8 High Alarm Indicator -
the "HIGH" icon on the LCD readout. The indicated value represents the oxygen
percentage at which the high alarm will be activated.
9 Calibration Reminder -
of the display. This symbol will be lighted after one week has elapsed from the
previous calibration.
10 Low Alarm Indicator -
the "LOW" icon on the LCD readout. The indicated value represents the oxygen
percentage at which the low alarm will be activated.
11 Up (Alarm High) -
The device must be in the unlocked state for the key to operate. See section 3.1.2 for
instructions on setting the high FiO 2 alarm limit.
Alarm Silence Indicator -
12
deactivate the audio alarm for 2 minutes.
13 ON/OFF Key -
OFF, the button must be held while a rapid 3-2-1 countdown takes place to prevent
accidental power-off.
14 Calibration Key -
un-locked state for the key to operate. See section 2.2.2 for instructions on calibrating.
Down (Alarm Low) -
15
device must be in the unlocked state for the key to operate. See section 3.1.1 for
instructions on setting the low FiO 2 alarm limit.
16
Un-lock Key -
17 Sensor with Diverter - The sensor (with diverter) is designed to fit industry
standard, 15mm I.D. "T" adapters.
Coiled Cable - The coiled cable allows the sensor to be positioned up to 8 feet from
18
the side of the unit.
19 Backlight -
See section 3.4 for more information on backlighting operation.
20 Smart Alarm - The smart alarm key is used to help set the High-Low Alarm window
quickly. See section 3.1.3 for instructions on using the smart alarm setting.
21 Sleep Mode Indicator -
consumption. See section 3.5 Sleep Mode Operation.
22 External Supply Port - The port provides connection for the external power supply.
See section 3.6 for more information on the power adapter.
23 Locking Shroud - Threaded coupler that locks cable to sensor and monitor.
The high alarm setting is displayed at all times just below
The calibration reminder symbol is located at the bottom
The low alarm setting is displayed at all times just below
The up key is used in setting the high FiO 2 alarm limit.
In an alarm condition, pressing the SILENT key
This key is used to turn the device on or off. To turn the device
This key is used to calibrate the device. The device must be in the
CAL
The down key is used in setting the low FiO 2 alarm limit. The
The un-lock key is used to unlock and lock the instrument.
The backlight key will manually activate the backlight for 30 seconds.
The sleep mode Indicator is used to help with battery
