- Page 1 KYMCO Many 110 EV Electric Scooter User Manual...
- Page 2 FCC Statement This device complies with part 15 of the fccrules. Operations is subject to the following two conditions: ( 1 ) this device may not cause harmful interference and ( 2 ) this device must accept any interference received, including interfeerence that may cause undesired operation (15.19) FCC 15.21: The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 3 —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.
- Page 4 NCC Notice Administrative Regulations on Low Power Radio Waves Radiated Devices Article 12 Without permission granted by the NCC, no company, enterprise, or user is allowed to change the frequency, enhance the transmitting power, or alter the original characteristics, as well as performance, of approved low power radio-frequency devices.
- Page 5 Dear User, Thank you very much for choosing a KYMCO NEW Many 110 EV Scooter. The KYMCO NEW Many 110 EV is the latest environmentally friendly scooter which is low-pollution, low-noise, and energy saving. Although this Scooter has good quality, it still requires periodic maintenance to retain its best performance.
- Page 6 Model and type Frame Number EA10UA (meter type: noodoe version) Flip the seat open and read the frame number as shown in the figure. Core battery 10Ah Personal battery 13Ah Ionex System EA10UB (meter type: LCD meter) Core battery 10Ah Personal battery 13Ah Ionex System...
-
Page 7: Table Of Contents
- Contents – Safe riding ..............1 Meter ................21 How to ride ..............2 How to enter the noodoe System ........25 Clothing ................2 Correct riding method ..........32 Load carrying ..............3 Correct Parking Method ..........37 Precautions ............... -
Page 8: Safe Riding
The rider must wear protective gear, such as a scooter 1. Safe riding helmet or gloves, motorcycle trousers, etc., in accordance As a responsible owner and rider. with the laws and regulations. Possessing a valid scooter license issued by the R.O.C. ... -
Page 9: How To Ride
Checks before riding Clothing Visually check tires for any foreign object or unusual Buckle up long sleeves. Pull clothes in snugly to prevent abrasion. sleeves from being caught by the brake lever. Wear a helmet and buckle up the chin belt. ... -
Page 10: Load Carrying
Vehicle functionalities are related to its structure. Load carrying Arbitrary modification may deteriorate the operability of Operability of the handles varies depending on the extra load. the vehicle, causing shortened service life and obstructing The handle swings easily with an excessive load. Avoid riding driver safety. - Page 11 6 months, 12 months, 18 months and 24 months to ensure safe use of the scooter. Be sure to carry out specified regular checks. If you are unclear about something, go to the authorized shop or Kymco Service Center for consultation or inspection.
-
Page 12: Precautions
The horsepower of the motor slows down. Precautions Kymco’s electric scooter has some parts that are different During riding, the motor power and speed may suddenly drop. This is not a malfunction, but a protective device. from those of a gas scooter. Therefore, special and Riding on a hot day or on a steep slope adds a huge load different precautions are listed. - Page 13 When the scooter is stopped and you do not use it, charge the Core/Personal/Shared battery fully. The Personal battery is the property of Kymco and the user only has the right to use it. Attention should be paid during use and avoid damage to the appearance.
-
Page 14: Parts Names
Daylight 2. Parts Names Front Blinker Headlight Brake Lever Side Mirror Seat (luggage box) Rear Armrest Tail light/Rear Blinker Reflective Sheet NFC Sensor Side Stand Main Stand Motor... - Page 15 Middle Hook Smart energy bay Disc Brake (EA10UB uses drum brakes) Main Switch Motor Controller Rear passenger foot peg Charging Outlet Front Hook...
- Page 16 Headlight Switch Blinker switch Horn switch Meter (EA10UB: LCD meter) noodoe button (EA10UB does not have this button) Cartridge Switch POWER Mode/Start-up Switch...
-
Page 17: Operation Of Each Part
Main switch cap 3. Operation of each part For anti-theft protection, lock the main switch cap when Main Switch Cap and 2-in-1 Key parking. Locking Method: Notch Number plate Main switch key Push the main switch key upwards to close the main switch cap and phone charging station. -
Page 18: Position Of The Main Switch
Position of the Main Switch : The Steering Stem is locked in this position. The key can be pulled out. : All vehicle power is cut off in this position. The key can be pulled out. (Engine off) : In this location, the scooter is totally powered on and the headlight and position lights are lit up. -
Page 19: Steering Stem Lock
POWER Mode/Start-up Switch Steering Stem Lock When this button is pressed, the meter LCD will display POWER and your scooter will enter POWER mode. In this mode, a larger current is output during continuous hill climbing so that it will be more powerful for hill climbing. Press this button again to return to normal mode. -
Page 20: Personal/Shared Battery
Personal/Shared battery QR Code (above the battery) Personal battery Shared battery (white handle) (orange handle) Smart Sensors (on both sides of the battery base) Note When you use the Personal/Shared battery to sense the pedal, point a Battery Base Smart Sensor (on either side) at the pedal icon to open the Smart energy bay. -
Page 21: Cartridge Switch
If the Smart energy bay does not operate smoothly (jitter) After riding, do not cover the headlight using any item when opened, go to the authorized shop or Kymco Service (such as your coat, jacket, raincoat, or scooter cover, etc.) Center for inspection and repair immediately. -
Page 22: Horn Switch
Horn switch Blinker switch The horn will sound when the main switch is turned ON and When you make a turn or change lanes, you should use the the Horn switch is pressed. Blinker. The Blinker goes off when pushing the switch back. : Use this position for Left Turn. -
Page 23: Front Hook
Front Hook Middle Hook Light objects can be hung on the front hook. However, the This Hook can carry lighter items which should not be object must not be heavier than 3 kg, otherwise the hook heavier than 3 kg. Otherwise, it may be broken. might break. -
Page 24: Usb Socket
If you have to park your scooter for a long time, we recommend that you use the Main Stand. If there is any problem with the Side Stand, go to your local authorized Kymco shop to have it checked. -17-... -
Page 25: Helmet Hook
R Gear (reverse gear) Helmet Hook Press the R Gear (continuously pressed) before the left Instructions for Use: handlebar switch, and the meter indicator (as shown below) 1. Open the seat and flip it up. lights up. The reversing warning sounds are made and the 2. -
Page 26: Install The Personal Battery
Install the Personal battery 5. Mount the Personal battery 1. You must brace the main until it is in place. stand up on level and flat ground. 6. Press the cartridge switch on the right handlebar to close the Smart energy 2. -
Page 27: Remove The Personal Battery
Remove the Personal battery 5. Lift the Personal battery upwards. 1. You must brace the main stand up on level and flat ground. 6. Sense the NFC by holding the Battery bottom (either side) close to it. 2. Turn the main switch key 7. -
Page 28: Meter
Reverse Indicator: press the R Gear (continuously 4. Meter pressed) before the left handlebar switch, and the meter indicator lights up. The reversing warning sounds are made and the scooter enters Reverse mode. Use the Acceleration Handlebar to reverse it. Blinker: The indicator is illuminated when the Blinker switch is activated. - Page 29 When the Side Stand is down, the meter LCD displays the scooter to the Kymco authorized shop for inspection. power disconnection icon and the Service Lamp lights up in 13. ADJ button (adjustment button): yellow.
- Page 30 : noodoe connection symbol: When your scooter is connected to your phone, the symbol appears. 15. Time settings (EA10UB) A. In ODO Mode, press “MODE” + “ADJ” for 2 seconds to enter Settings mode. At this time, “H:M” flashes. B. When “H:M” flashes, press the “Adj” button to increase the number progressively (00~23).
- Page 31 The Core battery has a capacity of 10 Ah. Refer to the table below for the rough remaining capacity (the The Personal battery/Shared battery has a capacity of 13 remaining capacity of the healthy battery): Ah. Refer to the table below for the rough remaining The capacity is 67~100% if three bars are illuminated.
-
Page 32: How To Enter The Noodoe System
Step 1: Download the app. 5. How to enter the noodoe System Go to Google Play (Android) or App Store (iOS) (EA10UB uses a LCD meter) directly, and type the keyword “noodoe” to search for it. Step 1: Download the app. Refer to “Download noodoe app,” download the app and the system installs the app automatically. - Page 33 Step 2 Introduction to operation buttons When riding Operate the ( ︿ ) and ( ﹀ ) buttons to switch between 4 ( ︿ ) button→ Page Up Key screens of Dashboard noodoe functions. Press the (O) button to end the action. (O) button →...
- Page 34 Step 3: Scooter Pairing noodoe Function When the user pairs with his/her scooter, he/she must sign A. Introduction to app functions The user may browse and collect creations from users all up for a new account. KEY ON (scooter) →long press the (O) button within 30 seconds to select a new user (scooter) over the world and install them into the Dashboard of →display the device name (scooter)→turn on the Bluetooth...
- Page 35 Create Mode B. Find My Scooter Create Mode allows you to remix an existing template to Forgot where you’ve parked? No worries, noodoe your liking. remembers. Tap the icon and the app will guide you back to where ...
- Page 36 D. Message Notice C. Navigation function Once the cell phone is linked, any incoming message will be forwarded to the scooter dashboard (Android users may select their display with → Settings → Application). While Driving: A message “For the sake of safety, no message is viewable when you drive the scooter.”...
- Page 37 Bluetooth/ Connection/ 6. The last screen at the previous shut down will be the Welcome Light automatically. Go to a KYMCO first screen on a restart. authorized store for repair if you cannot use these functions after starting the vehicle.
- Page 38 C. Entering the Find My Scooter screen will cover 7. The compass function must be activated by performing functions a and b, in which case the system enables setup on a cell phone. Minor errors may exist depending the Welcome Light until the user gets out of on data update frequency.
-
Page 39: Correct Riding Method
6. Correct riding method During riding Learning the accurate riding method is important for safety Step on the motorcycle from the left and sit on the seat and extends the service life of the vehicle. properly. Place your left foot on the ground to avoid Charge the Ionex ( Personal / Shared )battery or Core toppling over. - Page 40 Activating the Main Switch 0 is displayed on the speedometer of the meter Activating the Main Switch Note 00 is flashing on the When you activate the Main Switch, the Acceleration speedometer of the meter Handlebar must return to its original position, or the Acceleration Handlebar will not function properly.
- Page 41 Check of Front-Rear Safety Starting and Acceleration Turn on the Blinker before starting and check the rear side Release the rear brake lever and turn the Acceleration for safety before riding. Handlebar backward slowly. The scooter then starts slowly. Note Do not turn the Acceleration Handlebar rapidly to avoid sudden unintended acceleration of the scooter.
- Page 42 Vehicle Speed Control Adequate riding The Acceleration Handlebar determines the speed Follow the manual to extend the service life of vehicle. Accelerate => Speed increases Note Slowly turn the Acceleration Handlebar backward to Beware that the vehicle will slip easily and be unstable if increase the current to speed of the scooter.
- Page 43 Do not brake or turn abruptly Take extra cautions when riding on rainy days Do not brake or turn abruptly unless there is an The braking distance needed is longer on rainy days than emergency, otherwise the vehicle will slip or topple over, sunny days.
-
Page 44: Correct Parking Method
7. Correct Parking Method Pulling the Brake Lever Slowly When approaching a parking location: Return the Acceleration Handlebar to its original position. The Blinker blinks and goes off if turned on in advance. Slowly pull the front and rear Brake Levers tightly. Do not Pay attention to vehicles behind you and on your side. - Page 45 At a full stop of the vehicle Main Stand Place your left foot on the ground and turn off the Blinker Get off the scooter from the left side. Put down the main Switch. Then turn the Main Switch to “OFF”. stand or side stand on level and flat ground without affecting the traffic.
-
Page 46: Scooter Charging
8. Scooter Charging Locking the Handlebar Charger Mode For theft prevention, lock the handlebar and pull out the key 1. Standby mode →Green LED is on when parking your scooter. 2. Charging mode →Yellow LED is on Turn the Main Switch to “LOCK” and gently swing the 3. - Page 47 The main power source of the scooter is the battery. When you stop the scooter, turn off its power and charge the battery fully. Scooter Charging Method: (1) Turn the Main Switch to “OFF” (Fig. 1). (2) Connect the power cable of the charger and plug it into the AC 110v outlet (Fig.
- Page 48 accidental electric shock. Do not remove the Ionex Note ( Personal / Shared )battery for charging at this time. During the operation of the charger, the charger and During charging, you must use an independent power battery become hot. This is normal. Please perform source.
- Page 49 11. When the battery pack is damaged, go to your nearest should return it to the authorized shop, or bring it to a Kymco Service Center to inspect or replace the battery recycling site or recycling truck for recycling. pack. Do not disassemble it yourself.
- Page 50 How to use the Personal/Shared battery 1. You must brace the main stand up on level and flat ground. 2. Turn on the Main Switch (Fig. 1) and press the Battery Cartridge Switch to open the Smart energy bay. 3. Remove the Personal/Shared battery from the Smart energy bay, and place it in the battery charging dock (Fig.
-
Page 51: Battery Characteristics
Wait until the battery temperature Use the genuine battery, charger, and related accessories drops and charge it. dedicated for the Kymco Electric Scooter. The charger is not included with the scooter. You have the Warning option to rent or purchase it optionally. - Page 52 Read the manual carefully before use. Go to the Kymco authorized shop or Service Center for When using the battery set for the first time, replace it if battery maintenance and inspection on a regular basis.
-
Page 53: Checks Before Riding And Regular Checks
You must leave a proper gap for the brake lever. The “gap” accident prevention. For the first time check within one month, go to the Kymco indicates the distance between a released position and the Service Center and the authorized shop you bought your position that feels tight when moving the lever from a scooter. - Page 54 ■ Adjustment and inspection of the gap of the brake lever Check the brake operation. When riding on a dry road or in low speed, check if the front <Drum brake model> and rear break levers can brake effectively. (Refer to the Use Use the brake adjustment nut to adjust the gap.
- Page 55 ■ Check the Blinker Turn the main switch to “ON”. <Disc brake model> Operate the Blinker switch to verify if each Blinker Check Front/Rear Brake Lining flashes and dies out. Check the Blinker lens for stains or fractures. Use limit ...
- Page 56 Check if metal sheets or stones are caught in the groove. ■ Check tires Remove them before riding. When a tire cracks or the groove depth reaches the limit of Check the grip between tire and the ground and normal tire wear, replace it with a new one.
- Page 57 12V. If the voltage is too low, remove the battery, and (Recommended gear oil) recharge it. KYMCO Gear Oil or SAE90# Gear Oil When the battery terminal is rusty, open the seat and remove the battery cover. Clean the battery terminal. After cleaning, apply grease or petrolatum to the battery terminal before installing the battery.
- Page 58 Check the Steering Stem <Change Method> Visually check the steering stem for damage. 1. Brace the main stand up on level and flat ground. Apply the front brake and pull the lever up and down to 2. Remove the gear oil drain bolt and gear oil feeding bolt. check if there is any noise.
- Page 59 (6) Check if the head light, tail light and blinker goes on (9) Lubrication for All Parts of the Vehicle normally. Visually inspect that each part of the body is sufficiently After the main switch is turned ON: lubricated. Make sure the meter operates or a service code appears (If so, inspect and repair it at the authorized shop or Service Center).
-
Page 60: During A Malfunction
Is the battery fully charged (refer to the meter section)? (Make sure the bars displayed on the meter. Charge the battery if necessary) Check the fuse. Note If a service code appears, go to a Kymco authorized shop, Kymco EV Scooter shop, or Service Center for repairing. -53-... -
Page 61: Change The Fuse
12. Change the fuse Turn the main switch off to check for a blown fuse. Note Only replace it with a fuse of specified capacity. Removal Identify the cause of a blown fuse before replacing it. Don't overstretch the fuse clip during removal. Remove the helmet box. -
Page 62: Maintenance List
Operation of each part (Note 3) For your safety and warranty terms, it is recommended to perform these tasks at Kymco authorized shop. Heavy loads, long journeys, or rainy days may cause poor battery performance. Check or replace the battery as soon as possible. -
Page 63: New Many 110 Ev Scooter Specifications
14. NEW Many 110 EV Scooter Specifications Model EA10UA/EA10UB Total Length/ Width/ Height 1730mm /670mm /1070mm Dry Weight/ Ascending Angle 87kg/ 19° Motor Rated/Max. Power 2300W/3200W Ionex battery / Core battery 50.4V13Ah / 10Ah Charger Input AC 100-240V/50-60Hz/2.3A Output DC 57.4V/3A Charger Model 3180A-AGD7-900 Drive System... - Page 64 NFC product specifications Product name: NFC Reader Part no.: 36300-AGD7-900 Input: 5V Made in Taiwan CCAL18LP1700T5...
