Exported Data File Structure Details
Header Units / Format Example Data
Nanograms per
IR BCc cubic meter (ng/m ) 23422
3
(Integer)
Readable status Text Start up

6.2. Serial Data Format Structures

The format structures of the measurement serial data in streaming and polled serial data modes that are
output through the 4-pin serial port of the microAeth are as follows.
6.2.1. Verbose Structure
SingleSpot® sampling mode:

5 Wavelengths:

Serial number, Datum ID, Session ID, Data format version,Firmware version, Date / Time GMT, Timezone
offset, GPS lat, GPS long, GPS Speed, Timebase, Status, Battery, Accel X, Accel Y, Accel Z, Tape position,
Flow setpoint, Flow total, Sample temp, Sample RH, Sample dewpoint, Int pressure, Int temp, Optical
config, UV Sen1, UV Ref, UV ATN1, Blue Sen1, Blue Ref, Blue ATN1, Green Sen1, Green Ref, Green ATN1,
Red Sen1, Red Ref, Red ATN1, IR Sen1, IR Ref, IR ATN1, UV BC1, Blue BC1, Green BC1, Red BC1, IR
BC1, CKSUM
UV + IR Wavelengths:
Serial number, Datum ID, Session ID, Data format version, Firmware version, Date / Time GMT, Timezone
offset, GPS lat, GPS long, GPS Speed, Timebase, Status, Battery, Accel X, Accel Y, Accel Z, Tape position,
Flow setpoint, Flow total, Sample temp, Sample RH, Sample dewpoint, Int pressure, Int temp, Optical
config, UV Sen1, UV Ref, UV ATN1, IR Sen1, IR Ref, IR ATN1, UV BC1, IR BC1, CKSUM
Only IR Wavelength:
Serial number, Datum ID, Session ID, Data format version, Firmware version, Date / Time GMT, Timezone
offset, GPS lat, GPS long, GPS Speed, Timebase, Status, Battery, Accel X, Accel Y, Accel Z, Tape position,
Flow setpoint, Flow total, Sample temp, Sample RH, Sample dewpoint, Int pressure, Int temp, Optical
config, IR Sen1, IR Ref, IR ATN1, IR BC1, CKSUM
DualSpot® sampling mode:
5 Wavelengths:
Serial number, Datum ID, Session ID, Data format version, Firmware version, Date / Time GMT, Timezone
offset, GPS lat, GPS long, GPS Speed, Timebase, Status, Battery, Accel X, Accel Y, Accel Z, Tape position,
Flow setpoint, Flow total, Flow1, Flow2, Sample temp, Sample RH, Sample dewpoint, Int pressure, Int
temp, Optical config, UV Sen1, UV Sen2, UV Ref, UV ATN1, UV ATN2, UV K, Blue Sen1, Blue Sen2, Blue
Ref, Blue ATN1, Blue ATN2, Blue K, Green Sen1, Green Sen2, Green Ref, Green ATN1, Green ATN2, Green
K, Red Sen1, Red Sen2, Red Ref, Red ATN1, Red ATN2, Red K, IR Sen1, IR Sen2, IR Ref, IR ATN1, IR
ATN2, IR K, UV BC1, UV BC2, UV BCc, Blue BC1, Blue BC2, Blue BCc, Green BC1 Green BC2, Green BCc,
Red BC1, Red BC2, Red BCc, IR BC1, IR BC2, IR BCc, CKSUM
58 microAeth MA Series MA200, MA300, MA350 Operating Manual
®
Description
Calculated mass concentration with DualSpot®
loading compensation for infrared (IR) wavelength
using sample spots sense1 and sense2 in
nanograms per cubic meter. Calculated in
DualSpot® sampling mode.
Human readable description of status codes. See
section 6.3. Status Codes for detailed information.
AethLabs
UV + IR Wavelengths:
Serial number, Datum ID, Session ID, Data format version, Firmware version, Date / Time GMT, Timezone
offset, GPS lat, GPS long, GPS Speed, Timebase, Status, Battery, Accel X, Accel Y, Accel Z, Tape position,
Flow setpoint, Flow total, Flow1, Flow2, Sample temp, Sample RH, Sample dewpoint, Int pressure, Int
temp, Optical config, UV Sen1, UV Sen2, UV Ref, UV ATN1, UV ATN2, UV K, IR Sen1, IR Sen2, IR Ref, IR
ATN1, IR ATN2, IR K, UV BC1, UV BC2, UV BCc, IR BC1, IR BC2, IR BCc, CKSUM
Only IR Wavelength:
Serial number, Datum ID, Session ID, Data format version, Firmware version, Date / Time GMT, Timezone
offset, GPS lat, GPS long, GPS Speed, Timebase, Status, Battery, Accel X, Accel Y, Accel Z, Tape position,
Flow setpoint, Flow total, Flow1, Flow2, Sample temp, Sample RH, Sample dewpoint, Int pressure, Int
temp, Optical config, IR Sen1, IR Sen2, IR Ref, IR ATN1, IR ATN2, IR K, IR BC1, IR BC2, IR BCc, CKSUM
Verbose Structure Details
Header Units / Format Example Data
Model and number
Serial number MA200-0011
(MAxxx-xxxx)
Datum ID Whole number 1
Session ID Whole number 1
Data format
Natural number 1
version
Firmware
Decimal number 1.08
version
Year, month, day,
Date / Time hours, minutes, 2018-03-
GMT seconds (yyyy-MM- 21T14:17:00.00
ddTxx:xx:xx.xx)
Timezone offset Minutes (Integer) -420
Degrees
GPS lat 37.7461101412773
(ddmm.mmmmm)
Degrees
GPS long -122.420443087816
(dddmm.mmmmm)
Kilometers per hour
GPS speed 0.144168466329574
(Decimal number)
Seconds
Timebase 60
(Natural number)
Status Whole number 1
Percent
Battery 88
(Whole number)
Accel X Integer -5
AethLabs microAeth
®
Description
Unique identification number for the Instrument.
Identification number assigned to each line of
recorded data.
Identification number assigned to each sampling
and measurement session. This value is incremented
each time a new sampling and measurement
session is started (changes from STOPPED to
SAMPLING mode).
Unique identification number for exported data file
structure used when exporting data from microAeth
Manager software.
Unique identification number for firmware running on
instrument when measurement was recorded.
Local date and time produced from instrument's
internal clock using Coordinated Universal Time
(UTC) and Timezone offset.
Timezone offset from Coordinated Universal Time
(UTC) in minutes.
Measured latitude or relative angular distance north
or south on Earth's surface in degrees from the
equator.
Measured longitude or relative angular distance east
or west on Earth's surface in degrees from the prime
meridian.
Measured speed using GPS in kilometers per hour.
GPS is based on GPS lat and long, which are
required for GPS speed calculation.
Value in seconds of the measurement interval
between measurements.
See section 6.3. Status Codes for detailed
information.
Percent of instrument internal battery remaining.
Measured instantaneous acceleration in the x-axis.
