Summary of Contents for Euroboor ERM.100/3
- Page 1 User manual – version 1.0.4 EN Sharpening machine ERM.100/3 Serial no.: _______________________ Date of purchase: _______________________...
-
Page 2: Table Of Contents
Table of content Product description 1.1 Intended use 1.2 Function description 1.3 Technical data Safety instructions 2.1 Care obligation of customer 2.2 Explanation of the used safety signs 2.3 Basic safety measures 2.4 Operating staff requirements 2.5 Special types of dangers Installation 3.1 Environmental preconditions for installing the machine 3.2 Remove the transportation locking screws... -
Page 3: Product Description
1. Product description 1.1 Intended use The Euroboor sharpening machine ERM.100/3 is exclusively intended for grinding annular cutters. The machine is not intended for any type of use other than the one specified here, and any such use will be seen as improper. Safe operation of the machine cannot be guaranteed if the sharpening machine is not used properly. -
Page 4: Safety Instructions
2. Safety instructions 2.1 Care obligation of customer The sharpening machine ERM.100/3 was designed and produced after giving due consideration to danger analysis and after careful analysis of appropriate harmonized standards, as well as the further technical specifications. It conforms to the status of the latest technology and guarantees maximum possible safety. -
Page 5: Basic Safety Measures
Otherwise, the protection measures are therefore necessary. protection should always be there on the machine. The ERM.100/3 has a laser beam generating device. Eyes should never be exposed to the laser rays, as they may be damaged seriously. -
Page 6: Installation
3. Installation 3.1 Environmental preconditions for installing the machine Use the sharpening machine only in dry rooms; Ambient temperature should be between 5 C and 50 C (4 F - 122 Humidity should be lower 90%, no condensation allowed; The sharpening machine is a table top machine; Please ensure that the machine stands stable on a workbench;... -
Page 7: Start Up
4. Start up The following points must be observed and followed fully during start up, to avoid damage to the machine and potentially fatal physical injuries to the human body: Before undertaking the first start up, please check that all auxiliary tools and external parts have been removed from the machine;... -
Page 8: Operation
5. Operation 5.1. Description of the operating elements Photo 2 Motor Grinding head support Motor feed Annular cutter holder Laser source Section disk Switch on/off Guidance carriage Grinding disk protection fastening Philips-head screw Grinding disk protection Stop rail Laser guidance rod Quick adjusting angle Motor angle Fine tuner... -
Page 9: Adjusting And Installing The Machine
2.5) (photo 3). The sharpening machine have three index plates with five different grooves (number of teeth 6, 7, 8, 9 and 10). This machine is suitable for Euroboor HSS annular cutters with a maximum depth of 55 mm and a diameter of 44 mm. -
Page 10: Replacing The Index Plate
1) Set the cutter holder at 90 degrees; Photo 6 2) Place the Euroboor HSS annular cutter in the cutter holder. Don’t tight the Hex screw yet. It is important to hang the Hex screw on the round side of the cutter shank (photo 6);... -
Page 11: Operating The Machine
5.3 Operating the machine Use eye protection Always wear protective glasses while working with the Euroboor sharpening machine Annular cutters come in different variations. The variations with matching grinding order are: 1) Only V-shaped teeth a. - Page 12 5° 14° * Following instructions are specified as base guideline for standard Euroboor HSS annular cutters. Check always the measurements and angles, and fine-tune when necessary. For alternative cutters, use manufacturer provided specifications or revert to the settings provided on this page.
-
Page 13: Grinding Stretched Surfaces
5.3.2 Grinding stretched surfaces First is the grinding surface of the flat teeth. Not the market one, two teeth further. Set the column scale (photo 9) to °5. Set the cutter holder scale (photo 10) to °14. Every time make two clicks further, for the next tooth to grind. -
Page 14: Replacing The Grinding Disk
3) Move the annular cutter along the grinding disk in stationary condition until the stretched surface touches the diamond disk. Set the lateral stop and the fine tuner in such a way that the stretched surface can be ground. 4) Now grind the stretched surface set by you. Feed through the fine tuner should be low, and it should be uniform for all the stretched surfaces. - Page 15 Photo 12 4) Assemble the appropriate grinding disk on the motor shaft. Make sure the grinding wheel can rotate freely without touching any of the machine parts; 5) Fasten the retaining bolt; 6) Reassemble the grinding disk cover on the machine.
-
Page 16: Maintenance
Photo 13 6.2 Repairs For service and repair on assemblies like the grinding head or the guide carriage seek the help of a specialized Euroboor repair point, to make sure the values and settings are maintained or corrected. -
Page 17: Accessories
7. Accessories ERM3.0001 CBN Grinding wheel ERM3.0002 SDC Grinding wheel ERM3.0003 Cutter holder 31,75 mm (1 ¼”) Weldon ERM3.0004 Lock wrench M8x15 ERM3.0005 Head support wrench M8x30 ERM3.0006 Laser beam generator ERM3.0007 Head support wrench M8x75 ERM3.0008 Index plate 6/7 ERM3.0009 Index plate 8/10 ERM3.0010... -
Page 18: Warranty
8. Warranty Euroboor warranty on ERM.100/3 covers material defects and manufacturing mistakes. Wear and tear parts conditioned by operation, lack of maintenance, improper use of the machine and damages caused by the use of force are excluded from warranty. For additional details contact your point of sales.
