3.3.2 Removing and reinstalling cutting blade

With the milling head exposed it is possible to remove the cutting blades
1. Use supplied Torx T20 key to remove the set screw and remove the cutting blade from the
milling head for the outer blades first.
2. With the outer blades removed, space is created to do the same for the inner blades
3. Clean the cutting blade sockets. This serves multiple purposes:
a. When repositioning or replacing the cutting blades it should be prevented that dirt
gets in the way of proper installation
b. A clean milling head increases the life of the cutting blades
4. Reposition or replace the cutting blades as desired in exact reverse order. The set screws
should not be overtightened. Make sure to remove all tools
WARNING
- Shortly after operating the machine, the milling head and cutting plates can be hot
- The cutting plates are sharp
- Wear appropriate hand protection
- Be careful not to damage the milling head and cutting plates
[image 2-2]
