Thanks for buying a BISSELL Big Green Ultra
We're glad you purchased a BISSELL Big Green Ultra
multi-purpose deep cleaner. Everything we know about floor
care went into the design and construction of this complete,
high-tech home cleaning system.
Your Big Green is well made, and we back it with a
full two-year warranty. We also stand behind it with a
knowledgeable, dedicated Consumer Services department,
so, should you ever have a problem, you'll receive
fast, considerate assistance.
My great-grandfather invented the floor sweeper
in 1876. Today, BISSELL is a global leader in the design,
manufacture, and service of high quality
homecare products like
your Big Green Ultra.
Thanks again, from
all of us at BISSELL.
Mark J. Bissell
President and Chief Executive Officer
User's Guide
Big Green Ultra
Model 16753
Assembly
■
Operation
■
Safety
■
Storage
■
™
Deep
™
3 in 1 multi-purpose deep cleaner
■
Compact, convenient, easily
■
maneuvers under and around
furniture
Specialized tools for all
■
cleaning needs
Cleaner.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bissell Big Green Ultra 16753
Summary of Contents for Bissell Big Green Ultra 16753
- Page 1 My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your Big Green Ultra.
-
Page 2: Safety Instructions
Big Green Ultra multi-purpose cleaner. ■ Use only cleaning products formulated by WARNING: To reduce the risk BISSELL for use in this appliance. of electric shock, fire or injury: ■ Keep openings free of dust, lint, hair, etc. ■... -
Page 3: Product View
Tip: Several parts are packed in the corner pockets of your shipping box. Also, match the number on the written Flex Hose instructions to Assembly the number on the assembly picture to better understand each assembly step. Aluminum Wands (2) Wand Solution Tube Flex Hose Assembly to Cleaner... -
Page 4: How To Put It Together
How to use this guidelean carpet This User’s Guide has been designed to help Pay particular attention to the assembly diagram, you get the utmost satisfaction from your Big Green assembly instructions, and part names. Locate and Ultra multi-purpose cleaner. You’ll find assembly organize all parts before assembly. -
Page 5: Table Of Contents
Index Flex Hose Assembly to Cleaner Body. Insert Suction Fitting end of Safety instructions ..2 Flex Hose Assembly into Suction Inlet on Cleaner Body. Suction Product view ....3 Fitting will snap into place when correctly seated. -
Page 6: How To Begin
How to begin... Deep cleaning carpet 1. Vacuum carpet thoroughly. 2. Decide where to begin — and end — your job. Clean in 3’ X 4’ sections, starting in areas farthest from exit. Plan to leave a path open to empty soiled water and refill cleaner. 3. - Page 7 3. Remove Filler Cap from Solution Container. Invert Filler Cap to measure carpet cleaner solution - each filler cap holds 3-oz. Add three (3) full caps of BISSELL Carpet Care concentrate to Solution Supply Tank as shown. 4. Fill Solution Supply Tank with hot (NOT boiling) tap water until water appears in Filler Opening.
- Page 8 Deep cleaning 1. Place floor nozzle directly on carpet at arm’s length. Apply light downward pressure on the Grip/Trigger Unit. When you’re done Pull trigger to spray cleaning solution (wait 30 - 60 seconds for spray to start), while pulling wand toward you. NOTE: When using Extension Wands with your BIG 2.
-
Page 9: Cleaning Upholstery & Small Areas
How to clean upholstery and small areas Getting ready 1. Disconnect Wand Solution Tube and aluminum wands from Grip/Trigger unit of Flex Hose Assembly. 2. Position Wand Solution Tube Connector (with lock slot) of Small Area/Upholstery Cleaning Nozzle near Wand Solution Tube Connection (with lock pin) of Grip/Trigger Unit, as shown. -
Page 10: Dry Vacuuming
3. Attach Flex Hose Assembly to Cleaner Body. 4. Open Lid, grasp Carry Handle, and remove Solution Container. 5. Fold Paper Dust Bag (use only BISSELL Envirofresh Dust Bag). 6. Locate Dust Bag Connection on underside of Lid and position Bag as shown. -
Page 11: Putting It Away
Putting it away After wet/deep cleaning of carpet or upholstery; follow instructions in WHEN YOU’RE DONE, page 8. 1. Remove Flex Hose Assembly from Cleaner Body by pressing Hose Release Button on both sides of Flex Hose Assembly. Squeeze buttons inward and disconnect Flex Hose Assembly from Body. -
Page 12: Troubleshooting
Kink/blockage in hoses/tubes Straighten hoses/tubes from outlet Check aluminum wands/ before servicing. Flex Hose/Wand Solution Tube for obstructions Call BISSELL Consumer Services (see page 14) Reduced spray or no spray / Leaking connections Possible Causes Remedies Spray Nozzle clogged Clean Spray Nozzle... -
Page 13: Parts
Part numbers and descriptions Item Part No. Part Name 715-6000 Carpet Cleaning Nozzle with Wand Solution Tube 603-6001 Small Area/ Upholstery Cleaning Nozzle with Connector 716-4100 Flex Hose Assembly 715-9650 Aluminum Wand with Clip (1 ea) 713-2450 Wand Clip (1) 710-6005 Crevice Tool 710-6004... -
Page 14: Warranty
BISSELL Consumer Services. Two Year Warranty BISSELL Inc., upon receipt of the product, will repair or replace, free of charge, any part which is defective or malfunctioning within two years of the purchase date, provided that it is used for personal and not commercial or rental service.
