23" Shelf Edge Display User's Manual
Please keep this manual for future reference.
SAFETY INSTRUCTIONS....................................................................................1
Declarations and Statements................................................................2
WHAT'S IN THE BOX .......................................................................................3
Package Contents...............................................................................3
MOVING THE DISPLAY....................................................................................4
Unpacking the Display.............................................................................4
Carrying the Display....................................................................................6
Placing the Display......................................................................................6
Setting Down the Display.........................................................................6
MOUNTING THE DISPLAY...................................................................................7
Adjusting the Display...............................................................................7
Wall Mount Specifications......................................................................8
SETTING UP THE DISPLAY......................................................................................9
Connecting the Power Cable....................................................................10
CONNECTING THE DISPLAY...............................................................................11
Using the Micro-USB Port.......................................................................11
Using the Micro-HDMI Port .....................................................................22
Model: MSE-23016
TABLE OF CONTENTS
Components...................................................................................9
PAGE
Advertisement
Table of Contents
Related Manuals for Mimo Monitors MSE-23016
Summary of Contents for Mimo Monitors MSE-23016
-
Page 1: Table Of Contents
23” Shelf Edge Display User’s Manual Model: MSE-23016 Please keep this manual for future reference. TABLE OF CONTENTS PAGE SAFETY INSTRUCTIONS……………..…………………....……....…..1 Declarations and Statements………..……..…………..………………2 WHAT’S IN THE BOX ……….........…………...…..….……….3 Package Contents..…………………....………………………………3 MOVING THE DISPLAY…………..…....……………..…………….……….4 Unpacking the Display..………..…………….....…......……4 Carrying the Display….................6 Placing the Display...................…6... -
Page 2: Safety Instructions
WARNING: If using a Class 1 adapter, connect only to a grounded electrical outlet. Consult an authorized service technician if the display does not operate normally when you have followed the instructions in this manual. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) -
Page 3: Declarations And Statements
Note 2：“○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence. Note 3：The “−” indicates that the restricted substance corresponds to the exemption. Mimo Monitors | « SAFETY INSTRUCTIONS » info@mimomonitors.com... -
Page 4: What's In The Box
The illustrations in this manual may differ from the actual product and items. Display x 6 Adapter x 6 Power Cord x 6 Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) « WHAT’S IN THE BOX » |... -
Page 5: Moving The Display
Open the product box from the top side. Remove the top EPE cushion. Remove two sets of accessories from the side compartments in the top layer. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) | « MOVING THE DISPLAY »... - Page 6 Remove the cardboard and EPE foam base of the top layer. Repeat steps 3 to 5 for the second layer. Repeat steps 3 to 4 for the third layer. Remove the electrostatic bags covering each display. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) « MOVING THE DISPLAY » |...
-
Page 7: Carrying The Display
CAUTION: Never press or place anything on the back cover. This may damage the internal parts of the display. Mimo Monitors | « MOVING THE DISPLAY » info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) -
Page 8: Mounting The Display
90° NOTE: Before mounting, make sure there is space to connect your devices. See “CONNECTING THE DISPLAY” on page 13. Mimo Monitors « MOUNTING THE DISPLAY » | info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) -
Page 9: Wall Mount Specifications
The back of the display is equipped with two screw-holes with a width of 190.00mm that allow for mounting. Firmly secure a mount onto the display using two M3x4mm length screws (maximum torque: 8 kgf-cm). 190.00mm Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) | « MOUNTING THE DISPLAY »... -
Page 10: Setting Up The Display
Connects with the supplied adapter and power cord. (Power) M-HDMI Connects with devices transmitting audio/video using the HDMI (Micro-HDMI) interface. M-USB Connects with storage devices containing video and image files. (Micro-USB) Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) « SETTING UP THE DISPLAY » |... -
Page 11: Connecting The Power Cable
NOTE: Be sure use applicable AC/DC adapter: Manufacture WEIHAI Power Electronics Co., Ltd. Model: AMB-036-12. CAUTION: When disconnecting the AC power cord, be sure to first disconnect the plug from the outlet socket. Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) | « SETTING UP THE DISPLAY »... -
Page 12: Connecting The Display
NOTE: The display only supports the following video/image file formats (with their listed resolution) via the Micro-USB port: • MP4 (H.264/AVC) - 1920x1080, 1920x165 • JPG - 1920x1080, 1920x165 • BMP - 1920x1080, 1920x165 Mimo Monitors info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) « CONNECTING THE DISPLAY » |... -
Page 13: Using The Micro-Hdmi Port
NOTE: The native resolution for the display as transmitted via EDID is 1920x165. The display also supports 1920x1080 resolution but will only feature the top section (165 pixels) of the video/image. Mimo Monitors info@mimomonitors.com 2018-0510 Sales: 1-855-YES-MIMO (937-6466) Rev 1 - 78978 | « CONNECTING THE DISPLAY »...
