  • Page 1 NEW CONDENS FS 600 SERIES Cast Aluminium Floor Standing Condensing Boilers for Natural Gas INSTRUCTIONS FOR USE, INSTALLATION AND MAINTENANCE...
  • Page 2: Declaration Of Conformity

    NEW CONDENS FS 600 SERIES Declaration of conformity 1015 Gas Appliance Directive 2009/142 Efficiency Directive 92/42 Low Voltage Directive 2006/95 Electromagnetic Compatibility Directive 2004/108 President and Legal Representative...
  • Page 3: Manufacturer's Liability

    NEW CONDENS FS 600 SERIES Manufacturer's liability Our products are manufactured in compliance with the requirements of the various directives applicable. They are therefore de- livered with the marking and any documents necessary. In the interests of the quality of our products, we strive constantly to im- prove them.
  • Page 4: Health And Safety

    Instructions or as otherwise recommended ionisation flame control, modulating speed fan and mod- by Ferroli Ltd in writing. If in doubt please enquire. ulating gas valve. New Condens FS Series is a heat Any direct connection of a control device not generator arranged to operate alone or in cascade.
  • Page 5: Technical Data Table

    Technical Data Table FERROLI NEW CONDENS 600 SERIES EFFİCİENCY AND PERFORMANCE Max. heat input in CH mode Min. heat input in CH mode Max. heat output in CH mode (80/60°C) Min. heat output in CH mode (80/60°C) Max. heat output in CH mode (50/30°C) Min.
  • Page 6: Boiler Dimensions

    Boiler Dimensions MODEL 1200 1270 1046 1040 R 2” R 1 ¼” 1285 1270 1058 1056 R 2” R 1 ½” 1470 1270 1078 1090 DN65 R 1 ½” 1681 1270 1078 1150 DN65 R 2” 1776 1270 1078 1150 DN65 R 2”...
  • Page 7: Recommended Minimum Distances

    Recommended Minimum Distances 800 mm 800 mm 800 mm 800 mm 200 mm BOILER CLEARANCES Rear: 1000mm or adequate space from the rear of the The minimum dimensions as indicated must be respected to jacket to make the flue connections and access to the ensure good access around the boiler.
  • Page 8 Detailed recommendations are contained in the following Standards and Codes of Practice: BS EN 1212:2005 Chemicals used for treatment of water intended for human consumption. Sodium polyphosphate BS EN 13076:2003 Devices to prevent pollution by backflow of potable water. Unrestricted air gap. Family A. Type A Devices to prevent pollution by backflow of potable water.
  • Page 9: Frost Protection

    INTRODUCTION FOUNDATION / LOCATION OF BOILER The New Condens FS Series boilers are fully automatically The boiler must stand on a floor which must be flat, level controlled, floor standing, fanned, super efficient condensing and of a suitable load bearing capacity to support the appliances.
  • Page 10: Flue Installation

    Advice regarding the availability of proprietary types of should be taken with tall flue systems to ensure excess flue system can be obtained by contacting Ferroli Ltd. All buoyancy is not created. A negative pressure must not be joints or connections in the flue system must be created at the boiler flue outlet.
  • Page 11: Water Circulation System

    WATER CIRCULATION SYSTEM Note. A circulation pump MUST be connected to the boiler, see With the boiler firing at maximum rate, the temperature below. differential should not be less than 10°C. Higher flow rates required for lower temperature differentials could lead to The boiler must NOT be used for direct hot water supply.
  • Page 12: Water Hardness

    If a boiler is replaced in an existing system, we recommend installing a dirt trap or filter in the system return, upstream of Ferroli Ltd recommend the use of Fernox or Sentinel inhibi- the boiler. Flush the system thoroughly. tors and associated water treatment products, which must be used in accordance with the manufacturers' instructions.
  • Page 13: Important Note

    MUST comply with the pump manufacturer's minimum requirements, to avoid cavitation. Should these conditions not apply either lower the pump position or raise the cistern above the minimum requirement specified by Ferroli Ltd The isolation valves should be fitted as close to the pump as possible.
  • Page 14: Sealed System Requirements

    BOILER WATER CONNECTIONS SEALED SYSTEM REQUIREMENTS The boiler flow and return pipes are terminated with 2 x R2" BSP male connections at the rear of the appliance for the 604 Working pressure 6 bar maximum. and 605 models and DN65 for the others. Water returning from the system should be connected to the lower header pipe, with Particular reference should be made to BS.
  • Page 15: Electrical Connections

    ELECTRICAL CONNECTIONS Connection should be made in a way that allows complete isolation of the electrical supply - such as a double pole switch, Warning: This appliance MUST be earthed. having a 3mm (1/8") contact separation in both poles, or a A PERMANENT mains supply of 230V 50Hz is required.
  • Page 16: Wiring Diagram

    Wiring diagram...
  • Page 17: Sensor Locations

    Sensor locations...
  • Page 18: Commissioning Instructions

    COMMISSIONING INSTRUCTIONS Checks to be made at first lighting and after all maintenance operations that involved disconnection from the systems or an oper- ation on safety devices or parts of the boiler: Before lighting the boiler  Open any valves between the boiler and the system. ...
  • Page 19 SIEMENS Boiler Management Unit LMS 14 Heating mode DHW Control selection Information Reset Confirmation Chimney Sweep Escape Manual Operation + /- & Selection Commissioning Burner set up and flue gas analysis Flue gas analysis should be carried out at maximum and mini- mum rate.
  • Page 20: Gas Valve Adjustment

    GAS VALVE ADJUSTMENT Maximum rate adjustment  Switch the boiler on and operate for 10 minutes.  To ensure the boiler operates at maximum rate without modulating follow the instruction on page 19.  Insert the Flue Gas Analyser (FGA) probe into the test point. ...
  • Page 21: Servicing Instructions

    fitted it must never be shut off. Ferroli Ltd does not accept any liability resulting from the use Check the inner front and outer jacket panels are correctly of unauthorised parts or the repair and servicing of appliances fitted.
  • Page 22 Notes...
  • Page 24 FERROLI S.p.A. Via Ritonda 78/a 37047 San Bonifacio - Verona - ITALY www.ferroli.it...
