Alarm
Line Power Plugged In
Line Power Unplugged
External DC Power Supply
voltage out of range
Battery Voltage too low for
device to operate (E04)
Oxygen level above the high
oxygen alarm setting
Oxygen level below the low
oxygen alarm setting
Oxygen level below the low
oxygen alarm setting and
lower than 18%

3.4 Backlight Operation

To turn on the backlighting:
1. When the unit is on, pressing the Backlight
on for 30 seconds. Additional presses will turn off the backlighting.
2. If the device is being used in a dark location, press any key to activate the back light.
CAUTION: Excessive use of the backlight can reduce the life of the batteries.
!

3.5 Sleep Mode Operation

To use the sleep mode function:
1. Remove the batteries from the unit.
2. Locate the sleep mode switch in the battery compartment and set to the ON position.
3. Replace the batteries in the unit.
The unit will now perform a normal boot-up operation with sleep mode
enabled. With sleep mode enabled the unit will function with all the same
parameters as outlined above with one new feature. While in the ON mode, the
unit will time-out after 90 seconds to a battery saving condition. This condition
will be indicated by a crescent moon on the display. While in this condition
any key that is pressed will return the unit to the ON mode and reset the 90
second time-out counter. In sleep mode, the device will continue to monitor
the oxygen level and will activate the alarm if an alarm condition occurs.

3.6 External Power Supply Operation

To extend the life of the batteries a Maxtec approved external power supply
can be purchased. Once connected to the unit, total power is supplied by the
external power supply. The batteries are still required to be in the unit and will
provide emergency power in the event main AC power is lost.
10
Low Alarm
Alarm Priority LED
(add symbol)
Off
Informational
Single Yellow
Informational
Pulse
Informational
Solid Yellow
Pulsing Yellow
Medium
Off
Medium
Pulsing Yellow
Medium
Pulsing Red
High
866.4.Maxtec www.maxtec.com
High Alarm
LED
Audible Alarm
(add symbol)
Off
2 Pulses
Single Yellow
2 Pulses
Pulse
Solid Yellow 2 Pulses
Pulsing Yellow
3 Pulses
Pulsing Yellow
3 Pulses
Off 3 Pulses
Off
5+5 Pulses
key will turn the backlighting
Audible Alarm
Repeat
No Repeat
No Repeat
Every 15 Sec.
Every 25 Sec.
Every 25 Sec.
Every 25 Sec.
Every 15 Sec.
