Tomar Inteligent LED Series Instruction Sheet

TM
TOMAR iLED series dual channel LED warning lamps. Feature 41 programmable flash patterns,
synchronization and are available in lamp sizes 3" x 7", 4" x 6" and 7" x 9".

WIRES

RED +12VDC to activate
BLACK Connect to Chassis GROUND
YELLOW Flash Pattern Selection & Sync Line

ELECTRICAL

Input Voltage: 12VDC thru 28VDC
Complete installation with wire rated for 125% of amperage draw

MOUNTING -

Qty 4 - #6 Screws
WARNING: Do not seal TOMAR LED Lamps. Do not seal the LED lamp to the vehicle
mounting surface. Doing so will prevent water drainage and void the lamps warranty.
CURRENT DRAW - in Steadyburn Mode @ 12vdc
3x7 0.8 Amps
4x6 0.8 Amps
7x9 1.6 Amps

SELECTING FLASH PATTERNS

With the YELLOW wire shorted to +12vdc, turn the unit on. Continue to apply +12vdc to the
YELLOW wire for at least 2 seconds. All LEDs will flash 3 times to indicate you have entered flash
pattern selection mode. While maintaining power, remove the YELLOW wire from +12vdc and the
unit will operate in the currently selected flash pattern.

CYCLE FORWARD

Intermittently short the YELLOW wire once to +12vdc then release.
Repeat until the desired pattern is selected.

CYCLE BACKWARD

Intermittently short the YELLOW wire twice to +12vdc in less than one second.
Repeat until the desired pattern selected.

TO RESET PATTERN #1

Apply +12vdc to the YELLOW wire for at least 3 seconds then release. All LEDs will flash
2 times to indicate that you have reset the flash pattern selection to pattern # 1.
SYNCHRONIZE iLED
To synchronize, first select a flash pattern and program each lamp to the same flash pattern.
Unpredictable results will occur if synchronized lamps have different flash patterns selected.
Connect the YELLOW wires of up to qty 10 synchronized iLED
equivalent to 2 lamp units, when determining the number of lamps to synchronize. Do not exceed
100 feet of wire between the furthest synchronized units. For best results connect the BLACK lead
to Chassis Ground.
iLED
TOMAR Inteligent LED Series
LED with programmable internal FLASHER
INSTRUCTION SHEET
TM
WARNING LAMPS
2100 West Obispo
Gilbert, Arizona 85233
(480) 497-4400
FAX (480) 497-4416
E-mail: sales@tomar.com
TM
TM
lamps. The 7x9 lamps are
(800) 338-3133
(800) 688-6627
www.tomar.com
IS0439-03
03-17-2006
