- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Bissell 1671 Owner's Manual Shop genuine replacement parts for Bissell 1671 Find Your Bissell Vacuum Cleaner Parts - Select From 376 Models -------- Manual continues below --------...
- Page 2 Big Green ® D E E P C L E A N E R U S E R ’ S G U I D E 1672 SERIES Safety Instructions Product View Assembly 6-11 Operations / Special Tools Maintenance Troubleshooting Replacement Parts Consumer Services Warranty...
- Page 3 Consumer Services department, so, should you ever have a problem, you’ll receive fast, considerate assistance. My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your Big Green.
- Page 4 Read all instructions Use only cleaning products formulated by before using your Big Green. Always connect to BISSELL for use in this appliance. a properly grounded outlet. Unplug from outlet Keep openings free of dust, lint, hair, etc.
- Page 5 Tip: Finger tighten Large Vacuum threaded outlet Flex Hose Clips connections. Do not over tight- en, or use pliers or tools to tighten. Grip/Trigger Unit Hose with Threaded Connectors Vacuum Flex Hose Wand Solution Tube Top Power Unit Small Wand Clips Aluminum Wands...
- Page 6 Familiarize yourself with the parts and where power unit to they fit. Following this User’s Guide will greatly enhance your find these parts. ability to get the most performance from your BISSELL Big Also, match the Green for many years. number on...
- Page 7 How To Put It Together Continued Wand Solution Tube. Connect wand solution tube Wand Solution Tube to spray tip on floor nozzle and to cap valve on grip/trigger unit. Vacuum Flex Hose Small Wand Clips. Secure tube to wand with two small wand clips.
- Page 8 Use only Bissell ® Floor Care cleaning solution on no-wax and allergens in floors. Never use Bissell ® Carpet Cleaner or other carpet your home. cleaners on bare floors. Sweep before starting. Remove old wax before cleaning.
- Page 9 120° F/48° C) into filling cavity until level reaches bottom of three vertical lines in tank unit. Shake bottle of BISSELL Carpet Care. Fill measuring lid to fill line (10 ounces). Empty measuring lid into filling cavity Filling Cavity and replace measuring lid.
- Page 10 When You’re Done Turn off pump/spray and vacuum/suction switches. Unplug from outlet. Remove tank siphon tube, flip down carrying handle and lift top power unit from tank unit. Carry tank unit to a toilet or sink to empty. With carrying handle in one hand, place other hand in gripping slot under filling cavity on tank unit.
- Page 11 Align front edges and snap together. Floor Nozzle Fill measuring lid twice with Bissell Floor Care and empty into filling cavity. Vacuum/suction switch Pour two gallons of hot tap water into filling cavity.
- Page 12 How To Dry Vacuum Attach one of four dry vacuuming tools. Insert tank siphon tube in tank unit. Tip: Turn on vacuum/suction switch. Vacuum as usual. Always check motor filter before dry Empty collection tank when it is half full. vacuuming.
- Page 13 Putting It Away After Deep Cleaning/Wet Vacuuming Rinse filling cavity with clean water. Leave about 1/2 gallon of clean water in filling cavity. Hold floor nozzle over bucket or sink. Tank Turn on pump/spray switch, pull trigger for 30 seconds, siphon and empty power unit.
- Page 14 Wand solution tube kinked/disconnected Relax kinks in solution tubes/hoses Pump is not operating Check electrical plug Pump/spray switch on? Call BISSELL Consumer Services ( see page 15) Connections not tight Finger tighten all connections (do not use pliers or other tools) WARNING:...
- Page 15 BISSELL Replacement Parts Item Part No. Part Name 210-4706 Vacuum flex hose 555-9129 Large vacuum flex hose clips (3) 555-9013 Hose with threaded connectors 216-4181 Grip/trigger unit 210-1188 Dusting brush 010-9156 Crevice attachment 010-6055 Small vacuum nozzle 213-9152 Drain clean-out attachment...
- Page 16 NOTE: Please keep your original sales receipt. It is your warranty. You may purchase replacement parts from your retailer, by using the order form in this User’s Guide, by calling BISSELL Consumer Services or by visiting our website. To locate a retailer near you, or to place an order using...
- Page 17 User's Guide is not covered. If your BISSELL product should require service: Call BISSELL Consumer Services at the number below or visit the BISSELL website - www.bissell.com to locate a BISSELL Authorized Service Center in your area. If there are no authorized BISSELL Service Centers in your area, select the "Customer Service"...
