1 & 2 3 x 5.7
48
After protection
device operation
Max 16
Marking
M8 to Ø = 53mm
Fast-on terminal (6.35mm)
Internal connection
ØD
∅ x L
Weight
Mounting
(mm) (kgs)
53 x 116 0.3 M8 Stud
www.controltechniques.com
16 ±1mm
CT part number
1610-5752
Unidrive Regen Installation Guide
Issue Number: 2
