  • Page 1 Installer manual NIBE™ F2120 8, 12, 16, 20 Air/water heat pump IHB GB 1621-1 331385...
  • Page 3: Table Of Contents

    Filling and venting the heating medium sys- Start-up and inspection Readjusting, heating medium side Adjustment, charge flow 7 Control - Introduction General LED status Master control Control conditions Control - Heat pump EB101 8 Disturbances in comfort Troubleshooting NIBE™ F2120 Table of Contents |...
  • Page 4: Important Information

    Marking or trained users in shops, hotels, light The CE marking means that NIBE ensures that the product meets all regulations that are placed on it industry, farming and similar environ- based on relevant EU directives. The CE mark is obligat- ments.
  • Page 5 Country specific information Installer manual This installer manual must be left with the customer. NIBE™ F2120 Chapter 1 | Important information...
  • Page 6: Safety Precautions

    Do not install the outdoor unit in a location where insects Use main switch with sufficient breaking capacity. and small animals can inhabit. Chapter 1 | Important information NIBE™ F2120...
  • Page 7 - Do not use charging bottles. These types of bottles change the composition of the refrigerant, which makes the performance of the system worse. - When filling refrigerant, the refrigerant must always leave the bottle in liquid form. NIBE™ F2120 Chapter 1 | Important information...
  • Page 8 Insulation condensation water pipe, thickness (if KVR 10 is not used) NOTE Check the connections, main voltage and phase voltage before the machine is started, to prevent damage to the heat pump electronics. Chapter 1 | Important information NIBE™ F2120...
  • Page 9: Contact Information

    NIBE Energy Systems France Sarl, Zone industrielle RD 28, Rue du Pou du Ciel, 01600 Reyrieux Tel : 04 74 00 92 92 Fax : 04 74 00 42 00 E-mail: info@nibe.fr www.nibe.fr NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chesterfield S41 9QG Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: info@nibe.co.uk www.nibe.co.uk...
  • Page 10: Delivery And Handling

    Care must be exercised so that the heat pump is not ■ scratched during installation. F2120 F2120 F2120 min 300 mm 70 mm Do not place F2120 directly on the lawn or other non solid surface. Chapter 2 | Delivery and handling NIBE™ F2120...
  • Page 11 Before lifting remove the packaging and the securing strap to the pallet. Place lifting straps around each machine foot. Lifting from the pallet to the base requires four persons, one for each lifting strap. NIBE™ F2120 Chapter 2 | Delivery and handling...
  • Page 12: Condensation

    The condensation water is lead to an indoor drain (subject to local rules and regulations). Route the pipe downward from F2120. The condensation water pipe must have a water seal to prevent air circulation in the pipe. Chapter 2 | Delivery and handling NIBE™ F2120...
  • Page 13 The condensation water pipe must have a water seal to prevent air circulation in the pipe. Caution If none of the recommended alternatives is used good lead off of condensation water must be assured. NIBE™ F2120 Chapter 2 | Delivery and handling...
  • Page 14: Installation Area

    However, free space in front must be Fritt utrymme framför 1000 mm for future servicing dock 1000 mm för ev. framtida service Supplied components Enclosed components for F2120 2 x flexible hoses (R32) with 4 seals Particle filterR32 Chapter 2 | Delivery and handling NIBE™ F2120...
  • Page 15: Removing The Side Cover

    Removing the side cover NIBE™ F2120 Chapter 2 | Delivery and handling...
  • Page 16: The Heat Pump Design

    3 The heat pump design General F2120 (1x230V) BT84 BT12 QN34 BT81 BP11 L E K QA40 GQ10 BT14 EB10 XL20 BT17 XL21 BT15 Chapter 3 | The heat pump design NIBE™ F2120...
  • Page 17 F2120 (3x400V) BT84 BT12 QN34 BT81 BP11 L E K QA40 GQ10 BT14 EB10 XL20 BT17 XL21 BT15 NIBE™ F2120 Chapter 3 | The heat pump design...
  • Page 18 BT28 D at a Se ri e. n r. BT16 XL40 Art.nr. 711453 Chapter 3 | The heat pump design NIBE™ F2120...
  • Page 19 Harmonic filter (3x400V) Choke (1x230V) EMC filter (3x400V) Terminal block (1x230V) Cooling components Evaporator Condenser GQ10 Compressor Particle filter Drying filter Expansion valve Bypass valve 4-way valve QN34 Expansion valve, subcooling Non-return valve NIBE™ F2120 Chapter 3 | The heat pump design...
  • Page 20: Distribution Box

    Terminal block, subcooling QN34 Fuse, operating 230V~ Fuse, operating 230V~ Fuse for external heating cable KVR Fuse, fan Fuse, fan Miniature circuit breaker (Replaced with auto- matic protection (FB1) when installing accessory KVR 10.) Chapter 3 | The heat pump design NIBE™ F2120...
  • Page 21: Pipe Connections

    F2120 can be connected to the heating system ac- ■ cording to one of the system solutions that can be downloaded from the website www.nibe.eu. The heat pump must be vented by the upper connec- ■ tion (XL1) using the venting nipple on the enclosed flexible hose.
  • Page 22: Installing Flex Hoses

    Installing flex hoses Da ta Se rie .nr . 711453 Art.nr. Chapter 4 | Pipe connections NIBE™ F2120...
  • Page 23: Electrical Connections

    If the control is to be supplied separately from other ■ components in the heat pump (e.g. for tariff connec- tion), a separate operating cable must be connected to terminal block (X5). NIBE™ F2120 Chapter 5 | Electrical connections...
  • Page 24: Accessibility, Electrical Connection

    Accessibility, electrical connection Removing the side cover Unscrew the screws and lift off the cover. Chapter 5 | Electrical connections NIBE™ F2120...
  • Page 25: Configuration Using Dip Switch

    Permits cool- DIP S2 position Setting Default setting Switch S3 is the reset button that restarts control. Caution DIP S1 position 4 must be changed to ON in order to run cooling NIBE™ F2120 Chapter 5 | Electrical connections...
  • Page 26: Connections

    At installation, install the screwed connection on the rear of the heat pump. The part of the screwed joint that tensions the cable must be tightened to a tighten- ing torque above 3.5Nm. Chapter 5 | Electrical connections NIBE™ F2120...
  • Page 27: Connecting External Control Voltage

    When connecting external control voltage, remove the suitable one. bridges from terminal block X5 (see image). Length Total Fuse (F3) NIBE Part no. output T100mA/250V 718085 T250mA/250V 518900* T500mA/250V 718086 * Fitted at the factory.
  • Page 28 1,600 mm. EB14 Da ta Se rie .n r. Art.nr. 711453 L E K Da ta Se rie .n r. Art.nr. 711453 EB14 Chapter 5 | Electrical connections NIBE™ F2120...
  • Page 29: Optional Connections

    Optional connections Communication F2120 communicates with NIBE indoor modules/con- trol modules by connecting a three-core, screened cable to terminal block X22:1–4, as shown in the following image. For cascade connection, join terminal block X23 with F2040 X22 to the next heat pump.
  • Page 30: Connecting Accessories

    -X10 SMO 40 AA5-X4 For connection of indoor module/control module, see relevant manual on www.nibe.eu. Connecting accessories Instructions for connecting accessories are in the install- ation instructions provided for the respective accessory. See page 39 for the list of the accessories that can be used with F2120.
  • Page 31: Commissioning And Adjusting

    When the system is stable (correct pressure and all air elimin- ated) the automatic heating control system can be set as required. NIBE™ F2120 Chapter 6 | Commissioning and adjusting...
  • Page 32: Adjustment, Charge Flow

    For correct function of the heat pump over the entire year, the charge flow must be correctly adjusted. If an NIBE indoor module VVM or accessory controlled charge pump is used for the control module SMO, the control tries to maintain an optimal flow across the heat pump.
  • Page 33: Control - Introduction

    Master control perature, connection of the compressor heater, and protective functions during operation. To control F2120, a NIBE indoor module/control mod- Temperatures, number of starts and run time, are read ule is required, which calls upon F2120 according to off in the indoor module/control module.
  • Page 34: Control Conditions

    (at cold outdoor air). 3. When the temperature on the return line sensor channel BT3 falls below 10 °C. Chapter 7 | Control - Introduction NIBE™ F2120...
  • Page 35: Control - Heat Pump Eb101

    This can be activated if blockFreq 2 ice/snow accumulates on the fan, grille or fan cone. Select a frequency range within which the heat pump may work here. NIBE™ F2120 Chapter 7 | Control - Introduction...
  • Page 36: Disturbances In Comfort

    See the manual for the indoor module or control – module. Clogged particle filter. ■ Check whether alarm high condenser out (162) is – in the alarm log. Check and clean the particle filter. Chapter 8 | Disturbances in comfort NIBE™ F2120...
  • Page 37 2.083 6.514 1.916 5.306 1.752 4.348 1.587 3.583 1.426 2.968 1.278 2.467 1.136 2.068 1.007 1.739 0.891 1.469 0.785 1.246 0.691 BP11 1.061 0.607 BP11 0.908 0.533 BP11 0.779 0.469 0.672 0.414 NIBE™ F2120 Chapter 8 | Disturbances in comfort...
  • Page 38 1.518 1.22 4.69 2.50 1.274 1.07 4.10 2.33 1.075 0.93 0.911 0.81 0.775 0.71 0.662 0.62 0.568 0.54 0.490 0.47 0.4233 0.41 0.367 0.36 0.320 0.32 0.280 0.28 0.245 0.25 0.216 0.22 Chapter 8 | Disturbances in comfort NIBE™ F2120...
  • Page 39: Accessories

    Stainless Steel, 1 x 230 V SMO 40 With T&P valve Control module Part no. 069 112 Part no. 067 225 VVM 325 Copper, 3 x 400 V Part no. 069 154 VVM 500 Part no. 069 400 NIBE™ F2120 Chapter 9 | Accessories...
  • Page 40: 10 Technical Data

    10 Technical data Dimensions F2120-8 F2120 Ø52 1055 1130 F2120-12, -16, -20 F2120 Ø52 1205 1280 Chapter 10 | Technical data NIBE™ F2120...
  • Page 41: Sound Pressure Levels

    (nominal) Sound pressure level (L ) at 2 m* dB(A) Sound pressure level (L ) at 6 m* dB(A) 29.5 29.5 29.5 Sound pressure level (L ) at 10 m* dB(A) *Free space. NIBE™ F2120 Chapter 10 | Technical data...
  • Page 42: Technical Specifications

    Connection heating medium F2120 G1 1/4" external thread (Ø35 mm) Connection heating medium flex pipe G1 1/4" external thread (Ø35 mm) Dimensions and weight Width 1,130 1,280 Depth Height with stand 1,070 1,165 Weight (excl. packaging) Chapter 10 | Technical data NIBE™ F2120...
  • Page 43 F2120 – 1x230V Miscellaneous Enclosure class IP24 Colour grey Part No. 064 134 064 136 NIBE™ F2120 Chapter 10 | Technical data...
  • Page 44 Connection heating medium F2120 G1 1/4" external thread (Ø35 mm) Connection heating medium flex pipe G1 1/4" external thread (Ø35 mm) Dimensions and weight Width 1,130 1,280 Depth Height with stand 1,070 1,165 Weight (excl. packaging) Chapter 10 | Technical data NIBE™ F2120...
  • Page 45 SCOP 55 Warm climate 4.48 Power statements including defrosting according to EN14511 at heating medium supply corresponding to DT=5 K at 7 / 45. Nominal flow corresponds to DT=10 K at 7 / 45. NIBE™ F2120 Chapter 10 | Technical data...
  • Page 46: Working Area

    Working area Arbetsområde F2120-8 / F2120-12 värme Working rangeF2120-8 / F2120-12 heating Supply temperature [°C] Outdoor temperature [°C] Omgivningstemperatur [°C] Framledningstemperatur Returledningstemperatur Supply temperature Return temp Arbetsområde F2120-16 / F2120-20 värme Working rangeF2120-16 / F2120-20 heating Supply temperature [°C] Outdoor temperature [°C] Omgivningstemperatur [°C]...
  • Page 47 Supply temperature [°C] Omgivningstemperatur [°C] Outdoor temperature [°C] Framledningstemperatur Returledningstemperatur Supply temperature Return temp During shorter time it is allowed to have lower working temperatures on the water side, e.g. during start up. NIBE™ F2120 Chapter 10 | Technical data...
  • Page 48: Heating

    °C supply temperature 5,00 4,50 6,00 Outdoor temperature (°C) Utomhustemperatur (°C) 5,00 F2100-12 COP F2120-12 COP 4,00 °C supply temperature 3,00 2,00 1,00 0,00 Outdoor temperature (°C) Utomhustemperatur (°C) Utomhustemperatur (°C) Outdoor temperature (°C) Chapter 10 | Technical data NIBE™ F2120...
  • Page 49 6,00 4,00 Utomhustemperatur °C Outdoor temperature (°C) F2120-20 COP F2120-20 COP 55 °C 45 °C 35 °C framledningstemperatur °C supply temperature 6,00 5,00 4,00 3,00 2,00 1,00 0,00 Outdoor temperature (°C) Utomhustemperatur °C NIBE™ F2120 Chapter 10 | Technical data...
  • Page 50: Cooling

    Outdoor temperature (°C) Utomhustemperatur (°C) F2120-16 F2100-16 kW Max kylningskapacitet F2120-16 Max. cooling capacity °C supply temperature Kylningskapacitet (kW) Cooling capacity (kW) 10,00 9,00 8,00 7,00 6,00 5,00 4,00 3,00 Outdoor temperature (°C) Utomhustemperatur (°C) Chapter 10 | Technical data NIBE™ F2120...
  • Page 51: Energy Labelling

    The reported efficiency of the package also takes the controller into account. If an external supplementary boiler or solar heating is added to the package, the overall efficiency of the package should be recalculated. NIBE™ F2120 Chapter 10 | Technical data...
  • Page 52 For heat pump combination heater Declared load profile for water heating Water heating energy efficiency ƞ Daily energy consumption 7.56 Daily fuel consumption elec fuel Annual energy consumption 1,661 Annual fuel consumption Chapter 10 | Technical data NIBE™ F2120...
  • Page 53 For heat pump combination heater Declared load profile for water heating Water heating energy efficiency ƞ Daily energy consumption 9.54 Daily fuel consumption elec fuel Annual energy consumption 2,096 Annual fuel consumption NIBE™ F2120 Chapter 10 | Technical data...
  • Page 54 For heat pump combination heater Declared load profile for water heating Water heating energy efficiency ƞ Daily energy consumption 9.54 Daily fuel consumption elec fuel Annual energy consumption 2,096 Annual fuel consumption Chapter 10 | Technical data NIBE™ F2120...
  • Page 55: Electrical Circuit Diagram

    Electrical circuit diagram 1x230V NIBE™ F2120 Chapter 10 | Technical data...
  • Page 56 Chapter 10 | Technical data NIBE™ F2120...
  • Page 57 NIBE™ F2120 Chapter 10 | Technical data...
  • Page 58 Chapter 10 | Technical data NIBE™ F2120...
  • Page 59 3x400V NIBE™ F2120 Chapter 10 | Technical data...
  • Page 60 Chapter 10 | Technical data NIBE™ F2120...
  • Page 61 NIBE™ F2120 Chapter 10 | Technical data...
  • Page 62 Chapter 10 | Technical data NIBE™ F2120...
  • Page 63: Index

    Energy labelling, 51 Transport and storage, 10 Data for energy efficiency of the package, 51 Troubleshooting, 36 Information sheet, 51 Sensor placement, 37 Technical documentation, 52 Filling and venting the heating medium system, 31 NIBE™ F2120 Chapter 11 | Item register...
  • Page 68 WS name: Eva-Lena WS version: a1 (working edition) Publish date: 2016-05-26 08:12 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 331385...
