Mimo Monitors MST-23016 User Manual

23'' shelf edge display with android player
Hide thumbs Also See for MST-23016:
Table of Contents

Advertisement

Quick Links

Download this manual
23" Shelf Edge Display User's Manual
with Android Player
Please keep this manual for future reference.
SAFETY INSTRUCTIONS .....................................................................................1
Declarations and Statements................................................................2
WHAT'S IN THE BOX .......................................................................................3
Package Contents...............................................................................3
MOVING THE DISPLAY....................................................................................4
Unpacking the Display.............................................................................4
Carrying the Display....................................................................................6
Placing the Display......................................................................................6
Setting Down the Display.........................................................................6
MOUNTING THE DISPLAY...................................................................................7
Orienting the Display...............................................................................7
Wireless Antenna......................................................................................8
Wall Mount Specifications........................................................................8
SETTING UP THE DISPLAY......................................................................................9
Connecting the Power Cable....................................................................10
CONNECTING THE DISPLAY...............................................................................11
Using the Micro-USB Port.......................................................................11
Connecting a Second Display ...................................................................12
Connecting to Wireless Internet .............................................................13
Connecting to the Internet via a Wired Connection .................................14
HOME SCREEN....................................................................................................15
SETTINGS....................................................................................................15
Adjusting the brightness ..........................................................................16
Changing the Display's Language ............................................................17
Changing the Display's Language ............................................................18
INSTALLING APPS ..............................................................................................19
Model: MST-23016

TABLE OF CONTENTS

Components...................................................................................9
PAGE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MST-23016 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mimo Monitors MST-23016

Summary of Contents for Mimo Monitors MST-23016

  • Page 1: Table Of Contents

    23” Shelf Edge Display User’s Manual with Android Player Model: MST-23016 Please keep this manual for future reference. TABLE OF CONTENTS PAGE SAFETY INSTRUCTIONS .……………..…………………....……....…..1 Declarations and Statements………..……..…………..………………2 WHAT’S IN THE BOX ……….........…………...…..….……….3 Package Contents..…………………....………………………………3 MOVING THE DISPLAY…………..…....……………..…………….……….4 Unpacking the Display..………..…………….....…......……4 Carrying the Display….................6...

  • Page 2: Safety Instructions

    WARNING: If using a Class 1 adapter, connect only to a grounded electrical outlet. Consult an authorized service technician if the display does not operate normally when you have followed the instructions in this manual. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 3: Declarations And Statements

    Note 2：“○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence. Note 3：The “−” indicates that the restricted substance corresponds to the exemption. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 4: What's In The Box

    The illustrations in this manual may differ from the actual product and items. Display x 6 Adapter x 6 Power Cord x 6 Micro-HDMI Cable x 6 Type-C USB Cable x 6 Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 5: Moving The Display

    Open the product box from the top side. Remove the top EPE cushion. Remove two sets of accessories from the side compartments in the top layer. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)
  • Page 6 Remove the cardboard and EPE foam base of the top layer. Repeat steps 3 to 5 for the second layer. Repeat steps 3 to 4 for the third layer. Remove the electrostatic bags covering each display. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 7: Carrying The Display

    When setting the display down, place the screen face down on a flat and stable surface covered by a protective sheet and a table cushion as shown in the illustration provided. CAUTION: Never press or place anything on the back cover. This may damage the internal parts of the display. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 8: Mounting The Display

    If the display is not mounted in such a way the display may not function properly. NOTE: Before mounting, make sure there is space to connect your devices. See “CONNECTING THE DISPLAY” on page 13. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 9: Wireless Antenna

    The back of the display is equipped with two screw-holes with a width of 190.00mm that allow for mounting. Firmly secure a mount onto the display using two M3x4mm length screws (maximum torque: 8 kgf-cm). 190.00mm Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 10: Setting Up The Display

    Connects with the Type-C power input port of a second bar-type (Power Output) display to provide power to the second display. M-HDMI OUT Connects with the Micro-HDMI input port of a second bar-type (Micro-HDMI display to duplicate the video shown on this display. Output) Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 11: Connecting The Power Cable

     Be sure use applicable AC/DC adapter: Manufacture WEIHAI Power Electronics Co., Ltd. Model: AMB-036-12 CAUTION: When disconnecting the AC power cord, be sure to first disconnect the plug from the outlet socket. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 12: Connecting The Display

    Ethernet hub via an RJ45 cable and an RJ45-to-USB adapter. NOTE: The display only supports the following video/image file formats (with their listed resolution) via the Micro-USB port:  MP4 (H.264/AVC) - 1920x165  JPG - 1920x165  BMP - 1920x165 Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 13: Connecting A Second Display

    All Apps menu. Select Settings in the All Apps screen. Select Display in the Settings menu. Select Advanced in the Display menu. Select HDMI settings in the Display menu. Enable HDMI in the Advanced menu. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 14: Connecting To Wireless Internet

    Select the SSID of the router you want to connect to. Enter the router’s password if necessary. Return to the All Apps menu. Select the Browser app in the All Apps menu and open a webpage to ensure that you have properly connected to wireless Internet. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 15: Connecting To The Internet Via A Wired Connection

    Ensure that the switch in the Ethernet menu is On. Return to the All Apps menu. Select the Browser app in the All Apps menu and open a webpage to ensure that you have properly connected to wireless Internet. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 16: Home Screen

    All Apps menu. Select Settings in the All Apps screen. From the settings you can:  Adjust the brightness of the display  Change the display’s language  Change the date and time for the display Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 17: Adjusting The Brightness

    Return to the All Apps menu. Select 2nd Display Configuration in the All Apps menu. Toggle the bar at the top of the 2nd Display Configuration menu to adjust the brightness to the level you want. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 18: Changing The Display's Language

    (so that it is listed as number 1). Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 19: Changing The Display's Language

    Disable Automatic date & time in the Date & time menu. Select Set date in the Date & time menu, and then manually set the date. Select Set time in the Date & time menu, and then manually set the time. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)

  • Page 20: Installing Apps

    Select INSTALL in the confirmation message that appears. The app will begin installing. Once the app has finished installing an App Installed message will appear. You can choose to open the app by selecting OPEN. Mimo Monitors info@mimomonitors.com 2018-0510 Sales: 1-855-YES-MIMO (937-6466)
