- Page 1 VICTORIA HIGH-WALL DUCTLESS AIR CONDITIONING & HEATING SYSTEM OWNER'S MANUAL Models: CH30VCT230VI/CH30VCT230VO(230V) CH36VCT230VI/CH36VCT230VO(230V)
- Page 2 CH30VCT230VI/CH30VCT230VO(230V) System Includes: CH30VCT230VI, CH30VCT230VO CH36VCT230VI/CH36VCT230VO(230V) System Includes: CH36VCT230VI, CH36VCT230VO...
-
Page 3: Table Of Contents
CONTENTS ■ Operation and maintenace............1 ■ Notices for operation..............2 ■ Notices for use................3 ■ Names and functions of each part..........4 ■ Operation of wireless remote control..........5 ■ Emergency operation..............1 3 ■... - Page 4 Operation and maintenance-notices for operation ★ Earth: The ground be con- ★ Be sure to pull out the power plug ★ Select the most appropriate tem- perature. nected! when not using the air conditiiner for a long time. Keep room cool- er than outside about 5 degree.
-
Page 5: Notices For Operation
Notices for operation ★ To adjust the airflow direction Please don't cut off or damage the ★ power cords and control cords. appropriately. When operating the unit, to adjust the vertical air flow dire- If they are damaged, please ask the qualified ction by use of remote controller.And then, personnel to change them. -
Page 6: Notices For Use
Notices for use Working principle and special functions for cooling Principle: Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature. Anti-freezing function If the unit is running in COOL mode and in low termperature, there will be frost formed on the heat exchanger, when indoor heat exchanger temperature decreased below 32 , the... -
Page 7: Names And Functions Of Each Part
Names and functions of each part Indoor unit Air in （1） （2） （5） Air out （4） （8） Front panel ⑴ Filter ⑵ ⑶ Guide louver Wall pipe ⑷ ⑸ Bind tape Outdoor unit ⑹ Connection wire ⑺ Drainage pipe Air in Remote control ⑻... -
Page 8: Operation Of Wireless Remote Control
Operation of remote control ON/OFF button MODE button FAN button SWING button TURBO button ▲/ button SLEEP button TEMP button I FEEL button LIGHT button CLOCK button TIMER ON/TIMER OFF button health function Set fan speed I feel Send signal Operation mode Turbo mode Auto mode... - Page 9 Operation of remote control Note: ● This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status.
- Page 10 Operation of remote control temperature. Press "FAN" button to adjust fan speed. Press "SWING" button to adjust fan blowing angle. (Cooling only unit won’t receive heating mode signal. If setting heat mode with remote controller, press ON/OFF button can’t start up the unit).
- Page 11 Operation of remote control TURBO button Under COOL or HEAT mode, press this button to turn to quick COOL or quick HEAT mode. " " icon is displayed on remote controller. Press this button again to exit turbo function and " "...
- Page 12 Operation of remote control ● It’s defaulted to display set temperature when turning on the unit. There is no display in the remote controller. ● Only for the models whose indoor unit has dual-8 display. ● When selecting displaying of indoor or outdoor ambient temperature, indoor temperature indicator displays corresponding temperature and automatically turn to display set temperature after three or five seconds.
- Page 13 Operation of remote control TIMER ON setting will increase or decrease 1min. Hold "▲" or " " button, 2s later, the time will change quickly until reaching your required time. Press "TIMER ON" to confirm it. The word "ON" will stop blinking. " "...
- Page 14 Operation of remote control 8℃ heating function Under heating mode, press “TEMP” and “CLOCK” buttons simultaneously to start up or turn off heating function. When this function is started up, “ ” and 46°F(8°C) ” will be shown on remote controller, and the air conditioner keep the “...
- Page 15 Operation of remote control After putting through the power, press "ON/OFF" button on remote controller to turn on the air conditioner. Press "MODE" button to select your required mode: AUTO, COOL, DRY, FAN, HEAT. Press "▲" or " " button to set your required temperature. (Temperature can’t be adjusted under auto mode).
-
Page 16: Emergency Operation
Emergency Operation Displayer indicator light control of indoor unit It's a special selective button for the users ,who are not accustomed to the light at sleeping. Get the displayer indicator light on: When setting the light function,the mark will ● display on the remote controller screen by pressing this button. -
Page 17: Clean And Care
Clean and care CAUTION Turn power off and pull out the power plug before cleaning air conditioner. Or it may ● ● cause electric shock. Never sprinkle water on the indoor unit and the outdoor unit for cleaning because it ●... - Page 18 Clean and care ① Take down the air filter At the slot of surface panel to open an angle, pull the air filter downward and take it out. Cleaning ② To clean the dust adhering to the filters, you can either use a vacuum cleaner, or wash them with warm water (the water with the neutral detergent should below 45 ℃).
-
Page 19: Troubleshooting
Troubleshooting Warning Do not repair the air conditioner at your discretion. Incorrect repair may cause electric shock or fire, so please contact Authorized Service Center for professional repair. Following checks prior to contact may save your time and costs. Troubleshooting Phenomenon Air conditioner does not run upon immediately To protect the air conditioner upon immediate... - Page 20 Troubleshooting Phenomenon Troubleshooting Has the power been shut down? ● The unit can not run. Does power plug come loose from the socket? ● Is the circuit protection device tripped off or not? ● Is voltage higher or lower? ● (Tested by professionals) Break off Is the Timer correctly used?
- Page 21 Troubleshooting Troubleshooting Phenomenon In HEAT mode, when the temperature of ● Indoor unit cannot deliver air. indoor heat exchanger is very low, that will stop deliver air in order to prevent cool air. (Within 3min) In HEAT mode, when the outdoor temperature ●...
-
Page 22: System Operation
SYSTEM OPERATION COOLING OPERATION How it works: In cooling mode, your victoria indoor unit will absorb heat from the room, then the victoria outdoor unit will discharge the heat to the outdoors. The victoria cooling capacity decreases as the outdoor temperature increases. -
Page 23: Energy Saving Tips
ENERGY SAVING TIPS 1. Relaxing room temperature at night is OK: During the nighttime hours you don’t require the same level of conscious cooling or heating. Try using Sleep Mode to gradually relax room temperature and allow the unit to run less and save energy. 2. - Page 24 www.cooperandhunter.us LIMITED WARRANTY STATEMENT Ductless Heat Pump Split System This warranty should be registered on our web-site www.cooperandhunter.us The warranty is only valid when installed by a Licensed HVAC Technician FOR WARRANTY SERVICE OR REPAIR: Contact your installing contractor. You may find the installer’s name on the equipment or in your Owner’s packet. Complete product registration below and send back by e-mail at PRODUCT REGISTRATION: Model No.: ______________________________________________________________________________________________...
- Page 25 LIMITATIONS OF WARRANTIES: ALL IMPLIED WARRANTIES AND/OR CONDITIONS (INCLUDING IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE OR PURPOSE) ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, SOME STATES OR PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THE ABOVE MAY NOT APPLY TO YOU.
