OPTIONAL ACCESSORIES
CASTER KIT
P/N 430291
To improve maneuverability
on hard paved surfaces.
HOLD DOWN KIT
P/N 430299
For use on truck or trailer to
provide quick hold down for
your QB.
Part No. 430258
T h a n k Yo u f o r S e l e c t i n g
The Powerful QUIET BLOW
Operator Owner's Manual
QB883, QB883H, QB1103, QB1103H
3 3 3 3 3
Engine: HP
Engine:Type
Engine: Fuel cap.
Engine: Oil Cap.
Weight: Unit
Weight: Shipping
Engine Weight:
UNIT SIZE: OVERALL LENGTH: 51.75"(1.31m) OVERALL WIDTH 28.5" (0.72m)
OVERALL HEIGHT
BLOWER
®
For Models:
Specifications
QB883
QB883H
8.0 HP (5.97 kW)
8.0 HP (5.97 kW)
B & S
HONDA OHV
4.0 qt. ( 3.8 L)
6.4 qt. (6.1 L)
1.38 qt. (1.3 L)
1.16 qt. (1.1 L)
124 # ( 56.3 Kg)
136 # (61.7 Kg)
141 # (63.97 Kg)
153 # (69.4 Kq)
46 # (20.8 Kg)
48.5 # (22.0 Kg)
39" (0.99m)
Page 1 of 8
QB1103
QB1103H
11.0HP (8.2kW)
11.0HP (8.2kW)
B & S
HONDA OHV
6.0 qt. ( 5.7 L)
7.4 qt. ( 7.0 L)
1.5 qt.(1.4L)
1.2 qt.(1.13L)
150 # (68.0 Kg)
152 # (68.9 Kg)
167 # (75.8 Kg)
169 # (76.7 Kg)
64.254 #(29.1 Kg)
68.4 #(31.0 Kg)
Form No. F042099A
Advertisement
Table of Contents
Related Manuals for Billy Goat QB883, QB883H, QB1103, QB1103H
Summary of Contents for Billy Goat QB883, QB883H, QB1103, QB1103H
-
Page 1: Specifications
QB. Part No. 430258 T h a n k Yo u f o r S e l e c t i n g For Models: QB883, QB883H, QB1103, QB1103H 3 3 3 3 3 Specifications QB883 Engine: HP 8.0 HP (5.97 kW) -
Page 2: In The Interest Of Safety
IN THE INTEREST OF SAFETY 5 5 5 5 5 BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S MANUAL & ENGINE MANUAL.” THIS SYMBOL MEANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. The engine exhaust from this product contains chemicals known to the State of California to cause WARNING! cancer, birth defects or other reproductive harm. -
Page 3: Packing Checklist
PUT OIL IN ENGINE BEFORE STARTING Your Billy Goat is shipped from the factory in one carton, completely assembled except for the upper handle assembly, handle brace, plate deflector and throttle control. PACKING CHECKLIST These items should be included in your carton. -
Page 4: Instruction Labels
Nut Lock 5/16-18 8160002 Qty. 5 INSTRUCTION LABELS These labels should be included on your Blower. If any of these labels are damaged, replace them before putting this equipment into operation. Item and part numbers are given to help in ordering replacement labels. -
Page 5: Blowing Operation
OPERATION INTENDED USE: This machine is designed for cleaning outdoor surfaces, where the debris can be effectively blown into a consolidated area for convenient pickup and removal. Do not operate if excessive vibration occurs. If excessive vibration occurs, shut engine off immediately and check for damaged or worn impeller, loose impeller bolt, loose impeller key, loose engine or lodged foreign objects. - Page 6 PARTS DRAWING QB883, QB883H, QB1103, QB1103H Part No. 430258 Form No. F042099A Page 6 of 8...
- Page 7 QB883 QB883H QB1103 QB1103H PARTS LIST Denotes parts found in parts bag assembly. Notes standard hardware that may be purchased locally. Part No. 430258 Page 7 of 8 Form No. F042099A...
-
Page 8: Maintenance Schedule
22 22 22 22 Please fill in the WARRANTY CARD and send the upper part to Billy Goat. The WARRANTY terms are stated on the lower part which remains with the user. Whenever a Billy Goat Machine is faulty due to a defect in material and / or workmanship, the owner should make a warranty claim as follows: Serial No.
