Aethlabs microAeth MA Series Operating Manual page 35

Setting / Status Format
Datum Size Whole number
Tape At End Whole number
Tape Error Whole number
Tape Position Whole number
Milliseconds
Tape Sample Time
(Whole number)
Door State Whole number
Battery Perc Whole number
Voltage
Battery Mean (Whole number with
'V')
Current
Current (Whole number with
'mA')
Degrees celsius
Baro Temperature
(Decimal number)
Pascals
Baro Pressure
(Decimal number)
Alt Resets Whole number
Percent
Humidity
(Decimal number)
Degrees celsius
Temperature
(Decimal number)
X <x.xxx>
Acceleration Y <y.yyy>
Z <z.zzz)
Satellites Whole number
Degrees
Latitude
(ddmm.mmmmm)
Degrees
Longitude
(dddmm.mmmmm)
Kilometers per hour
Speed
(Decimal number)
Year, month, day,
hours, minutes,
RTC Time
seconds (yyyy/MM/dd
hh:mm:ss)
Time Source <GPS or Manual>
Year, month, day,
hours, minutes,
GPS Time
seconds (yyyy/MM/dd
hh:mm:ss)
<OK or Not OK or
WiFi
Sleeping>
68 microAeth MA Series MA200, MA300, MA350 Operating Manual
®
Example Description
372 Length of each data line.
0 Tape is a end.
0 Tape error.
Value of tape position counter. Increments by
1 after each tape advance. Counter is reset
1 when 'Release Tape' is used to release the tape
cartridge no matter the position of the newly
inserted tape cartridge.
Length of time of sampling at current filter tape
0
spot location.
1 Not available in current firmware.
100 Percent of instrument internal battery remaining.
4.20V Value of current voltage of battery.
0mA Not available in current firmware.
Measured temperature inside instrument case in
19.37
Celsius.
Measured pressure inside instrument case in
101512.00
pascals.
1 Not available in current firmware
Measured relative humidity of instrument sampling
0.00
stream in percent.
Measured temperature of instrument sampling
0.00
stream in degrees celsius.
X 5.466
Measured instantaneous acceleration in the
Y -18.466
x-axis, y-axis, and z-axis.
Z -277.333
Number of satellites that are visible to the
0
instrument's internal GPS receiver.
Measured latitude or relative angular distance
37.74619191 north or south on Earth's surface in degrees from
the equator.
Measured longitude or relative angular distance
-122.42032557 east or west on Earth's surface in degrees from
the prime meridian.
Measured speed using GPS in kilometers per
0.0000 hour. GPS is based on GPS lat and long, which
are required for GPS speed calculation.
18/11/21 Date and time of instrument's internal clock in
01:17:29 Coordinated Universal Time (UTC).
GPS Time source is GPS or manual.
18/11/21 Date and time provided by GPS in Coordinated
01:17:29 Universal Time (UTC).
OK Not available in current firmware.
Setting / Status
Bluetooth
AethLabs AethLabs
Format Example Description
<OK or Not OK or Not OK or
Not available in current firmware.
Sleeping> Sleeping
microAeth MA Series MA200, MA300, MA350 Operating Manual
®
69
