Euroboor B45S User Manual

Beveling machine
Hide thumbs Also See for B45S:
Table of Contents

Advertisement

Quick Links

Download this manual
User manual
11-2019
Beveling machine
B45S
B45S
Serial number:
Date of purchase:
[ only when registered you benefit from extended warranty ]
/
Don't forget to register your machine at:
www.euroboor.com/register
/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B45S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Euroboor B45S

Summary of Contents for Euroboor B45S

  • Page 1 User manual 11-2019 Beveling machine B45S B45S Serial number: Date of purchase: Don’t forget to register your machine at: www.euroboor.com/register [ only when registered you benefit from extended warranty ]...
  • Page 2 Congratulations on purchasing this premium beveling machine. At Euroboor we strive to exceed our customers’ expectations by developing and providing premium and innovative portable drilling, beveling and cutting solutions. We believe that a professional like you must be able to rely on a professional supplier.

  • Page 3: Table Of Contents

    Table of contents 1. Safety ..........................4 1.1. General safety instructrions ...................... 4 1.2. Specificl safety information ....................... 7 2. Description ........................9 2.1. Intented use ..........................9 2.2. Description and features ......................10 2.3. Case content ..........................11 2.4. Technical data .......................... 11 2.5.

  • Page 4: Safety

    1. Safety 1.1 General safety instructions Do not use this beveling machine before you have thoroughly read and completely understood this manual, specifically the “General safety instructions” and ‘’Specific safety information’’ , including the figures, specifications, safety regulations and the signs indicating DANGER, WARNING and CAUTION.
  • Page 5 If you detect damage have the machine serviced before use. Many accidents are caused by poorly maintained tools. 7. Only use accessories that are recommended by Euroboor for your machine model. Accessories that are suitable for one machine may become hazardous when used on another...
  • Page 6 SERVICE • Tool service must be performed only by qualified repair personnel. Service or maintenance performed by unqualified personnel could result in a risk of injury. • When servicing a tool, use only identical replacement parts. Follow instructions in the maintenance section of this manual.

  • Page 7: Specificl Safety Information

    1.2 Specific safety information WARNING: Electrical voltage! Risk of fatal injury due to electrical shock. • Grounded tools must be plugged into an outlet properly installed and grounded in accordance with all codes and ordinances. Never remove the grounding prong or modify the plug in any way.
  • Page 8 WARNING: Never bevel materials which contain asbestos • Only use recommended Euroboor cutting plates, rated at the machine’s maximum cutting rate or higher. • Do not use dull or damaged cutting plates to prevent excessive friction and load, and thus to prevent damage to and failure of the beveling machine.

  • Page 9: Description

    2. Description 2.1 Intended use This beveling machine is an electrically driven portable machine for machining workpieces in steel, chrome steel alloys, aluminium, aluminium alloys, brass and plastic. The machine is designed exclusively for adding bevelled edges, rounding off edges, removing burrs and removing sharp corners on workpieces.

  • Page 10: Description And Features

    2.2 Description and features [image 1-1] Main handle 5. Gear casing 9. Clamping ring 13. Lock pin Auxiliary front handle 6. Power cord 10. Milling head 14. Speed adjustment wheel Motor housing 7. Support deck 11. Impeller 15. Carbon brush holder Motor cover 8.

  • Page 11: Case Content

    2.3 Case content 1 x B45S Beveling machine, including 45° milling head with cutting plates 1 x user manual 1 x auxiliary front handle 1 x spanner 22 mm 1 x C-spanner 1 x L-type torx wrench 2.4 Technical data...
  • Page 12 There is the need to identify safety measures to protect the user that are bases on an estimation of exposure in the actual conditions of use (taking into account all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time).

  • Page 13: Symbols

    2.6 Symbols Symbol Term, meaning Explanation Be absolutely sure to read the documentation in Read documentation this user manual and specifically the “General safety instructions” and ‘’Specific safety information’’. Wear ear protection Use ear protection during operation. Wear eye protection Use eye protection during operation.

  • Page 14: Environmental

    2.7 Environmental Separate collection. This product must not be disposed of with normal household waste. Separate collection of used products and packaging allows materials to be recycled and used again. Re-use of recycled materials helps prevent environmental pollution and reduces the demand for raw materials.

  • Page 15: Preparation & Adjustment

    3. Preparation & adjustment 3.1 Assembly WARNING: To reduce the risk of injury, turn machine off and disconnect from power source before installing and removing accessories, before adjusting or changing set- ups or when making repairs. An accidental start-up can cause injury. The machine comes fully assembled.
  • Page 16 Setting bevel depth 1. Loosen the clamping ring lever. 2. Rotate the entire support deck assembly, use the dial ring as indication for the depth adjustment. Each complete rotation corresponds to a bevel depth of 1.5 mm (1/16"), this is indicated on the scale.

  • Page 17: Prior To Use

    Do not use this tool continuously for a period over 30 minutes. Electrical safety Always check that the power supply corresponds to the voltage on the rating plate. If the supply cord is damaged, it must be replaced by a specially prepared cord available at Euroboor or your Euroboor dealer.

  • Page 18: Using The Machine

    4. Using the machine WARNING: Always observe the safety instructions and applicable regulations. WARNING: To reduce the risk of serious personal injury, turn the machine off and disconnect the machine from power source before making any adjustments or removing/installing attachments or accessories. 4.1 Starting and stopping WARNING: Make sure the power circuit voltage is the same as shown on the specification plate on the machine.
  • Page 19 Controlling running speed This machine is equipped with variable speed control. The speed adjustment wheel can be rolled down to increase the machine speed and up to decrease the machine speed. Switching off If the lock pin is not engaged, release the On/Off trigger switch. If the lock pin is engaged, squeeze and release the On/Off trigger switch.

  • Page 20: Maintenance

    5. Maintenance Your Euroboor beveling machine has been designed to operate over a long period of time. Continuous satisfactory operation depends upon proper tool care and regular cleaning. CAUTION: To reduce the risk of injury, turn the machine off and disconnect machine from power source before installing and removing accessories, before adjusting or changing set- ups or when making repairs.
  • Page 21 For every type of milling head the replacement procedure is the same. 1. Loosen the clamping ring lever. 2. Rotate the entire support deck assembly until it comes off the machine. 3. Use the supplied spanner 22 mm to hold the spindle in place. 4.
  • Page 22 Always replace the 3 cutting plates at the same time, using the same brand and type for all 3 pieces. Once all 3 sides of the cutting plates are used, they need to be replaced. Use official Euroboor cutting plates to ensure the same quality and endurance.
  • Page 23 Replacing the impeller The impeller contains 2 bearings which are subject to regular wear. A worn-out impeller results in a roughly operating machine and an uneven bevel. It can be replaced as follows: Locking nut Impeller [image 4-3] 1. Remove the milling head as described in paragraph: Changing or replacing the milling head. 2.
  • Page 24 4. Place the new carbon brushes in the destined slots, ensuring they align properly and slide freely. 5. Place back the top cover and screw in all four screws. WARNING: Always replace carbon brushes as a pair. Always use official Euroboor carbon brushes which can be ordered from your Euroboor reseller.

  • Page 25: Exploded View & Spare Part List

    6. Exploded view & spare part list 6.1 Exploded view...

  • Page 26: Spare Part List

    6.2 Spare part list Part Item number Part description B45S.0003 Screw B45S.0004 Flat B45S.0008 Connection sleeve B45S.0016 Butterfly bolt B45S.0006 O ring B45S.0010 Dial plate B45S.0136 Set screws B45S.0001 Locknut B45S.0002 Guide wheel B45S.0126 Iron seal bearing B45S.0017 Cutter screw B45S.0018...
  • Page 27 040.0161 Needle bearing B45S.0236X Gear box cover 050.0064 Skeleton oil seal 050.0070 Non-contact bearings 032.0166 Hole ring B45S.0033 Armature set B45S.0032 Rotor 032.0126 Bearing 050.0261 Dust cover 0024 Screw B45S.0151 Stator 050.0181A O ring 050.1009CK Housing assembly 050.0142 Housing 050.0371C Carbon brush 050.0371D...
  • Page 28 B45S.0012 Screw B45S.0030 Wrench B45S.0029 Cutter wrench Single open-end B45S.0028 wrench B45S.0106X PP box 055.0022A Screw...

  • Page 29: Warranty And Service

    Service To maximize the lifetime of your Euroboor bevelling machine always use service and parts from an official Euroboor distribution channel. Whenever in need of such, always contact original point of sales or if no longer existent the distributor of Euroboor products in your country.
