Luna GII Quick Operation Manual
1. Button Functions
Mute Button: Press it to mute alarms
Knob: Start treatment and adjust device settings
Ramp Button: Press it to enable the Ramp feature
2. Setting up the Device
Power Cord
Power Outlet
E
A. Connect one end of the tube to the assembled mask.
B. Connect the other end of the tube securely to the air outlet of the device, as shown in the figure
above.
C. Connect the power adapter to the DC inlet of the device.
D. Connect the power cord to the power adapter.
E. Plug the power cord into the power outlet.
3. Adjusting Device Settings
A. After the device is connected to power, its screen displays the Main Interface shown in the figure
below.
B. From the Main Interface shown above, press and hold the Ramp Button
seconds. The screen displays the Initial Setup Interface, as shown in the figure below.
C. Press
the Knob
to access the Setup Interface, as shown in the figure below.
Luna GII Quick Operation Manual V1.0
A
Mask
Tube
Power Adapter
D
1 / 2
B
Air Outlet
C
Device
DC Inlet
Filter Cap (Air Inlet)
for three
Advertisement
Table of Contents
Related Manuals for 3B Medical Luna GII
Summary of Contents for 3B Medical Luna GII
- Page 1 Luna GII Quick Operation Manual V1.0 Luna GII Quick Operation Manual 1. Button Functions Mute Button: Press it to mute alarms Knob: Start treatment and adjust device settings Ramp Button: Press it to enable the Ramp feature 2. Setting up the Device...
- Page 2 Luna GII Quick Operation Manual V1.0 D. Press and turn the Knob to adjust an option. E. Press the Knob to confirm your adjustment to the option. F. The cursor switches among the options as you turn the Knob . Refer to steps C-E to adjust other options.
