Amendment of the original operating
instructions
Inspection of the bolted connection of the
worm wheel of the elevator machines
ZAS0, ZAS1, ZAS2, ZAS3
1. Safety instructions
Pictographs:
Attention!
General hazardous area. Death or severe injury or significant property damage
can occur if the corresponding precautions are not taken!
2. Inspection of the bolted connection of the worm wheel
Caution!
Installation, connection to the power supply and commissioning may only be
performed by qualified service personnel! The relevant regulations must be
observed!
ZAS0, ZAS1, ZAS2 and ZAS3 are elevator machines with worm gears.
This instruction manual is an amendment to the original operating instruction:
ZAS0 Part-No. 01008051-GB
ZAS1 Part-No. 01009054-GB
ZAS2 Part-No. 01009066-GB
ZAS3 Part-No. 01009067-GB
This instruction manual describes the inspection of the bolted connection of the fitting bolt and nut
of the worm wheel for SWG0-, SWG1-, SWG2- and SWG3-gearboxes for ZAS0-, ZAS1-, ZAS2-
and ZAS3-elevator machines.
This Inspection is not a necessary part of the regular maintenance.
Attention!
If it is possible to turn a nut on the fitting bolt or the whole connection of the
nut and fitting bolt the elevator has to be shut down in order to avoid an
uncontrolled movement of the elevator car!
