Summers ULTRA Operator's Manual page 181

Stock # Description
8G2200 JACK LEG SKID SPRAYER 83-
8G2240 SPACER BLOCK SKID KNOCKON89-
8G2280 VALVE BRCKT SKID BTTMFLL 85-
8G2281 NYLON TIE .187 X 7-1/2" BROWN
8G2282 NYLON TIE .187 X 7-1/2" RED
8G2283 NYLON TIE .187 X 7-1/2" ORANGE
8G2284 NYLON TIE .187 X 7-1/2" YELLOW
8G2285 NYLON TIE .187 X 7-1/2" GREEN
8G2286 NYLON TIE .187 X 7-1/2" BLUE
8G2380 CONTROL BOX LESS COVER TL/EEN
8G2384 COVER TIPLIFT CONTROL BOX
8G2390 MNTNG BRCKT TIPLIFT CONTRL BOX
8G2540 CORRUGATED LOOM .50" ID
8G2542 CLIP CORRUGATED LOOM
8G2544 OUTLET CORRUGATED LOOM
8G4224 SWINGARM CNTRL 1.25"SQ 83-
8G4230 TEE HANDLE 7/16"NC 83-
8G4280 END STOP TUBE ASSY 83-
8G5160 BASE CNTRL SWNGARM MIDMNT90-
8G5185 VERTICAL UPRIGHT ASSY LT 95-
8G5195 VERTICAL UPRIGHT ASSY RT 95-
8G5200 BRCKT TRNS ADJ W/JCKATTCH 83-
8G7390 BRACKET TRUCK CLEAN H20 95-
8G8000 POLY BOOM PROTECTR FOR 1"SQ-6"
8G8010 U-BOLT 3/8 X 1-5/16 X 2-1/4"SQ
8G8020 U-BOLT 3/8 X 2-9/16 X 3-1/2"SQ
8G8211 HUB HDA211 W/CUPS&ZRK 4BLT
8G8213 DUST CAP H211
8G8217 BEARING INNER & OUTER HDA211
8G8220 SEAL H211
8G8230 RACE INNER & OUTER H211 L44610
8G9220 BRACKET DIRECTO/RADAR MNT93-
8H1304 SPRING HVY 1.19"ID- 2.88" PNTD
8J5100 #6 JIC(M) X #6 JIC(M) UNION
8J5102 #6 ORB TO 3/8"FPT ADAPTR SWVL
8J5104 #4 ORB(M) X #6 JIC(M) ELBOW
8J5106 #4 HEX SOCKET ORB PLUG
8J5110 #10 JIC(M) X #10 JIC(M) UNION
8J5150 3/8" MPT X #6JIC(M)STR ADPTR
8J5152 #8 JIC(F) X #6 JIC(M) RDCR
8J5170 1/2" MPT X #10 JIC(M)STR ADPTR
8J5200 #10 JIC(F) X #6 JIC(M)HEX BUSH
8J5298 TEE #6 SWIVELNUTRUN(M+M+F-SW)
8J5300 TEE #6 JIC (MALE) 3X
8J5312 TEE #10JIC(M2X)X3/4-16ORBBRNCH
8J5500 9/16"-18 ORB X #6 JIC(M) STR
8J5510 3/4"-16 ORB X #6 JIC(M) STR
8J5520 3/4"-16 ORB X #10 JIC(M) STR
8J5522 3/4MPT X #10JIC(M) STR
8J5540 7/8"-14 ORB X #10 JIC(M) STR
8J5550 1-1/16" - 12ORBX#10JIC(M)STR
8J5600 9/16"-18 ORB X #6 JIC(F-SW)STR
8J5620 3/4"-16 ORB X #6 JIC(F-SW)STR
8J5680 3/4"-16 ORB X 3/4"-16ORB UNION
8J5682 3/4"-16ORB(2X)ADJUSTABLE UNION
8J5690 3/4-16X3/4-16 ORB M-SW90*UNION
8J5700 #6 JIC(F-SW) X #6 JIC(M)90*ADP
8J5710 #10 JIC(F-SW)X#10 JIC(M)90*ADP
Stock # Description
8J5800 3/8"FPT X #6 JIC (F-SW) STR
8J5810 1/2"FPT X #10 JIC(F-SW) STR
8J5980 9/16"-18ORB M X 3/4"-16ORB F
8J6000 9/16"-18 ORB X #6 JIC(M)90*ADP
8J6002 9/16"-18ORB X #6 JIC(M)BRNCH T
8J6004 9/16"-18ORB X #6 JIC(M)RUN TEE
8J6010 3/4"-16 ORB X #6 JIC(M)90*ADP
8J6020 3/4"-16 ORB X #10 JIC(M)90*ADP
8J6030 7/8"-14 ORB X #10 JIC(M)90*ADP
8J6060 3/4"-16ORB X #6JIC(F-SW)90*ADP
8J7000 BALL VALVE HYD 9/16"-18ORB(2X)
8J7040 THERMAL RELIEF MANIFLD 4000PSI
8J7110 CHECKVLV TNK 7/8-14ORB ML/FML
8J7116 3/4"-16 ORB(2X)1WAY 1/16"RESTR
8J7216 #6JIC(M)X6JIC(F)1/16"RSTR BLKZ
8J7250 RELIEF VLV 2250PSI 9/16"-18ORB
8K1109 SPINDLE W/H1010 15K 3.38"03-
8K1110A SPINDLE W/H1020 25K BLK 13-
8K5350 SPLITSTEELBUSH 2" X 1.5"ID- 2"
8K5400 SPLITSTEELBUSH 4 X 3.5ID- 1.5"
8K5505 U-BOLT 3/4 X 2-1/8 X 4-1/4" SQ
8K5515 U-BOLT 3/4 X 4-1/16 X 6" SQ
8K5520 U-BOLT 3/4 X 6-1/8 X 7-1/2" SQ
8K7209 HUB H1020 W/CUPS&ZERK 10BLT25K
8K7210 HUB H1010 W/CUPS&ZRK 10BLT 15K
8K7211 HUB H1010 W/CUPS&ZRK 10BLT 12K
8K7212 GASKET HUB CAP H1010
8K7213 HUB CAP H1010 DC27
8K7214 BOLT HUB CAP H1010
8K7215 STUD WHEEL 3/4-16 UNF X 2-5/8"
8K7215B STUD WHEEL 3/4-16UNF X 3.3"
8K7216 NUT 3/4"-16UNF FLANGE
8K7217 BEARING INNER 12K H1010 39585
8K7218 BEARING OUTER 12&15K H1010 460
8K7219 BEARING INNER 15K H1010 33275
8K7220 SEAL 3" ID 12K H1010 SE48
8K7221 SEAL 3.3"ID 15K H1010 SE67
8K7222 NUT 3/4"-16UNF INNER BUDD
8K7223 NUT 1-1/8"-16UNF OUTER BUDD
8K7230 RACE INNER 12K H1010 39520
8K7231 RACE INNER 15K H1010 33462
8K7232 RACE OUTER 12K&15K H1010 453A
8K7250 AXLE 12K 1010 3.0 X 12-1/8 96-
8K7251 AXLE 15K 1010 3.38"X12.13 03-
8K7252 AXLE 25K 4.5 X 12.09" 06-
8K7252A AXLE 25K 4.5 X 12.84" 13-
8K7312 GASKET HUB CAP H1020 06-
8K7313 HUB CAP HDA 1020 06-
8K7317 BEARING INNER HDA1020 25K
8K7318 BEARING OUTER HDA1020 25K
8K7320 SEAL 4.37" ID 25K H1020 06-
8K7330 RACE INNER HDA1020 25K 06-
8K7332 RACE OUTER HDA1020 25K 06-
8K8000 STL 7K2045 3/8X3.5 PNTDLGHT09-
8K8005 TUBE LGHT BRKT SHRT 1.5SQ PNTD
8K8010 TUBE LGHT BRCKT 1.5SQ PNTD 00-
8K8015 TUBE LGHTBRKT 1.5SQ STR PTD11-
8K8020 STL 12GA MNTNG BRCKT LIGHT 00-
