MLDV
Direct Vent Gas Fireplace
Model: MLDV500
Installation & Operating
Instructions
WARNING
IF THE INFORMATION IN THESE INSTRUCTIONS IS NOT
FOLLOWED ExACTLY, A FIRE OR ExPLOSION MAY
RESULT CAUSING PROPERTY DAMAGE, PERSONAL
INjURY OR LOSS OF LIFE.
–
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
–
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
–
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WARNING: Improper installation, adjustment, alteration,
services or maintenance can cause injury or property
damage. Refer to this manual. For assistance or additional
information consult a qualified installer, service agency
or the gas supplier.
This appliance may be installed in an aftermarket*,
permanently located, manufactured home (USA only) or
mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified
kit is used.
* Aftermarket: Completion of sale, not for purpose of resale, from the
manufacturer.
75d0004
MLDV cover
DUE TO HIGH TEMPERATURES, THE APPLIANCE
SHOULD BE LOCATED OUT OF TRAFFIC AND
AWAY FROM FURNITURE AND DRAPERIES.
CHILDREN AND ADULTS SHOULD BE ALERTED
TO THE HAZARDS OF HIGH SURFACE
TEMPERATURE AND SHOULD STAY AWAY TO
AVOID BURNS OR CLOTHING IGNITION.
YOUNG CHILDREN SHOULD BE SUPERVISED
WHEN THEY ARE IN THE SAME ROOM AS THE
APPLIANCE.
CLOTHING OR OTHER FLAMMABLE MATERIAL
SHOULD NOT BE PLACED ON OR NEAR THE
APPLIANCE.
KEEP THE ROOM AREA CLEAR AND FREE
FROM COMBUSTIBLE MATERIALS, GASOLINE,
AND OTHER FLAMMABLE VAPORS AND
LIqUIDS.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future refer-
ence.
75D0004 3/13 Rev. 15
Advertisement
Table of Contents
Related Manuals for Vermont Castings MLDV500
Summary of Contents for Vermont Castings MLDV500
- Page 1 MLDV Direct Vent Gas Fireplace Model: MLDV500 Installation & Operating Instructions WARNING IF THE INFORMATION IN THESE INSTRUCTIONS IS NOT FOLLOWED ExACTLY, A FIRE OR ExPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INjURY OR LOSS OF LIFE. – Do not store or use gasoline or other flammable...
-
Page 2: Table Of Contents
CONTENTS MLDV Series Gas Fireplace Thank you and congratulations on your purchase of a Vermont Castings Group Fireplace. PLEASE READ THE INSTALLATION AND OPERATION INSTRUCTIONS BEFORE USING THE APPLIANCE! IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION MLDV Series Gas Fireplace INSTALLER OWNER Please leave these instructions with the appliance. Please retain these instructions for future reference. • Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. •... -
Page 4: Code Approval
MLDV Series Gas Fireplace IMPORTANT SAFETY INFORMATION 1. Do not use this fireplace to cook food or burn paper or IMPORTANT: other objects. PLEASE READ THE FOLLOWING 13. Never place anything on top of fireplace. 14. Do not use any solid fuels (wood, coal, paper, card- CAREFULLY board, etc.) in this fireplace. -
Page 5: Product Specifications
PRODUCT FEATURES MLDV Series Gas Fireplace PRODUCT SPECIFICATIONS Insulation Board • This appliance has been certified for use with either natural or propane gas. See appropriate data plates. • This appliance is not for use with solid fuels. • The appliance is approved for bedroom or bed- sitting room installations. -
Page 6: Fireplace & Framing Dimensions
FIREPLACE and FRAMING DIMENSIONS MLDV Series Gas Fireplace 30 ” (784 mm) Min. Rough 20 ” 52 ” (1327 mm) Opening (524 mm) Depth 22 ” (565 mm) 22 ” (565 mm) 1/2” or 5/8” Min. Rough Opening Width (42 ” 91080 mm) Min. Rough Opening Height 6” (152 mm) ” 50 ” (246 mm) (1292 mm) 50 ” 38 ”... -
Page 7: Pre-Installation Information
INSTALLATION INFORMATION MLDV Series Gas Fireplace BEFORE YOU START FIREPLACE LOCATION Plan for the installation of your appliance. This includes Read this homeowner manual thoroughly and follow all determining where the unit is to be installed, the vent con- instructions carefully. Inspect all contents for shipping figuration to be used, framing and finishing details, and damage and immediately inform your dealer if any damage whether any optional accessories (i.e. -
Page 8: Clearances
CLEARANCES MLDV Series Gas Fireplace CLEARANCES TO COMBUSTIBLES Follow these instructions carefully to ensure safe installation. Failure to follow instructions exactly can create a fire hazard. The appliance cannot be installed on a carpet, tile or other combustible material other than wood flooring. -
Page 9: Secure Fireplace To Floor Or Framing
SECURE FIREPLACE TO FLOOR OR FRAMING MLDV Series Gas Fireplace The fireplace must be secured to the floor and/or to framing studs as shown in Figure 6. Use two () wood screws or DO NOT REMOVE INSULATION masonry/ concrete screws to secure fireplace to the floor. Use four (4) screws to attach fireplace to framing. -
Page 10: Venting Installation
• Installation of any damaged venting component. • Unauthorized modification of the venting system. • Installation of any component part not manufactured or approved by Vermont Castings Group. • Installation other than permitted by these instruc- tions. 75D0004... -
Page 11: Optional Top Vent Application
VENTING INSTALLATION MLDV Series Gas Fireplace OPTIONAL TOP VENT APPLICATION The appliance is shipped as a rear vent unit. If the installa- After conversion to top vent configuration, tion layout requires the unit to be a top vent configuration, the 5" (127 mm) flue pipe should be the appliance can be converted by following the steps concentric with the 8"... -
Page 12: Vent Pipe Clearances
VENTING INSTALLATION MLDV Series Gas Fireplace This fireplace must be vented to the Horizontal sections of this vent system outside. The venting system must NEVER require a minimum of 3” clearances to be attached to a chimney serving a separate combustibles at the top of the flue and 1”... -
Page 13: Installation Planning
VENTING INSTALLATION MLDV Series Gas Fireplace For two-story applications, firestops are required at each Read all instructions completely and floor level. If an offset is needed in the attic, additional pipe thoroughly before attempting installation. and elbows will be required. Failure to do so could result in serious injury, You may use a chase with a vent termination with exposed property damage or loss of life. -
Page 14: Termination Location
3. Vermont Castings Group assumes no responsibility for the only permitted if veranda, porch, deck or balcony is fully open on a improper performance of the appliance when the venting minimum sides beneath the floor: system does not meet these requirements. -
Page 15: Termination Clearances
VENTING INSTALLATION MLDV Series Gas Fireplace Termination Clearances Termination clearances for buildings with combustible and noncombustible exteriors. Inside Corner Alcove Applications* Outside Corner Combustible 6" (152 mm) Combustible 6" (152 mm) Noncombustible 2" (51 mm) Noncombustible 2" (51 mm) Balcony - Balcony - with no side wall with perpendicular side wall... -
Page 16: Rear Wall Vent Installation
Combustible Interior Walls: Cut a 1 " x 10 " hole behind the appliance. Only an Vermont Castings Group through the interior wall. brand termination is allowed for this application. Combustible Exterior Walls: Cut a 10 "... -
Page 17: Horizontal W/Vertical Rise Termination Config
All rear vent through-the-wall applica- When vent termination exits through foundations less than tions must use Vermont Castings Group- 0" below siding outcrop, the vent pipe must be flush with designed 5 x 8 square termination. No other the siding. - Page 18 VENTING INSTALLATION MLDV Series Gas Fireplace The horizontal vent run refers to the total length of vent • If a 90° elbow is used in the horizontal vent run (level pipe from the flue collar of the fireplace (or the top of the height maintained) the horizontal vent length is reduced Transition Elbow) to the face of the finished outside wall by 36".
- Page 19 VENTING INSTALLATION MLDV Series Gas Fireplace • " For each 45° elbow installed in the horizontal run, the length of the horizontal run MUST be reduced by 18" (67 mm (457 mm). This does not apply if the 45° elbows are installed on the vertical part of the vent system.
-
Page 20: Below Grade Installations
VENTING INSTALLATION MLDV Series Gas Fireplace " Screws (41 mm Firestop Minimum " 4" Clearance (41 mm Ground Window Well 1" Minimum Combustible Gravel Wall Drain " (190 mm Foundation Wall FP1954 Noncombustible Wall FP1965 Figure 26 - FP1954 Exterior Wall Framing Dimensions Figure 27 - wall framing for 4"... -
Page 21: Vertical Through-The-Roof Applications
VENTING INSTALLATION MLDV Series Gas Fireplace This Gas Fireplace has been approved for, VERTICAL THROUGH-THE-ROOF APPLICA- • Vertical installations up to 40' (1 m) in height. Up to TIONS a 10' (3 m) horizontal vent run can be installed within Install restrictor disc as shown in Figure 29 for vertically the vent system using a maximum of two 90°... -
Page 22: Installation For Vertical Termination
VENTING INSTALLATION MLDV Series Gas Fireplace • Two sets of 45°elbows offsets may be used within the INSTALLATION FOR VERTICAL vertical sections. From 0 to a maximum of 8' (.5 m) of TERMINATION vent pipe can be used between elbows. Figure 31 1. - Page 23 VENTING INSTALLATION MLDV Series Gas Fireplace Otherwise, install firestop below the framed hole. The 5. Place the flashing over the pipe section(s) extending firestop should be installed with no less than three (3) through the roof. Secure the base of the flashing to nails per side.
-
Page 24: Flex Vent Installation
FLEx VENT INSTALLATION MLDV Series Gas Fireplace 1. Flexible UL1777 listed venting may be used in any 1. Insert the long side of the 5" inner ring into venting application where rigid direct vent components exhaust pipe, gently tap to seat into place, and can be used. - Page 25 Clamp UL1777 Flex Vent Figure 39 - FP1975 Typical Pipe Connection Firestop pipe connection UL1777 Flex Vermont Castings PIpe Group Horizontal Vent Termination Screws DVFF8A/8 5" x 8" to (3 Places equidistant just 5" x 8" Flex Adapter above gear clamp) UL1777 Flex Vent 1C\v"...
- Page 26 Clamp UL1777 Flex Vent Figure 43 - FP1975 Typical Pipe Connection Firestop 4 x 7 pipe connection UL1777 Flex Vermont Castings PIpe Group Horizontal Vent Termination Screws 7TDVP58 5" x 8" to (3 Places equidistant just 4" x 7" Reducer...
-
Page 27: Fireplace Installation
FIREPLACE INSTALLATION MLDV Series Gas Fireplace CHECK GAS TYPE Use proper gas type for the fireplace you are installing. 100 gallon (min) If you have conflicting gas type, do not install fireplace. Propane/LP Supply External See dealer where you purchased the fireplace for proper Tank Regulator fireplace for your gas type or conversion kit. -
Page 28: Gas Line Installation
FIREPLACE INSTALLATION MLDV Series Gas Fireplace A manual shutoff valve must be installed Only persons licensed to work with gas upstream of the appliance. Union tee piping may make the necessary gas and plugged 1/8” NPT pressure tapping connections to this appliance. point should be installed upstream of the appliance. -
Page 29: Check Gas Pressure - Millivolt
CHECK GAS PRESSURE and ELECTRICAL INSTALLATION - MILLIVOLT MLDV Series Gas Fireplace 1. Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, STOP! Do not install the appliance. -
Page 30: Remote Wall Mounted Switch
REMOTE WALL SWITCH INSTALLATION MLDV Series Gas Fireplace REMOTE WALL MOUNTED SWITCH A remote wall switch and up to fifteen (15) feet of 18 Ga. wire may be used with this appliance. Attach the wall Do not connect wall switch 110V circuit. switch in a junction box at the desired location on the wall. - Page 31 OPTIONAL FAN/BLOWER SYSTEM MLDV Series Gas Fireplace 5. Remove hearth brick and wall brick panels. Start Position 6. Disconnect the gas line to the valve. 7. Remove screws securing engine base to firebox floor and lift engine up to remove. 8.
- Page 32 OPTIONAL FAN/BLOWER SYSTEM MLDV Series Gas Fireplace Variable Thermal White Fan Control Sensor (Hi Temp) Blower Motor 110/115V AC Black Blower Plug Black Blower White Green Motor White Figure 55 - Blower Wiring Diagram Electrical Grounding Instructions: This appli- ance is equipped with a three-prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly FP1910...
-
Page 33: Operating Instructions - Millivolt
OPERATING INSTRUCTIONS - MILLIVOLT MLDV Series Gas Fireplace FOR YOUR SAFETY READ BEFORE LIGHTING If you do not follow these instruction exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with a pilot which must be lit with built-in piezo ignitor while following these instructions exactly. -
Page 34: Lighting Pilot
OPERATING INSTRUCTIONS - MILLIVOLT MLDV Series Gas Fireplace LIGHTING PILOT FOR THE FIRST TIME APPROVED LEAK TESTING METHOD If using a soap and water You may check for gas leaks with the following methods solution to test for leaks, DO only: NOT spray solution onto control body. -
Page 35: Lighting Burner
OPERATING INSTRUCTIONS - MILLIVOLT MLDV Series Gas Fireplace LIGHTING BURNER MAIN BURNER SWITCH The “ON/OFF/RS” switch for the main burner can be found behind door of the fireplace. This switch allows you to turn on and to turn off the main burner without using the gas valve knob. Make sure the button is in the “ON”... -
Page 36: Checking Gas Pressure - Scs
CHECK GAS PRESSURE and ELECTRICAL INSTALLATION - SIGNATURE COMMAND MLDV Series Gas Fireplace 1. Check gas type. The gas supply must be the same as Pressure Inlet stated on the appliance’s rating decal. If the gas supply is different from the fireplace, STOP! Do not install the appliance. -
Page 37: Junction Box Wiring
ELECTRICAL INSTALLATION MLDV Series Gas Fireplace jUNCTION BOx WIRING 1. This should be done before framing the fireplace. Wire the receptacle into an electrical circuit. Wire with mini- mum 60° C wire in accordance with prevailing codes. . Remove the external junction box cover by removing the screw from the side of the outside firebox wall. -
Page 38: Signature Command Wiring Diagram
ELECTRICAL INSTALLATION MLDV Series Gas Fireplace Optional To Junction Box AC Module in Fireplace Pilot Optional White Light Black Optional White Blower Black White Optional Black Aux. Green Connector Pin To Control Board Input 300 Watt Max. Each Optional A/C Module Replaces 6V Adapter When Used RF Receiver ON/OFF Button Control Board 6V AC Black / Thermopile Adapter Red / Thermopile Sensor Conversion NG/LP Ignitor / Sparker Plug-in Connector Control Board to Command Center OFF/LO... -
Page 39: Optional Fan/Blower System - Scs
OPTIONAL FAN BLOWER SYSTEMS MLDV Series Gas Fireplace Electrical Grounding Instructions: This Electrical connections should only be appliance is equipped with a three-prong performed by a qualified licensed electrician. (grounding) plug for your protection against Main power supply must be turned off before shock hazard and should be plugged directly connecting the fan to the main electrical into a properly grounded three-prong... -
Page 40: Blotsdv
MLDV Series Gas Fireplace OPTIONAL FAN BLOWER SYSTEMS BLOTSDV AUTOMATIC THERMOSTAT BLOWER 120VAC Receptacle Junction BLACK GREEN WHITE BLACK WHITE BLACK BLACK Speed Control Figure 60 - BLOTSDV Blower Wiring Diagram FP685 Before installing the blower, wire the receptacle into an electrical circuit. -
Page 41: Operating Instructions - Scs
OPERATING INSTRUCTIONS - SIGNATURE COMMAND MLDV Series Gas Fireplace FOR YOUR SAFETY READ BEFORE LIGHTING If you do not follow these instruction exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with an ignition device which automatically lights the pilot. Refer to the instructions. -
Page 42: Operating Instructions
OPERATING INSTRUCTIONS - SIGNATURE COMMAND MLDV Series Gas Fireplace OPERATING INSTRUCTIONS 1. STOP! Read the safety information above. . This appliance is equipped with an ignition device which automatically lights the burner. Do not try to light the burner by hand. 3. -
Page 43: Signature Command System Operation
SIGNATURE COMMAND SYSTEM OPERATION INSTRUCTIONS MLDV Series Gas Fireplace FEATURES To Thermopile RF Receiver Command Center ON/OFF To Sensor • Easy Access Function Operation and System Configura- To Sparker tion • Operation Confirmation/Fault Diagnostic Indications NG/LP (LED/Buzzer) Conversion • ON/OFF/HI/Med/Low Operation •... - Page 44 SIGNATURE COMMAND SYSTEM OPERATION INSTRUCTIONS MLDV Series Gas Fireplace SYSTEM CONFIGURATION/SETUP NOTE: By disabling this feature, your fireplace may con- All System configuration/setup is done on the Command Center. tinue to operate unattended. . When the master switch is in the ON position (“-”), press- NOTE: When using On/Off wall switch, the switch must be ing the ON button and the OFF button on the Command in the ON position to perform all configuration set ups at...
-
Page 45: Signature Command System Operation Instructions
SIGNATURE COMMAND SYSTEM OPERATION INSTRUCTIONS MLDV Series Gas Fireplace FUNCTIONS/OPERATION . Press the OFF button to decrease flame height. The first Turning on the fireplace two presses will decrease the flame height to medium and low. 1. Turn on the master switch and wait for a beep. 3. -
Page 46: Final Installation
GLASS REMOVAL and BRICK INSTALLATION MLDV Series Gas Fireplace GLASS FRAME REMOVAL 1. Remove access panel by lifting up and out. . Release three (3) clamps on bottom of fireplace. Figure 62 3. Tilt glass frame out and lift glass frame up until it clears hook on top of fireplace. -
Page 47: Rockwool Placement
LOGS and ROCK WOOL INSTALLATION MLDV Series Gas Fireplace 1. Distribute one layer of rock wool to cover all round burner ports. Do not cover rectangular slots, located in front and rear. Figure 64 FP1983 Figure 64 - Rock Wool Placement on Burner. FP1983 MLDV rock wool place . -
Page 48: Log Installation
LOG INSTALLATION MLDV Series Gas Fireplace 3. Place log # at angle across the Log # burner by setting the logs over the two pins located on top of the burner. Figure 66 Figure 66 - Install Log #2 LG544 Log #3 4. - Page 49 LOG INSTALLATION MLDV Series Gas Fireplace 6. Place log #5 by matching the rectan- gular notch on the bottom of the log with the rectangular protrusion on log #, then set the notch on the bottom of this log over the very far left tong on the grate.
-
Page 50: Cleaning And Maintenance
CLEANING and MAINTENANCE MLDV Series Gas Fireplace Thermocouple Sensor Turn off gas before servicing fireplace. It is recommended that a qualified service Thermopile technician perform these check-ups at the beginning of each heating season. BURNER, PILOT AND CONTROL COMPART- MENT Keep the control compartment, logs, and burner areas surrounding the logs clean by vacuuming or brushing at FP1943... -
Page 51: Vent System
CLEANING and MAINTENANCE MLDV Series Gas Fireplace LOGS VENTING SYSTEM Leave logs installed in the fireplace for cleaning. Vacuum The fireplace and venting system should be inspected surface of the logs with a brush attachment. If logs must be before initial use and at least annually by a qualified field removed for cleaning, handle carefully by holding gently at service person. -
Page 52: Troubleshooting
TROUBLESHOOTING MLDV Series Gas Fireplace STANDING PILOT IGNITION MILLIVOLT SYSTEM SYMPTOM POSSIBLE CAUSE ACTION 1. Spark ignitor will A. Wire disconnected. A. Open door and check to make sure wire is connected to not light pilot after ignitor. repeated triggering B. - Page 53 TROUBLESHOOTING MLDV Series Gas Fireplace STANDING PILOT IGNITION MILLIVOLT SYSTEM SYMPTOM POSSIBLE CAUSE ACTION 4. Frequent pilot A. Pilot flame may be too high A. Clean and adjust the pilot flame for maximum flame outage problem. or too low, causing pilot impingement on thermocouple.
-
Page 54: Signature Command System
TROUBLESHOOTING MLDV Series Gas Fireplace SIGNATURE COMMAND SYSTEM ACTION OPERATION FAULT DIAGNOSIS Using Battery polarity wrong? Re-install batteries battery? Make sure Command Install batteries and/or Battery voltage low? Change batteries Center and plug in the AC board No beep in about the control 8 seconds board are... -
Page 55: Replacement Parts
REPLACEMENT PARTS MLDV Series Gas Fireplace FIREBOx COMPONENTS and ACCESSORIES Item Description qty. MLDV500 Standard Features Junction Box Assembly (not shown) 6D18K 75D0004 Control Cover 74D0119 MLDV parts Glass Frame Assembly 75D1016 Insulation Board 75D0008 Accessories/Field Installed Options Eyebrow 030777 Decorative Mesh Glass Cover (not shown) -
Page 56: Logs
REPLACEMENT PARTS MLDV Series Gas Fireplace LOGS Item Description qty. MLDV500 Log #1 75D0536 Log # 75D0537 Log #3 75D0538 Log #4 75D0539 Log #5 75D0540 Log #6 75D0541 Log #7 75D054 75D0004... -
Page 57: Standing Pilot Millivolt Control
REPLACEMENT PARTS MLDV Series Gas Fireplace STANDING PILOT - MILLIVOLT CONTROL 11,12, 13, 14, 15 0004 MLDV control parts 75D0004... - Page 58 Thermostatic Remote Control RCST/RCT/WWTD/RCSTEB/RCSITE On/Off Remote Control RCB/RCBE/RCMT/WMTD Full Function Remote Control RCSTEB/RCSITE Wall Switch MVWS Wired Thermostat Kit Fuel Conversion Kits - Millivolt Control Natural Gas to LP MLDV500 Kit #ML500CKP LP to Natural Gas MLDV500 Kit #ML500CKN 75D0004...
-
Page 59: Signature Command System
REPLACEMENT PARTS MLDV Series Gas Fireplace SIGNATURE COMMAND SYSTEM 13,14,15,16,17 0004 SG parts 8/08 75D0004... - Page 60 SCS AC Module (Opt. Blower, Light & Aux. Control) SCSACM NOTE: TSFSC must be used with SCS A/C Module to control blower, lights and aux. Fuel Conversion Kits - Signature Command System Natural Gas to LP MLDV500 Kit #ML500CKPS LP to Natural Gas MLDV500 Kit #ML500CKNS 75D0004...
-
Page 61: Venting Components
VENTING COMPONENTS MLDV Series Gas Fireplace 0004 MLDV vent parts For more information about, or instructions for, the venting components referenced above, please contact the component manufacturer: Selkirk Corporation: www. selkirkcorp.com or 800-99-8368 Duravent: www. duravent.com or 800-835-449 75D0004... - Page 62 MLDV Series Gas Fireplace VENTING COMPONENTS VENT COMPONENTS FOR 4" x 6B\," Current Duravent Duravent or Vermont or Vermont qty./ Castings Group Castings Group Selkirk Item Box Description Part no. Part no. Part no. Thru-roof Flexible Pipe Termination Kit with flex adapter TRFK 4"...
- Page 63 VENTING COMPONENTS MLDV Series Gas Fireplace VENT COMPONENTS FOR 5" x 8" Current Duravent Duravent or Vermont or Vermont qty./ Castings Group Castings Group Selkirk Metal-Fab Item Description Part no. Part no. Part no. Part no. Horizontal Termination Cap w/Built-In Vinyl Siding BHR58TK9 Standoff Heat Deflector, Firestop and Adjustable Pipe 11"...
-
Page 64: Vent Components
VENTING COMPONENTS MLDV Series Gas Fireplace HORIZONTAL VENTING - 4" x 7" Description Model Number Horizontal Vent Termination Kits Rear Vent Hot Touch Termination Kit w/ 10" to 16" 7TBRHTK Adjustable Termination Pipe, Firestop, and Hot Touch Termination w/ Siding Shield Up and Out Side Wall Termination Kit w/ 10"... - Page 65 VENTING COMPONENTS MLDV Series Gas Fireplace VERTICAL VENTING - 4" x 7" Description Model Number Vertical Vent Termination Kits Vertical Vent Termination w/ Storm Collar 7TDVSKV (flashing NOT included) Vertical Vent Termination w/ Storm Collar - 8 pack 7TDVSKV/8 (flashing NOT included) Vertical Vent Termination w/ 1/1 - 6/1 Flashing, Storm 7TDVSKVA* Collar and Ceiling Support Kit...
-
Page 66: Massachusetts Residents Only
MLDV Series Gas Fireplace Massachusetts Residents Only — Please read and follow these special requirements NOTE REGARDING VENTED PRODUCTS . Approved Carbon Monoxide Detectors. Each carbon This product must be installed by a licensed plumber or gas fitter monoxide detector as required in accordance with the above when installed within the Commonwealth of Massachusetts. -
Page 67: Warranty
You may also have additional rights not covered in the Limited Lifetime Warranty. Vermont Castings Group reserves the right to investigate any and all the claims against the Limited Lifetime Warranty and decide upon method of settlement. -
Page 68: Efficiencies
D.O.E. Fireplace Efficiency (%) (AFUE%) MLDV500NV 70.5 67.1 MLDV500PV 76.4 67.3 Recherchez dans la brochure les caractéristique de rendement énergétique de foyer au gaz Énerguide Selon CSA P.4.1-09 Based on CSA P.4.1-09 Vermont Castings Group 149 Cleveland Drive • Paris, Kentucky 40361 www.vermontcastingsgroup.com...
