Judgement Voltage of
FE.16 Instantaneous Power
● Deceleration Operation Mode： When the power line recovers, the Output Frequency
of the inverter will be restored to the target frequency according to the accel. Time.
● Deceleration Stop Mode：When the power line recovers, the inverter continues to
slow down to 0Hz then stop, and the inverter will not start until the inverter start again.

6.13 Jogging

Jogging function is used on low speed equipment tesing for a short time. When in
Jogging mode,the starting mode is fixed as a direct start mode F1.00=0，stopping mode is
fixed as a ramps decel. Stop mode F1.05=0。
Note: There is no Jogging key on the Integral Keypad. To achieve this function, digital
input (DI)should be selected.
Code
F5.01
F5.02
F5.03
F5.04
F5.05
F8.00
F8.01 Jog Accel. Time
F8.02 Jog Decel. Time
Failure
Name
DI1 Function
DI2 Function
DI3 Function
DI4 Function
HDI Function
Jog Frequency
Figure 6-13-1 Jogging
Chapter 6 Parameter Function Description
（60.0 ～ 100.0）
80.0%
Default Setting Range
1
4
9
12
0
0.10 ～ F0.07
5.00Hz
（0.0 ～ 6500.0）s
20.0s
（0.0 ～ 6500.0）s
20.0s
- 86 -
100% equals
Standard DC
%
Bus Voltage
Description
3：Jog
Forward
0 ～ 63
4：Jog
Reverse
-
-
-
