46 Monitoring/scaling
settings
46.01 Speed scaling
0.10...30000.00 rpm
46.02 Frequency scaling
0.10...1000.00 Hz
46.03 Torque scaling
0.1...1000.0%
46.04 Power scaling
0.1...30000.0 kW or
0.1...40214.5 hp
46.05 Current scaling
0...30000 A
46.06 Speed ref zero scaling
0.00 ... 30000.00 rpm
46.11 Filter time motor
speed
2...20000 ms
46.12 Filter time output
frequency
2...20000 ms
Description
Speed supervision settings; actual signal filtering; general
scaling settings.
Defines the maximum speed value used to define the
acceleration ramp rate and the initial speed value used to
define the deceleration ramp rate (see parameter group
23 Speed reference ramp). The speed acceleration and
deceleration ramp times are therefore related to this value
(not to parameter 30.12 Maximum
Also defines the 16-bit scaling of speed-related
parameters. The value of this parameter corresponds to
20000 in eg. fieldbus communication.
Acceleration/deceleration terminal/initial speed.
Defines the maximum frequency value used to define the
acceleration ramp rate and the initial frequency value
used to define deceleration ramp rate (see parameter
group 28 Frequency reference
acceleration and deceleration ramp times are therefore
related to this value (not to parameter
frequency.
Also defines the 16-bit scaling of frequency-related
parameters. The value of this parameter corresponds to
20000 in eg. fieldbus communication.
Acceleration/deceleration terminal/initial frequency.
Defines the 16-bit scaling of torque parameters. The value
of this parameter (in percent of nominal motor torque)
corresponds to 10000 in eg. fieldbus communication.
Torque corresponding to 10000 on fieldbus.
Defines the output power value that corresponds to 10000
in eg. fieldbus communication. The unit is selected by
parameter 96.16 Unit selection.
Power corresponding to 10000 on fieldbus.
Defines the 16-bit scaling of current parameters. The
value of this parameter corresponds to 10000 in fieldbus
communication.
Defines a speed corresponding to a zero reference
received from fieldbus (either the embedded fieldbus
interface, or interface FBA A or FBA B). For example, with
a setting of 500, the fieldbus reference range of 0...20000
would correspond to a speed of 500...[46.01] rpm.
Note: This parameter is effective only with the ABB Drives
communication profile.
Speed corresponding to minimum fieldbus reference.
Defines a filter time for signals
and 01.02 Motor speed
Motor speed signal filter time.
Defines a filter time for signal
Output frequency signal filter time.
speed).
chain). The frequency
30.14 Maximum
01.01 Motor speed used
estimated.
01.06 Output frequency.
Default
FbEq 16
1500.00 rpm
1 = 1 rpm
50.00 Hz
10 = 1 Hz
100.0%
10 = 1%
1000.0 kW or
hp
1 = 1 unit
10000 A
0.00 rpm
1 = 1 rpm
500 ms
1 = 1 ms
500 ms
1 = 1 ms
