Aethlabs microAeth MA Series Operating Manual page 31

Verbose Structure Details
Header Units / Format Example Data
Accel Y Integer -8
Accel Z Integer -255
Tape position Whole number 1
Milliliters per minute
Flow setpoint 100
(Whole number)
Flow total Milliliters per minute
100.10
(Decimal number)
Milliliters per minute
Flow1 60.23
(Decimal number)
Milliliters per minute
Flow2 39.87
(Decimal number)
Degrees celsius
Sample temp 26.6705474853515
(Decimal number)
Percent
Sample RH 22.6140441894531
(Decimal number)
Sample Degrees celsius
10.3270139694213
dewpoint (Decimal number)
Pascal
Int pressure 100692
(Natural number)
Degrees celsius
Int temp 35.375
(Decimal number)
<SS or DS>-XX-X-
Optical config DS-UV-B-G-R-IR
X-X-XX
Counts
UV Sen1 710434
(Whole number)
Counts
UV Sen2 724526
(Whole number)
Counts
UV Ref 907699
(Whole number)
Attenuation units
UV ATN1 20.031862
(Decimal number)
Attenuation units
UV ATN2 12.559727
(Decimal number)
60 microAeth MA Series MA200, MA300, MA350 Operating Manual
®
Description
Measured instantaneous acceleration in the y-axis.
Measured instantaneous acceleration in the z-axis.
Value of tape position counter. Increments by 1 after
each tape advance. Counter is reset when 'Release
Tape' is used to release the tape cartridge no matter
the position of the newly inserted tape cartridge.
Target value of the instrument total flow rate in
milliliters per minute. Used in SingleSpot™ and
DualSpot® sampling modes.
Measured total flow through the instrument in
milliliters per minute. Measured in SingleSpot™ and
DualSpot® sampling modes.
Measured flow through sample spot sense1 of the
instrument in milliliters per minute. Measured in
SingleSpot™ and DualSpot® sampling modes.
Calculated flow through sample spot sense2 of the
instrument in milliliters per minute. Calculated in
DualSpot® sampling mode. No flow in SingleSpot™
sampling mode.
Measured temperature of instrument sampling
stream in degrees celsius.
Measured relative humidity of instrument sampling
stream in percent.
Calculated temperature of dewpoint of instrument
sampling stream in degrees celsius.
Measured pressure inside instrument case in
pascals.
Measured temperature inside instrument case in
Celsius.
Identification of sampling mode (SingleSpot™ (SS)
or DualSpot® (DS)) and only the optical wavelengths
used for each measurement are displayed.
Measured optical intensity of ultraviolet (UV)
wavelength for sample spot sense1 in counts.
Measured in SingleSpot™ and DualSpot® sampling
modes.
Measured optical intensity of ultraviolet (UV)
wavelength for sample spot sense2 in counts.
Measured in DualSpot® sampling mode.
Measured optical intensity of ultraviolet (UV)
wavelength for reference spot in counts. Measured
in SingleSpot™ and DualSpot® sampling modes.
Calculated attenuation of ultraviolet (UV)
wavelength for sample spot sense1 in attenuation
units. Calculated in SingleSpot™ and DualSpot®
sampling modes.
Calculated attenuation of ultraviolet (UV)
wavelength for sample spot sense2 in attenuation
units. Calculated in DualSpot® sampling mode.
AethLabs
Verbose Structure Details
Header Units / Format Example Data
Unitless
UV K 0.0046992627903819
(Decimal number)
Counts
Blue Sen1 751124
(Whole number)
Counts
Blue Sen2 759335
(Whole number)
Counts
Blue Ref 843783
(Whole number)
Attenuation units
Blue ATN1 15.778888
(Decimal number)
Attenuation units
Blue ATN2 9.550997
(Decimal number)
Unitless
Blue K 0.00198470731265842
(Decimal number)
Counts
Green Sen1 810122
(Whole number)
Counts
Green Sen2 829080
(Whole number)
Counts
Green Ref 902411
(Whole number)
Attenuation units
Green ATN1 13.872042
(Decimal number)
Attenuation units
Green ATN2 8.236315
(Decimal number)
Unitless
Green K 0.00123747368343174
(Decimal number)
Counts
Red Sen1 794974
(Whole number)
Counts
Red Sen2 759396
(Whole number)
Counts
Red Ref 888090
(Whole number)
AethLabs microAeth
®
Description
Calculated loading compensation factor for
ultraviolet (UV) wavelength using sample spots
sense1 and sense2, used to compensate BC1 value
resulting in BCc. Calculated in DualSpot® sampling
mode.
Measured optical intensity of blue wavelength
for sample spot sense1 in counts. Measured in
SingleSpot™ and DualSpot® sampling modes.
Measured optical intensity for blue wavelength
for sample spot sense2 in counts. Measured in
DualSpot® sampling mode.
Measured optical intensity of blue wavelength for
reference spot in counts. Measured in SingleSpot™
and DualSpot® sampling modes.
Calculated attenuation of blue wavelength for
sample spot sense1 in attenuation units. Calculated
in SingleSpot™ and DualSpot® sampling modes.
Calculated attenuation of blue wavelength for
sample spot sense2 in attenuation units. Calculated
in DualSpot® sampling mode.
Calculated loading compensation factor for blue
wavelength using sample spots sense1 and sense2,
used to compensate BC1 value resulting in BCc.
Calculated in DualSpot® sampling mode.
Measured optical intensity of green wavelength
for sample spot sense1 in counts. Measured in
SingleSpot™ and DualSpot® sampling modes.
Measured optical intensity of green wavelength
for sample spot sense2 in counts. Measured in
DualSpot® sampling mode.
Measured optical intensity of green wavelength for
reference spot in counts. Measured in SingleSpot™
and DualSpot® sampling modes.
Calculated attenuation of green wavelength for
sample spot sense1 in attenuation units. Calculated
in SingleSpot™ and DualSpot® sampling modes.
Calculated attenuation of green wavelength for
sample spot sense2 in attenuation units. Calculated
in DualSpot® sampling mode.
Calculated loading compensation factor for green
wavelength using sample spots sense1 and sense2,
used to compensate BC1 value resulting in BCc.
Calculated in DualSpot® sampling mode.
Measured optical intensity of red wavelength
for sample spot sense1 in counts. Measured in
SingleSpot™ and DualSpot® sampling modes.
Measured optical intensity of red wavelength
for sample spot sense2 in counts. Measured in
DualSpot® sampling mode.
Measured optical intensity of red wavelength for
reference spot in counts. Measured in SingleSpot™
and DualSpot® sampling modes.
MA Series MA200, MA300, MA350 Operating Manual 61
