Summers ULTRA Operator's Manual page 23

6. DETERMINE TIP SIZE – stamped number on orifice side identifies Tips.
Part Number
8F3411X
8F3413X XR80015VS
8F3415X
8F3417X
8F3419X
8F3421X
8F3423X
8F3425X
8F3511X XR11001VS
8F3513X XR110015VS
8F3515X XR11002VS
8F3517X XR11003VS
8F3519X XR11004VS
8F3521X XR11005VS
8F3523X XR11006VS
8F3525X XR11008VS
7. DETERMINE APPLICATION RATE
A. Choose a desired ground speed within factory recommended range of 5 to 8 miles per hour (mph).
B. By knowing tip size and desired ground speed, refer to English or Metric Application Rate Chart
(shown on following pages to determine application rate (US gallons per acre or liters per hectare)
based on different operation pressures.
C. Example of how to obtain 5.0 U.S. gallons per acre application rate:
1. Determined tip size to be XR8001.
2. Choose desired ground speed to be 6 miles per hour (mph).
3. Refer to English Application Rate Chart (shown on following page) to see that XR8001 tip trav-
eling at 6 mph will deliver 5.0 U.S. gallons per acre at 40 psi operation pressure.
D. Spraying solutions other than water: All tabulations in this manual are based on spraying water
which weighs 8.34 lbs. per U.S. gallon. Conversion factors must be used when spraying solutions
which are heavier or lighter than water. To properly size nozzles for the solution to be sprayed
multiply the desired GPM or GPA of solution by the water rate conversion factor, then use the new
converted GPM or GPA rate to select the proper size nozzle.
Example: Desired application rate is 20GPA of 28%N. Determine the correct nozzle size as fol-
lows:
GPA (solution) x Conversion factor = GPA (from table)
20GPA (28%) x 1.13 = 22.6 GPA (water)
The applicator should choose a nozzle size that will supply 22.6 GPA of water at the desired pres-
sure.
WEIGHT OF
SOLUTION
7.0 LBS. PER GALLON
8.0 LBS. PER GALLON
8.34 LBS. PER GALLON
9.0 LBS. PER GALLON
10.0 LBS. PER GALLON
SECTION 2 - SPRAYER OPERATION
Tip Size TIP MATERIAL
XR8001VS
XR8002VS
XR8003VS STAINLESS
XR8004VS STEEL
XR8005VS
XR8006VS
XR8008VS
STAINLESS
STEEL
SPECIFIC
GRAVITY
.84
.96
1.00
1.08
1.20
DEGREE TIP
80°
110°
CONVERSION WEIGHT OF
FACTORS SOLUTION
.92 10.65 LBS. PER GAL.
.98 11.0 LBS. PER GAL.
1.00 12.0 LBS. PER GAL.
1.04 14.0 LBS. PER GAL.
1.10
2.9
OPTIONAL END
COLOR CODE NOZZLE SIZE
ORANGE
GREEN
YELLOW
BLUE
RED
BROWN
GRAY
WHITE
ORANGE
GREEN
YELLOW
BLUE
RED
BROWN
GRAY
WHITE
SPECIFIC CONVERSION
GRAVITY
1.28
1.32
1.44
1.68
OC04
OC06
OC08
OC12
OC12
OC16
OC16
-
OC04
OC06
OC08
OC12
OC12
OC16
OC16
-
FACTORS
1.13
1.15
1.20
1.30
