Appendix E
Table E-1 Drive ratings in 40°C ambient
Model Rating
UNI 1405 4kW
UNI 2401 5.5kW
UNI 2402 7.5kW
UNI 2403 11kW
UNI 3401 15kW
UNI 3402 18.5kW
UNI 3403 22kW
UNI 3404 30kW
UNI 3405 37kW
UNI 4401 45kW
UNI 4402 55kW
UNI 4403 75kW
UNI 4404 90kW
UNI 4405 110kW
UNI 5401
Table E-2 Drive ratings in 50°C ambient
Model Rating
UNI 1405 4kW
UNI 2401 5.5kW
UNI 2402 7.5kW
UNI 2403 11kW
UNI 3401 15kW
UNI 3402 18.5kW
UNI 3403 22kW
UNI 3404 30kW
UNI 3405 37kW
UNI 4401 45kW
UNI 4402 55kW
UNI 4403 75kW
UNI 4404 90kW
UNI 4405 110kW
UNI 5401
*No UL approval for Unidrive size 5 with 240A continuous in a 50°C ambient.
44
Unidrive Regen specifications
Maximum permissible continuous output
current
3kHz 4.5kHz 6kHz
9.5A 8.5A
12A
16A
25A 21.7A 18.2A
34A
40A 37A
46A 40A
60A 47A 40A
70A 56A 46A
96A 88A
124A 104A 88A
156A 124A 105A
180A 175A 145A
202A 175A 145A
300A
Maximum permissible continuous output
current
3kHz 4.5kHz 6kHz
6.9A 5.9A 5.1A
12A
16A 14.7A
20A 17.3A 14.7A
34A 28A
40A 34A 28A
44A 36A 31A
44A 36A 31A
50A 41A 34A
95A 85A 75A
105A 85A 75A
135A 105A 85A
180A 150A 125A
190A 150A 125A
240A*
www.controltechniques.com
Maximum
overload time
9kHz 12kHz 60sec
7A 5.5A
11.7A
14.2A 11.7A
14.2A 11.7A
28A 23A
28A 23A
32A 26.6A
150%
32A 26.7A
35A 28A
70A
70A
80A
110A
110A
120%
Maximum
overload time
9kHz 12kHz 60sec
4.0A 3.3A
11.6A 9.7A
11.6A 9.7A
11.6A 9.7A
21A 17.9A
21A 17.9A
24A 20.6A
150%
24A 20.9A
26A 23A
60A
60A
65A
95A
95A
150%
