MONACO MOTORHOME LIMITED WARRANTY
If you use your Monaco® motorhome only for recreational travel and family camping purposes, the
Limited Warranty provided by Monaco ("Warrantor") covers your new motorhome when sold by an
authorized dealer, for twelve (12) months from the original retail purchase date or the first 24,000
miles of use, whichever occurs first. However, the Limited Warranty provided by Warrantor covers the
steel or aluminum frame structure of the sidewalls (excluding slide outs), roof, and rear and front walls
for sixty (60) months from the original retail purchase date or the first 50,000 miles of use, whichever
occurs first.
If you use your motorhome for any rental, commercial or business purposes whatsoever, the
Limited Warranty provided by Warrantor covers your new motorhome when sold by an authorized
dealer for ninety (90) days from the original retail purchase date or the first 24,000 miles of use,
whichever occurs first. In addition, the Limited Warranty provided by Warrantor covers the steel or
aluminum frame structure of the sidewalls (excluding slide outs), roof, and rear and front walls for
twelve (12) months from the original retail purchase date or the first 24,000 miles of use, whichever
occurs first. A conclusive presumption that your motorhome has been used for commercial and/or
business purposes arises if you have filed a federal or state tax form claiming any business tax benefit
related to your ownership of the motorhome.
The above Limited Warranty coverage applies to all owners, including subsequent owners, of the
motorhome. However, a subsequent owner must submit a warranty transfer form by filing the form
through an authorized Monaco dealer. A subsequent owner's warranty coverage period is the remaining
balance of the warranty coverage period the prior owner was entitled to under this Limited Warranty.
Warranty transfer forms can be obtained by contacting the Customer Relations Department. There is
no charge for the transfer.
The Executive 2005
WARRANTY - LIMITED: THE EXECUTIVE 2005 . . . . . . . . . .1
WARRANTY - LIMITED: 2005 ROADMASTER CHASSIS . . .6
WARRANTY INFORMATION FILE . . . . . . . . . . . . . . . . . . . .10
- LIMITED: THE EXECUTIVE 2005
WARRANTY
1
Warranty

Advertisement

Table of Contents
loading

Summary of Contents for Monaco Executive 2005

  • Page 1 WARRANTY - LIMITED: THE EXECUTIVE 2005 ..1 WARRANTY - LIMITED: 2005 ROADMASTER CHASSIS . . .6 WARRANTY INFORMATION FILE ....10...
  • Page 2 "good will" repairs, which shall not alter the express terms of this limited warranty. Warrantor may use new and/or remanufactured parts and/or components of substantially equal qual- ity to complete any repair. Warranty The Executive 2005...
  • Page 3 Warrantor prior to incurring the towing charges to receive directions to the nearest repair facility. Because Warrantor does not control the scheduling of service work by its authorized servicing deal- ers, you may encounter some delay in scheduling and/or in the completion of the repairs. Warranty The Executive 2005...
  • Page 4 DENT OF, AND SHALL SURVIVE, ANY FAILURE OF THE ESSENTIAL PURPOSE OF ANY LIMITED REMEDY. Some states do not allow the exclusion or limitation of consequential or inci- dental damages, so the above exclusions may not apply to you. Warranty The Executive 2005...
  • Page 5 THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE. 101503 Warranty The Executive 2005...
  • Page 6 Limited Warranty. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Warranty The Executive 2005...
  • Page 7 Warrantor directly in writing of the failure to successfully repair the defect(s) so that Warrantor can become directly involved in exercising a final repair attempt for the purpose of performing a successful repair to the identified defect(s). Warranty The Executive 2005...
  • Page 8 (See Owner's Manual), damage caused by off road use, collision, fire, theft, vandalism, explosions, overloading in excess of rated capacities, and odometer tampering shall discharge Warrantor from any express or implied warranty obligation to repair any resulting defect. Warranty The Executive 2005...
  • Page 9 THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE. ROADMASTER CHASSIS DIVISION MONACO COACH CORPORATION 91320 COBURG INDUSTRIAL WAY COBURG, OREGON 97408 101503 Warranty The Executive 2005...
  • Page 10 The foregoing is not a warning. See the Limited Warranty or call (877) 466-6226 for warranty information and limitations. Warranty The Executive 2005...
  • Page 11 The Executive 2005 Sections General Information ~ 1 Driving & Safety ~ 2 Exterior & Interior Care ~ 3 Appliances ~ 4 Equipment ~ 5 Water Systems ~ 6 LP-Gas Systems ~ 7 Electrical Systems - House ~ 8 Electrical Systems - Chassis ~ 9...
  • Page 12 ©Copyright Monaco Coach Corporation. All rights reserved. Executive is a registered trademark of Monaco. All other trademarks or registered trademarks are property of their respective holders. Brand name products of other companies mentioned in this manual are not endorsed by the manufacturer of the motorhome.
  • Page 13: Table Of Contents

    The Executive 2005 General Information Section 1 SAFETY LEGEND............15 INTRODUCTION ............17 CUSTOMER RELATIONS..........18 REPORTING SAFETY DEFECTS ........18 TAKING DELIVERY ............18 Monaco Responsibilities..........18 Dealer Responsibilities..........19 Customer Responsibilities ........19 SERVICE SUGGESTIONS..........19 Prepare for the Appointment ........20 Prepare a List ............20 Be Reasonable With Your Requests ......20 No Looking Over the Technician’s Shoulder .....20...
  • Page 15: Safety Legend

    Owner’s Manual. Also refers to the WAR- RANTY INFORMATION FILE, found within the Warranty Information Box inside the motorhome. TIP: Information regarding helpful hints and/or suggestion for ease of operation of the motorhome and/or its components. General Information --- Section 1 The Executive 2005...
  • Page 17: Introduction

    Additional Information: www.monaco-online.com Changes, additions and supplemental information Click on Monaco, then click on ENTER to enter the in the form of Manual Addendums and “Tech main web page. Point on the SERVICE link and Tips” can be obtained by visiting our Website at choose OWNERS MANUAL ADDENDUMS from the www.monaco-online.com.
  • Page 18: Customer Relations

    National Highway Traffic Safety Administration (NHTSA) in addition to notifying Monaco. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of motorhomes, it may order a recall or remedy campaign.
  • Page 19: Dealer Responsibilities

    Monday and Friday are busy days for most dealers. Therefore, it makes sense to make a mid-week appointment whenever possible. Ask your dealer if addi- tional time is needed for check in and completion of paperwork. General Information --- Section 1 The Executive 2005...
  • Page 20: Prepare For The Appointment

    Check out the service or repair job when you pick up your motorhome and notify the service manager of any dissatisfaction. If circumstances prevent returning for immediate corrective work, make an appointment as soon as possible. Section 1 --- General Information The Executive 2005...
  • Page 21: Glossary Of Terms

    Current - The rate of flow of electricity or the movement rate of electrons along a conductor. It is comparable to the flow of a stream of water. The unit of measure for current is the ampere. General Information --- Section 1 The Executive 2005...
  • Page 22 Egress Window - The formal name for the emergency window located in the rear of the motorhome. Egress windows can be easily identified by their red handles. Full Hook-Up Site - A campground that has city water, shore power and sewer hook-ups or connec- tions available. Section 1 --- General Information The Executive 2005...
  • Page 23 Roadside - This refers to the side of the motorhome which faces the road when it is parked. Often called the off-door side or the driver’s side. General Information --- Section 1 The Executive 2005...
  • Page 24 Wet Cell Battery - A type of battery that uses liquid as an electrolyte. This type of battery requires periodic maintenance such as cleaning the connections and checking the electrolyte level. Section 1 --- General Information The Executive 2005...
  • Page 25: Vendor List

    Carbon Monoxide Detector Leece-Neville Safe-T-Alert 800-346-8093 800-383-0269 www.prestolite.com www.safe-t-alert.com Aqua-Hot (Optional) Citizen Band Radio Vehicle System Cobra 800-685-4298 733-889-3087 www.hydro-hot.com www.cobraelec.com Awnings (Optional) Collision Warning System (Optional) Carefree Eaton Vorad 800-621-2617 800-826-4357 www.carefreeofcolorado.com www.truck.eaton.com General Information --- Section 1 The Executive 2005...
  • Page 26 Filters - Coolant/Fuel/Oil/Hydraulic DVD Player - Bedroom Detroit Power Cool/ Power Gaurd Panasonic 800-445-1980 800-211-7262 www.detroitdiesel.com www.panasonic.com Fleetguard Engine 800-223-4583 Cummins 800-22Filter 800-343-7357 www.fleetguard.com www.cummins.com Racor Fluid Filters 800-344-3286 www.parker.com/racor/ Section 1 --- General Information The Executive 2005...
  • Page 27 Wilsonart 800-558-5700 800-433-3222 www.insinkerator.com www.wilsonart.com Inverter Navigation System Xantrex Pioneer 360-435-8826 800-746-6337 www.traceengineering.com www.pioneerelectronics.com Keyless Entry Outside Mirrors Essex Electronics Velvac Mirror 800-539-5377 800-783-8871 www.keyless.com www.velvac.com Leveling Jacks - Hydraulic (Optional) 760-746-5732 General Information --- Section 1 The Executive 2005...
  • Page 28 MTI Industries, Inc. www.alliedsafe.com 800-383-0269 www.mtiindustries.com Satellite Radio (Optional) Sirius Solar Panels (Optional) 1-888-539-7474 RV Solar Consultants www.siriusradio.com 541-937-9812 www.amsolar.com Satellite Systems (Optional) Steering Gear 888-584-4163 www.kvh.com 615-444-6110 www.trw.com Tracstar 407-650-9054 www.tracstar.com Section 1 --- General Information The Executive 2005...
  • Page 29 Tires Wheels - Aluminum Goodyear Tire & Rubber Accuride 800-321-2136 800-626-7096 www.goodyear.com www.accuridecorp.com Toilet Windshield Wipers Sealand Diesel Equipment 800-321-9886 800-632-4959 www.sealandtechnology.com www.dieselequipment.com Transfer Switch ESCO 574-264-4156 Transmission Allison Transmission 800-524-2303 www.allisontransmission.com General Information --- Section 1 The Executive 2005...
  • Page 30 NOTES Section 1 --- General Information The Executive 2005...
  • Page 31: Limited Warranty Transfer Application

    SELLING DEALER SIGNATURE TERMS & REPRESENTATIONS By your signature(s) on this form, and in order to induce Monaco Coach Corporation to transfer its Limited Warranty, you represent the following: 1. That you have received and read a copy of the Limited Warranty.
  • Page 33 The Executive 2005 Driving & Safety Section 2 DRIVING & SAFETY ............35 TIRES................76 Inspections..............35 Importance of Air Pressure........77 Familiarize Yourself ..........35 Tire Pressure Inflation Guideline.......78 Mirror Adjust (Manual) ..........35 Tire Chart - Goodyear..........78 Safety Seat Belts .............37 Inspecting & Pressure ..........80 Driving Tips .............40...
  • Page 35: Driving & Safety

    Mirror Adjust (Manual) Prior to starting out, adjust mirrors. It is recommended have an assistant help with the adjustments to prevent damage to the mirror or the motorhome. Driving & Safety --- Section 2 The Executive 2005...
  • Page 36 Use the mirror select and adjust switch 070181g located on the roadside console to fine Mirror with optional “See Vision” camera tune the view. 080378 Mirror Adjust Switch 080452 Mirror Select Switch Section 2 --- Driving & Safety The Executive 2005...
  • Page 37: Safety Seat Belts

    Individual states and Canadian provinces may have laws that can exceed the require- ments described above. It is your obligation to know and comply with the laws in the state or province in which you travel. Driving & Safety --- Section 2 The Executive 2005...
  • Page 38 The top of the head must be below the top of the safety seat. Secure safety seat harness straps at or below the shoul- ders. (See Example 1). 020231b Example 1: Convertible Seat Facing to the Rear. Section 2 --- Driving & Safety The Executive 2005...
  • Page 39 Do not disassemble or modify the system. Replace the seat belt assembly after a severe impact, even when damage is not obvious. Driving & Safety --- Section 2 The Executive 2005...
  • Page 40: Driving Tips

    Keep in mind that road surfaces may be repaved or packed with snow; therefore, the actual posted clearance height would not apply in such conditions. Section 2 --- Driving & Safety The Executive 2005...
  • Page 41 • Do not start the turn until the center of the intersection is reached with your hips. If there are two lanes available, take the right hand lane. A car or driver on the left hand side is easier seen. Driving & Safety --- Section 2 The Executive 2005...
  • Page 42 Do not "pump" the brakes as this can result in a loss of air pressure. Avoid "riding" the brakes as this can cause the brakes to overheat. Either method can result in loss of brake effectiveness or brake failure. Section 2 --- Driving & Safety The Executive 2005...
  • Page 43 Wet Conditions: • Worn or improperly inflated tires can increase the risk of hydroplaning. • Heavy rain or deep standing water can affect brake application causing brakes to apply unevenly or grab. Driving & Safety --- Section 2 The Executive 2005...
  • Page 44 Store the extra pair of shoes near the entry door. WARNING: Avoid the risk of fire or explosion. Turn off all pilot lights and appliances before enter- ing a refueling station. Section 2 --- Driving & Safety The Executive 2005...
  • Page 45: Collision Warning System (Opt)

    The CPU is also capable of storing digital information similar to the 'black box' used on air- craft. INFORMATION: Refer to the manufacturer’s manual for more detail on the CWS components and their operation. Driving & Safety --- Section 2 The Executive 2005...
  • Page 46: Driver Display Unit

    • A repeated alarm will sound, regardless of motorhome speed, when the motorhome and potential hazard are within one-half second of collision. Section 2 --- Driving & Safety The Executive 2005...
  • Page 47: Smart Cruise

    The proximity alert is activated when the motorhome is moving up to two miles per hour and an object is detected less than 15 feet in front of the motorhome. In this case, the yellow light comes on, accompanied by a low-pitch tone. Driving & Safety --- Section 2 The Executive 2005...
  • Page 48: Side Sensors

    Interpretation of curves, dips and hills can influence the Eaton Vorad CWS system alerts. The fol- lowing road situations may help you to better understand how to safely and effectively use the Collision Warning system. 020284h Section 2 --- Driving & Safety The Executive 2005...
  • Page 49 When approaching a curve, alerts may sound and illuminate if there is an object on the side of a curved portion of the road that lies in a direct line with the motorhome prior to entering the curve. 020284f Driving & Safety --- Section 2 The Executive 2005...
  • Page 50 020284d The antenna assembly cannot detect objects above its beam, causing vehicles ascending a hill to go undetected. Generally, the alarm will not sound from deflecting the road surface. 020284c Section 2 --- Driving & Safety The Executive 2005...
  • Page 51: Data Recorder

    WARNING: The Eaton Vorad System is a tool to enhance, not substitute for safe driving practices. The driver is ultimately responsible for safe operation of the motorhome. Driving & Safety --- Section 2 The Executive 2005...
  • Page 52: Pre-Trip Preparations - Checklist

    • Secure loose, heavy or sharp objects in case of a sudden stop. • Close all cabinet doors and drawers. • Walk the interior and check for items not secured. • Test appliances before leaving home. • Turn interior lighting off. Section 2 --- Driving & Safety The Executive 2005...
  • Page 53 • Check fuel level gauge. Fill the fuel tank if necessary. • Check all other dash gauges for operation and correct level indications. • Secure and lock the entry door for travel. • Lower the antenna. Driving & Safety --- Section 2 The Executive 2005...
  • Page 54 • Secure loose items to prevent weight shifts that could affect the balance of the motorhome. TIPS: Multi-purpose items, versatile clothing and periodic removal of unused cargo will streamline cargo storage. Section 2 --- Driving & Safety The Executive 2005...
  • Page 55: Hitch

    Overloading the hitch receiver can cause unusual handling characteristics and over- stress the hitch receiver and chassis. It could also void the warranty. If there are any questions, call a factory technician. 100200 Driving & Safety --- Section 2 The Executive 2005...
  • Page 56: Tow Plug Connection

    LEFT TURN & STOP for use when towing a trailer BROWN WIRE- equipped with a battery. The posi- TAIL LIGHTS tive terminal maintains the charge of the trailer battery. WHITE WIRE- GROUND 080462b Section 2 --- Driving & Safety The Executive 2005...
  • Page 57: Rear View System

    NOTE: The rear camera will automatically display when the motorhome is placed in reverse. NOTE: The radio systems operate with the radio remote control or from the radio touch screen labels. Driving & Safety --- Section 2 The Executive 2005...
  • Page 58: See Vision (Opt)

    As an aid in guidance when backing, select either right or left turn signal to display the desired camera for a more complete view. Cancel the turn signal to return to rear view. 080377d Section 2 --- Driving & Safety The Executive 2005...
  • Page 59: Backing Up A Motorhome

    The directional signal given should remain steady until the desired movement is complete. Driving & Safety --- Section 2 The Executive 2005...
  • Page 60 Never attempt short back up distances with a tow bar or tow dolly. Damage to the motorhome, vehicle or towing device will result. Section 2 --- Driving & Safety The Executive 2005...
  • Page 61: Set-Up Procedure Checklist

    If blocking up a rear jack pad to gain added clearance when the motorhome is on a slope, place a wheel chock at the opposite set of rear wheels to prevent the motorhome from rolling. Driving & Safety --- Section 2 The Executive 2005...
  • Page 62 Typical Power Pedestal electronic equipment may result! NOTE: To avoid shore power overload when hooked to 30 Amp service, determine appliances current load prior to turning on appliances or using interior outlets. Section 2 --- Driving & Safety The Executive 2005...
  • Page 63: Dry Camping Tips

    Drive-through sites are preferred for easier positioning of the motorhome and tow vehicle. If only back-in sites are available, disconnect the tow vehicle before entering the campground for easi- er maneuverability. Driving & Safety --- Section 2 The Executive 2005...
  • Page 64 • Frequently monitor water and battery consumption. Routinely check fuel levels, especially during cold weather temperatures. Section 2 --- Driving & Safety The Executive 2005...
  • Page 65 • Rope lights (10 ft) are a 1.3 Amp draw. • The porch light is a 2.0 Amp draw. • One fluorescent dual bulb light has a 2.1 Amp draw. • One halogen ceiling light has a .09 Amp. Driving & Safety --- Section 2 The Executive 2005...
  • Page 66: Breaking Camp

    • Inspect belts and hoses for wear. • Inspect wiring for loose, frayed or corroded connections. • Start engine and listen for unusual noises. • Inspect gauges and controls for proper operation. Section 2 --- Driving & Safety The Executive 2005...
  • Page 67: Emergency Roadside Procedures

    In the event of an emergency stop due to a mechanical breakdown or other motorhome related problems, contact the manufacturer’s Customer 020170 Support (1-877-466-6226) or an emergency serv- ice provider. Driving & Safety --- Section 2 The Executive 2005...
  • Page 68: Onstar® (Opt)

    In the event of motorhome breakdown, subscribers can contact an advisor at the call center. Concerns involving interior operations that do not impede travel should be made directly to the Monaco Coach Corporation Customer Service Department. 031039 ®...
  • Page 69: In Case Of Flat Tire

    Turn the ignition off and turn the hazard flasher system ON. Save the old tire for possible warranty coverage. 070175 INFORMATION: Goodyear emergency service number is 877-484-7376. Driving & Safety --- Section 2 The Executive 2005...
  • Page 70: Light - Retractable

    1. Add 30 gallons of fuel to the empty tank, possibly more if the motorhome is parked on an angle. 2. Follow the instructions "To Prime the Fuel System" located in the Fuel System/Fuel Filters of Section 10. Section 2 --- Driving & Safety The Executive 2005...
  • Page 71: Dead Chassis Battery

    • If the engine fails to crank, or does not crank fast enough, discontinue the attempt. Continued attempts will only diminish any remaining surface charge in the chassis battery and end future alternative attempts. Driving & Safety --- Section 2 The Executive 2005...
  • Page 72 If uncertain about performing a jump-start procedure, con- tact a professional. Damage and personal injury can occur if this procedure is not performed correctly. Section 2 --- Driving & Safety The Executive 2005...
  • Page 73 Voltage sensitive equipment on the towed vehicle can be damaged, leaving the towed vehicle disabled. If a jump-start is necessary, it is recom- mended to call Roadside Assistance. They will have the equipment necessary to jump- start the motorhome. Driving & Safety --- Section 2 The Executive 2005...
  • Page 74: Towing Procedures

    • Do not tow the motorhome from the rear. Towing from the rear will severely overload the front tires and suspension possibly resulting in tire and/or front suspension failure. Rear frame extensions are not designed to support weight loads imposed by lifting the motorhome from the rear. Section 2 --- Driving & Safety The Executive 2005...
  • Page 75: Brake - Disabling Parking Brake

    WARNING: Only trained personnel should perform this proce- dure. 090368 Properly chocked wheel. Driving & Safety --- Section 2 The Executive 2005...
  • Page 76: Tires

    To obtain the maximum wear and best service from tires, it is helpful to understand the components and functions of the tire. Section 2 --- Driving & Safety The Executive 2005...
  • Page 77: Importance Of Air Pressure

    Driving on a tire that is under-inflated can exceed the design limits of the tire and may damage the sidewall. A damaged sidewall can burst upon inflation resulting in serious damage, injury or death. Aged tires are also susceptible to sidewall damage. Driving & Safety --- Section 2 The Executive 2005...
  • Page 78: Tire Pressure Inflation Guideline

    Every load range has a maximum rating as well as a minimum rating. Do not exceed those ratings. Rated load capacities are listed for individual tires in a Dual or Single position. Section 2 --- Driving & Safety The Executive 2005...
  • Page 79 The motorhome manufacturer is not the author of this chart and makes no representation or warranty concerning the accuracy of the information disclosed by the chart. Monaco is not responsible for the accuracy of the information disclosed or for any errors within the Tire Inflation Chart.
  • Page 80: Inspecting & Pressure

    Always use an accurate tire pressure gauge when check- ing tire pressure. 090440 Example of Overinflation More wear in center. Section 2 --- Driving & Safety The Executive 2005...
  • Page 81 An air coupling is located in the LP-Gas tank compartment. This Type C fitting can be used to add air to the tires. Detailed informa- 020161 tion about this fitting is located in Section 10. Driving & Safety --- Section 2 The Executive 2005...
  • Page 82: Air Pressure Checklist

    9. Check the sidewalls to make sure there are no gouges, cuts, bulges, or other irregularities. NOTE: Air pressure in a tire goes up (in warm weather) or down (in cold weather) 1 to 2 pounds for every 10 degrees of temperature change. Section 2 --- Driving & Safety The Executive 2005...
  • Page 83: Supporting When Leveling

    CAUTION: Supporting the tires prevents damage to the sidewall of the tires and does not prevent tire roll. 020063b modified Driving & Safety --- Section 2 The Executive 2005...
  • Page 84: Tire Vibration

    Though the sidewall of the tire may look fine and be structurally sound, weathering can occur inside the well of the tread, therefore replacement may be deter- mined not by mileage but age. Have the tire manufacturer inspect the tires for age weathering. Section 2 --- Driving & Safety The Executive 2005...
  • Page 85: Storage Of Tires - Long Term

    If the pressure check indicates the tires have lost air during storage, inflate them to the correct pressure for the current load before putting the motorhome into service. Driving & Safety --- Section 2 The Executive 2005...
  • Page 86: Wheel Mounting

    Damage to the wheel or mounting system could cause a wheel to come off while the recreational vehicle is in motion. Section 2 --- Driving & Safety The Executive 2005...
  • Page 87 • If air wrenches are used they must be periodically calibrated for the proper torque output. Use a torque wrench to check the air wrench output and adjust the line pressure for the correct torque. 090268 copy 2 Driving & Safety --- Section 2 The Executive 2005...
  • Page 88: Weighing The Motorhome

    The GAWR is the maximum weight for which a single axle is designed. The tires, wheels, axle, motorhome frame and/or other components of the motorhome may limit these per axle and total maximum weight ratings. Section 2 --- Driving & Safety The Executive 2005...
  • Page 89 • Gross Axle Weight Rating (GAWR): Load-carrying capacity specified by manufactur- er of a single axle system, as measured at tire ground interfaces. • Sleeping Capacity Weight Rating (SCWR): The manufacturer's designated number of sleeping positions multiplied by 154 pounds. Driving & Safety --- Section 2 The Executive 2005...
  • Page 90 Pull knob up to Push down unlock. knob to lock. 090256 Tag Axle Regulator: Located in the Roadside Rear Engine Compartment. Section 2 --- Driving & Safety The Executive 2005...
  • Page 91 When weighing, the scales and the motorhome must be level to obtain an accurate scale reading. Even when an axle is not physically on the scale, a definite lean in the motorhome will produce inaccu- rate scale readings. Driving & Safety --- Section 2 The Executive 2005...
  • Page 92: Weight Label

    Weight Label 100179D Section 2 --- Driving & Safety The Executive 2005...
  • Page 93: Six-Point Weighing (Example)

    • Weigh the driver side rear corner (Scale B) and record weight on chart Scale B, line 2. Example: 7,100 lbs. • Weigh the passenger side rear corner (Scale E) and record weight on chart Scale E, line 2. Example: 6,900 lbs. 020152b Six-point Weighing Example Chart Driving & Safety --- Section 2 The Executive 2005...
  • Page 94 Tire pressure below the minimum inflation pressure can overheat and damage the tire casing leading to premature tire failure or blowout. Section 2 --- Driving & Safety The Executive 2005...
  • Page 95 14,000 20,000 6,000 5,000 5,000 10,000 4,500 4,000 8,500 10,000 1,500 31,500 43,000 11,500 NOTE: All measurements used should be with a full fuel tank and nobody in the motorhome. 020255g Driving & Safety --- Section 2 The Executive 2005...
  • Page 96 A 30-gallon LP-Gas tank will have 24 gallons of LP-Gas due to the 80% valve. This would mean 24 gallons multiplied by 4.2, or 100.8 pounds. 15,000 - 415 14,585 14,585 - 100.8 14,484.2 Section 2 --- Driving & Safety The Executive 2005...
  • Page 97 Label. • Compare wheel position weights with weight ratings on the label. If wheel position weights exceed maximum specifications, items will need to be removed until rating weight is within specification. Driving & Safety --- Section 2 The Executive 2005...
  • Page 98 020254 Section 2 --- Driving & Safety The Executive 2005...
  • Page 99 4,000 8,500 10,000 1,500 31,500 43,000 11,500 NOTE: All measurements used should be with a full fuel tank and nobody in the motorhome. 31,500 11,500 10,670 10,587 10,419 9,649 9,649 020255h Driving & Safety --- Section 2 The Executive 2005...
  • Page 100 NOTE: All measurements used should be with a full fuel tank and nobody in the motorhome. 020255h Section 2 --- Driving & Safety The Executive 2005...
  • Page 101 WEIGHT RECORD SHEET: 020262 020263 Driving & Safety --- Section 2 The Executive 2005...
  • Page 102 WEIGHT RECORD SHEET: 020262 Section 2 --- Driving & Safety The Executive 2005...
  • Page 103: Views

    VIEWS - Front 010689d Rear 010763d Driving & Safety --- Section 2 The Executive 2005...
  • Page 104: Roadside

    Roadside 010688c Curbside 010687e Section 2 --- Driving & Safety The Executive 2005...
  • Page 105: Security System (Opt)

    • A continuous light impact or a heavy impact will sound the alarm. • Opening the entry door, selected bay doors or a bedroom window will cause the siren to chirp for three seconds, followed by a continuous alarm. Driving & Safety --- Section 2 The Executive 2005...
  • Page 106 NOTE: A Warn Away chirp will not sound when the system is armed in Silent Mode. A heavy impact or opening the entry door will sound a continuous alarm. Section 2 --- Driving & Safety The Executive 2005...
  • Page 107 2. Turn the ignition OFF. 3. Access Valet/Program button on main dash panel near ignition. Press and hold the Valet/Program button ten seconds and release. 4. Ensure the LED is a steady glow. Driving & Safety --- Section 2 The Executive 2005...
  • Page 108 • A 24 hour support number is located on the back of the Key Fob. • The headlights will only flash when using the Key Fob. • The range of the remote Key Fob is approximately 1,200 feet. Section 2 --- Driving & Safety The Executive 2005...
  • Page 109 Dash. essary to advance to the desired feature. • Press the Valet/Program button and HOLD. Valet/Program Button on main dash panel near ignition. Valet/Program button & blue LED status light. Driving & Safety --- Section 2 The Executive 2005...
  • Page 110 OFF. Engaging this feature will force passive arming, even if a zone is left open or invalid. Automatic Engine Disable (AED) ON/OFF: *Not wired. Armed While Driving/Vehicle Recovery System (VRS): Turned *OFF. Section 2 --- Driving & Safety The Executive 2005...
  • Page 111 Ignition Controlled Dome light Supervision ON/OFF: *Not wired. Double Pulse Unlock ON/OFF: *OFF. Channel 3 Validity/Latched: Latched Rest with Ignition/30 Second. Timed/Second Unlock Output: *ON AUX Channel 3. NOTE: *Bold indicates the factory default settings. Driving & Safety --- Section 2 The Executive 2005...
  • Page 112: Smoke Detector

    When testing the smoke alarm it is advised to stand at arm’s length. CAUTION: Never use an open flame to test the smoke alarm. You may ignite and set fire to the alarm and to the motorhome. Section 2 --- Driving & Safety The Executive 2005...
  • Page 113: Maintenance

    Even low levels of CO have been known to cause brain and other vital organ damage in unborn infants, with no effect on the mother. Driving & Safety --- Section 2 The Executive 2005...
  • Page 114: Operation

    If the power is on and the connections are correct, but the indicator still does not light, the detector should be returned for service. Do not attempt to fix the detector. Section 2 --- Driving & Safety The Executive 2005...
  • Page 115: Alarm

    The alarm will sound four beeps and the indicator lamp goes steady red. Six seconds later the alarm will again beep four times and the indicator light goes steady green. Driving & Safety --- Section 2 The Executive 2005...
  • Page 116: Cleaning & Maintenance

    The CO detector has NO user service parts. If there is a problem with the detector refer to an authorized service center. DO NOT REMOVE POWER. INSPECT: Check the CO detector weekly and at the beginning and end of each trip. Section 2 --- Driving & Safety The Executive 2005...
  • Page 117: Fire Extinguisher

    C - Fires that involve energized electrical wiring or equipment. If electricity to the equipment is turned off, a class C fire becomes one of the other two class fires. 100209 Driving & Safety --- Section 2 The Executive 2005...
  • Page 118: Escape (Egress) Window

    The glass slider in the Egress window operates the same as all other windows in the motorhome. Occasionally open and close the Egress window to prevent the rubber seal from sticking. 020029 Section 2 --- Driving & Safety The Executive 2005...
  • Page 119 NOTES Driving & Safety --- Section 2 The Executive 2005...
  • Page 120 NOTES Section 2 --- Driving & Safety The Executive 2005...
  • Page 121 The Executive 2005 Exterior & Interior Care Section 3 EXTERIOR CARE ............123 WALL COVERINGS............147 Corrosion ..............123 WOOD CARE ...............148 Washing ..............123 COUNTERTOPS ............150 Drying ..............124 Solid Surface............150 Waxing ..............124 STAINLESS STEEL SURFACE ........151 Tire Care ...............125 WINDOWS ..............151 Wheels - Aluminum ..........126 Condensation ............151...
  • Page 123: Exterior Care

    If necessary, turn the motorhome around to keep the area being washed in the shade. Try not to allow the detergent to dry onto the clear coat surface. Use plenty of water when rinsing the surface to remove all detergent residue. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 124: Drying

    Polishes - Polishes usually contain a combination of wax based substances with an abrasive, getting the two for one idea. These products can be too abrasive for clear coats and are not recommended for use. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 125: Tire Care

    When these same dressing products are used on a passenger car tire that is replaced every three to four years, it is rare to see a major problem. However, in most cases recreational vehicle tires may last longer due to limited annual mileage and exposure. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 126: Wheels - Aluminum

    When using chemicals to remove road tars, use only automotive type products that are recommended for use on painted surfaces and fiberglass. Observe the warning recom- mendations and directions printed on the container of any agent being used. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 127: Exterior Maintenance

    All joints and seams should be inspected at least twice a year and recalked as nec- essary. WARNING: Some products may contain hazardous materials which require special handling. Read labels carefully. Follow all product manufacturer safety requirements. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 128 Spray Foam: This product is used as a sealant where a hole has been made for items such as water lines or wires that are coming through a floor opening. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 129: Interior Care

    To determine if the lens is glass or plastic, simply tap the lens with a fingernail. Plastic lens will have a dull hollow sound whereas glass will have a clear ping. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 130: Fabrics

    Water stains may become permanent and unable to be removed with solvent cleaning agents. Avoid products containing Carbon Tetrachloride as it is highly toxic. To help prevent overall soiling, frequent vacuuming or light brushing to remove dust and grime is recommended. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 131 • Grid Head press for short intervals with minimum steam. Do not lock the head. • Flat bed press dampened drapery using cloth covering. • Avoid prolonged contact with heat. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 132: Fabric Specifications Charts

    Fabric Specifications Charts Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 133 Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 134 Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 135 Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 136 Ralph Lauren Fabrics (Optional Package) Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 137 Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 138 Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 139: Vinyl

    Wash with diluted bleach and use a soft brush for stubborn growth. Rinse repeatedly with clear, cold water. Ballpoint Ink: Wipe the stain immediately with rubbing alcohol in a well ventilated area. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 140 Loose material should be gently scraped with a dull knife. Use lukewarm water and sponge repeat- edly. Any soiled area that remains after drying should be gently rubbed with a cloth, dampened with a mild detergent solution. Rinse thoroughly with clean water. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 141: Leather

    Allow to air dry or dry quickly with warm setting of hair dryer. Disinfect with 5:1 non-chlorinated bleach solution. Stubborn Spots and Stains: Use a mild solvent (Afta) with a clean cloth or sponge. Wipe with damp cloth and let dry. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 142: Floors

    Soot become permanent. Toothpaste Urine 1 4 3 2 5 6 Vomit * While recommended cleaning agents are effective, some stains may become permanent. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 143: Tile Floors

    NOTE: Tile is ceramic and will chip and break easily. Avoid dropping heavy or sharp objects on the tile. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 144 It is recommended to test a small amount of sealant on an inconspicuous area before applying to the entire floor. Avoid getting sealant onto surfaces other than the flooring. 070182 Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 145: Laminate Floor (Opt)

    Use a mixture of soap-free household cleaner (either vinegar or ammonia work well) and water for a more thorough cleaning. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 146: Shower

    Metals. Use a glass cleaner applied to a soft cloth to clean. Suede Fabric: Restore suede surfaces using a soft brush. Remove dust from the suede fabric using the soft brush attachment of a vacuum. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 147: Wall Coverings

    If the stain does not disappear, rinse the soapy area thoroughly with clean water. Mix a solution of 50% water and 50% household bleach. Clean the stained area with the bleach solution. Rinse with clean water. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 148: Wood Care

    When scratches appear lighter than the surrounding dark-stained woodwork, it usually means either that the scratch goes through the stain into the wood or that the varnish is flaking off. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 149 Commercial scratch removers, or stick wax to match the wood finish, can also be used. After the scratch has been hidden, polish or wax the entire area. Deep scratches should be repaired and finished by a professional. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 150: Countertops

    If contact is made, quickly wash with water. NOTE: Do not cut directly on the solid surface. When pouring boiling water into the Solid Surface sink, run cold water to prevent damage. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 151: Stainless Steel Surface

    • In very cold weather, leave cabinet and closet doors partially open. Air flow will warm and ventilate the interior storage compartments and exterior walls to reduce or eliminate condensation and prevent the possibility of ice formations. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 152: Window Treatments

    ¼ ounce clear liquid soap to 8 ounces water. NOTE: Do not use colored liquid soap as a stain may appear when fabric dries. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 153: Mold & Mildew

    For example, studies have shown that ozone cleaners are not effective at killing airborne mold or surface mold con- tamination. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 154 Limited Warranty coverage period provided. THE MANUFACTURER WILL NOT BE RESPONSIBLE FOR ANY DAMAGES CAUSED BY MOLD THAT MAY BE THE CONSE- QUENCE OF OR ASSOCIATED WITH DEFECTS IN THE CONSTRUCTION. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 155: Pest Control

    Prior to operating the motorhome after storage, remove all insect and animal nests that may have developed around vents, engine compartments, the exhaust pipe and in the wheel wells. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 156 Secure the wrap with tape or a rubber band and poke a ¼" hole in the plastic. Place the trap in the area where fruit flies are present. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 157 When calling on the services of a professional to combat pest infestation, call a reputable business that is licensed in handling pesticides. Check references. Explain that you are seeking assistance for a motorhome, as treatments may differ from standard household jobs. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 158: Storage

    Desiccate filter systems will help remove interior moisture. • If AC power is not available, turn the chassis battery disconnect switch OFF. • If possible, store the motorhome inside a storage building. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 159: Long Term

    Line voltage loss and the resistance at each electrical connec- tion is a hazardous combination and should be avoided. Damage to sensitive elec- tronic equipment may result! Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 160 Consult the engine manufacturer owner’s manual or a distributor for further detailed information on fuel stabilizers and additives. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 161: Winter Storage Checklist

    • Holding Tank - Drain and rinse. Close valves. LUBRICATION: Add a small amount of antifreeze to waste holding tanks to keep valves and gaskets lubricated. • Drain Traps - Pour RV antifreeze down all drains. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 162: Removal From Storage

    • Drain, sanitize and flush the fresh water system as outlined in the Water Systems - Section 6. Inspect the sewer drain hose and connections for leaks. Replace if necessary. Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 163 • If desired, have the dealer or repair center double-check preparation to make necessary adjustments and/or correct defects. Exterior & Interior Care --- Section 3 The Executive 2005...
  • Page 164 NOTES Section 3 --- Exterior & Interior Care The Executive 2005...
  • Page 165 The Executive 2005 Appliances Section 4 APPLIANCES - INTRODUCTION ........167 AIR CONDITIONING - ROOF ........186 REFRIGERATOR - NORCOLD ........167 Operations.............186 Operation Specifics ..........168 Heat Pump ............187 Control Panel............169 Return Air Filters............188 Icemaker ...............170 Auto Temp Start ............188 Refrigerator Alarm ..........171 AQUA-HOT ..............190...
  • Page 167: Appliances - Introduction

    To reduce the possibility of food spoilage, keep the interior box temperature at or below 54º F. The refrigerator will consume more energy to maintain low temperature, especially in hot, humid climates. Lower temperature may also lead to quicker frost build-up. Appliances --- Section 4 The Executive 2005...
  • Page 168: Operation Specifics

    • Figure C: If the controls do not light up, check the house bat- teries charge status or see if the 12 Volt DC wires are plugged into the refrigerator's circuit board (located outside 030967 behind refrigerator access door). 030974e Section 4 --- Appliances The Executive 2005...
  • Page 169: Control Panel

    “NO” “FL” displays. Turn the refrigerator off then back on. If the gas does not ignite after several attempts consult a dealer or authorized Norcold service center. Appliances --- Section 4 The Executive 2005...
  • Page 170: Icemaker

    F (+/- 5°). The water line heater is only for the line from the solenoid to the icemaker. The line from the icemaker shut-off valve to the water valve is not protected. 030974d Behind Exterior Refer Access Panel Thermal Disk Heater Tape Section 4 --- Appliances The Executive 2005...
  • Page 171: Refrigerator Alarm

    To engage the storage feature, partially open doors and 030965 slide tab into the cut-out of the strike plate. Storage Feature Appliances --- Section 4 The Executive 2005...
  • Page 172: Storage Procedures

    1. Remove the light cover by pulling it toward the front of the refrigerator. 2. Remove the light bulb from the holder. 3. Install a GE#214-2 replacement bulb and install the cover. 031116 Section 4 --- Appliances The Executive 2005...
  • Page 173: Service

    Ice can be dispensed as crushed or cubed. An infrared sensor prevents dispenser operation with the freezer door open. 031122 Controls NOTE: The refrigerator operates using a compressor, not from LP-Gas. Appliances --- Section 4 The Executive 2005...
  • Page 174 Do not use the first one or two trays of ice if the refrigerator has been in storage. Ice cubes may have contaminates. Do not operate the icemaker without water pressure supplied to the refrigerator. Damage to the icemaker assembly may occur. Section 4 --- Appliances The Executive 2005...
  • Page 175 A completely closed up refrigerator in storage is a perfect habitat for molds and bacteria to grow. NOTE: Consult the refrigerator owner's manual for more details. Appliances --- Section 4 The Executive 2005...
  • Page 176: Water Dispenser - Hot

    Repeat this step one or two times. When a steady stream is dispensed, the hot water is ready for use. To shut off the system, turn the switch to the OFF position. 040490c Section 4 --- Appliances The Executive 2005...
  • Page 177 Use only mild cleaners to clean the dispenser spout and plastic components. Use of cleaning agents containing acids, alkalies and organic solvents will result in the deterioration of plastic components. Draining the Insta-Hot Tank: Drain the Insta-Hot tank before storage, or if interior temperature drops below freezing. Appliances --- Section 4 The Executive 2005...
  • Page 178: Microwave/Convection Oven

    • Steam accumulating inside or around the outside of the oven door may occur when the microwave/convection oven is operated under high humidity conditions and in no way indicates a malfunction of the unit. Wipe away steam using a soft cloth. Section 4 --- Appliances The Executive 2005...
  • Page 179: Setting The Clock

    When cleaning the touch pad, open the door to prevent accidental operation. Use mild soap and water with a soft cloth. Avoid using excess amounts of water on the touch pad. The turntable plate and oven racks are dishwasher safe. Appliances --- Section 4 The Executive 2005...
  • Page 180 • Rinse the filter thoroughly and shake dry. Place the filter back into the opening, tip upward and slide filter to the end of the opening. Lock in place. Be careful not to kink or warp the filter upon installation. Section 4 --- Appliances The Executive 2005...
  • Page 181 • If the control panel becomes wet, clean with a soft, dry cloth. Do not use harsh detergents or abrasive when cleaning the control panel. Appliances --- Section 4 The Executive 2005...
  • Page 182: Automatic Appliance Selector

    A yellow flame or yellow flame tips indicate a rich fuel mixture, which can leave a black color or carbon on the bottom of the cookware. 030884 Section 4 --- Appliances The Executive 2005...
  • Page 183 Explosion, fire, property dam- age, injury or death can result. Contact a qualified service center to have the problem correctly diagnosed and repaired before resuming operation. Appliances --- Section 4 The Executive 2005...
  • Page 184: Cleaning & Care

    Only one of the following can be used at a time: Bedroom A/C, Washer-Dryer, or Cooktop. This is due to the auto- matic appliance selector limiting the use of appliances according to priority, to prevent electrical overload. 030890 Section 4 --- Appliances The Executive 2005...
  • Page 185: Wall Thermostat

    Only one of the following can be used at a time: Bedroom A/C, Washer-Dryer, or Cooktop. This is due to the automatic appliance selector limiting the use of appliances according to priority, to prevent electrical overload. Appliances --- Section 4 The Executive 2005...
  • Page 186: Air Conditioning - Roof

    • Press the MODE button repeatedly until Cool is displayed. • Set desired fan speed by pressing the FAN button. Cool • Set desired cooling temperature by pressing the UP or DOWN buttons. 050200b Section 4 --- Appliances The Executive 2005...
  • Page 187: Heat Pump

    The blower motor will stop for five minutes and Defrost will be displayed. After the defrost cycle the heat pump operation will resume. The Aqua-Hot the diesel burner or electric element will need to be turned on. The exchanger blow- ers will automatically begin operation. Appliances --- Section 4 The Executive 2005...
  • Page 188: Return Air Filters

    A/C in order to maintain preferred interior tempera- ture. Time setting on the ATS Control Module determines how long the generator will run before the ATS system disengages the generator. Section 4 --- Appliances The Executive 2005...
  • Page 189 If the error indicator still illuminates, test the Control Module. Unplug the remote cable (phone line) at the Control Module. Push and hold the Test button. If the generator engages, the problem may lie in the ATS remote. Discontinue ATS system use, and have the system serviced. Appliances --- Section 4 The Executive 2005...
  • Page 190: Aqua-Hot

    The heat exchangers are small radiators with 12 Volt DC blower motors. Current consumption is approximately ½ Amp per large heat exchanger. The small heat exchanger used in the private bath and the holding tank bay is ¼ Amp. Section 4 --- Appliances The Executive 2005...
  • Page 191 Hot coolant, providing hot water and interior heating. Use the Comfort Control to operate the heat exchangers. To Use the System: • Turn on the interior house power. • Set the Comfort Controls to Furnace. Furnace • Select the desired Zone and Temperature. 050200b Appliances --- Section 4 The Executive 2005...
  • Page 192: Troubleshooting

    When there is a call for heat the system will activate the circulation pumps. The fan speed selec- tor switches will have power applied to them and will be audible when turned ON. Section 4 --- Appliances The Executive 2005...
  • Page 193: Bay Thermosat

    Loud growls or other abnormal noise indicate service or repair is required. CAUTION: Before cleaning or servicing disconnect all power supplies. INFORMATION: For more details about the Aqua-Hot system, see the Owner's Information Packet. Appliances --- Section 4 The Executive 2005...
  • Page 194: Fuel Filter/Water Separator

    • Spin bowl/element onto head and tighten firmly by hand. • Start Aqua-Hot and check fuel filter for leaks. NOTE: After replacing filter, it ma take several cycles to purge air from system when attempt- ing to start the Aqua-Hot. Section 4 --- Appliances The Executive 2005...
  • Page 195: Aqua-Hot Overall View

    Aqua-Hot Overall View General Layout: An understanding of the general layout of the Aqua-Hot system will help in operating and trou- bleshooting the system. 040468d Appliances --- Section 4 The Executive 2005...
  • Page 196: Electric Baseboard Heater (Opt)

    To Reset the Overload Switch: • Turn off power supply. • Remove grille to access the Overload switch. • Using a pencil or small screwdriver, press the red Reset button down. 030940 030939 Section 4 --- Appliances The Executive 2005...
  • Page 197: Washer-Dryer Prepared

    • If the cabinet or closet in which a washer-dryer is installed does not have vented louvered doors, the manufacturer’s installation instructions may require installation of vented doors or vents to be installed in the doors. This is for sufficient circulation of air. Appliances --- Section 4 The Executive 2005...
  • Page 198: Washer-Dryer

    Gas while operating fuel-burning appliances. CAUTION: Do not use the washer-dryer while traveling. Suspension movement, combined with the weight of the drum while in the wash cycle, can damage the internal components of the washer-dryer. Section 4 --- Appliances The Executive 2005...
  • Page 199: Test Procedure

    7. Set the selector knob to Dry. Dryer fan should begin and the drum should rotate both directions. 8. Set the selector knob to Reset. Wait five seconds. 9. Set the Dry Time knob to zero. The Auto Dry light should go off. Appliances --- Section 4 The Executive 2005...
  • Page 200: Washer-Dryer Maintenance

    Periodically apply a thin coat of paste wax to the inner door, especially to the area that is immediately next to the door window. This will protect the door fin- ish from laundry spills and discoloration. Section 4 --- Appliances The Executive 2005...
  • Page 201: Winterizing The Washer-Dryer

    4. Any remaining liquid should contain a sufficient amount of antifreeze to be protected from freezing. NOTE: After winter, perform a Test Procedure before washing or drying any laundry to make sure all antifreeze has purged. Appliances --- Section 4 The Executive 2005...
  • Page 202: Dishwasher (Opt)

    Use only powdered detergent. Liquid and Tablets are not recommended for use. It is highly recommended to regularly use a liquid rinse agent for best drying results. The rinse agent dispenser is located inside the dishwasher holding approximately 1.7 fluid ounces of rinse agent. Section 4 --- Appliances The Executive 2005...
  • Page 203 Clean and dry the inside compartment. Leave the door ajar to allow air circulation. Shut off both power and water supplies to the dishwasher. INFORMATION: For Winterization of Dishwasher, refer to the Dishwasher Manufacturer owner’s man- ual. Appliances --- Section 4 The Executive 2005...
  • Page 204 NOTES Section 4 --- Appliances The Executive 2005...
  • Page 205 The Executive 2005 Equipment Section 5 EQUIPMENT - INTRODUCTION........207 AIR MATTRESS BED ...........236 ENTRY STEP ...............207 Troubleshooting.............238 Operation ..............207 STORAGE - UNDER BED ..........239 Tips...............208 SUPER SLIDE (OPT) ...........239 Stepwell ..............209 POWER SUPER SLIDE (OPT) ........240 Stepwell Cover ............209 RADIO-BEDROOM ............241 ENTRY DOOR ..............211...
  • Page 207: Equipment - Introduction

    This is the “last out” feature. When the ignition is on the step will always activate with door movement, regardless of the power switch position. CAUTION: High curbs can impede step operation. Use care when parked on side streets. Equipment --- Section 5 The Executive 2005...
  • Page 208: Tips

    • Lubricate points with graphite or a dry spray lubricant. • Work step several times, allow- ing lubricant to work into sur- faces. • Repeat as necessary. • Remove excess lubricant. Apply Lubricant 090448 Section 5 --- Equipment The Executive 2005...
  • Page 209: Stepwell

    The stepwell cover is under air pressure. When operating the stepwell cover, make sure there are no pets, shoes or other obstructions in the stepwell area. Do not operate the stepwell cover while standing in the stepwell area. Equipment --- Section 5 The Executive 2005...
  • Page 210 WARNING: When adjusting the stepwell cover clear the stepwell area of obstruc- tions, pets or persons. Do not adjust the stepwell cover while stepwell area is occupied. 090387 Air Solenoid Section 5 --- Equipment The Executive 2005...
  • Page 211: Entry Door

    • When the transmission is placed in neutral, the entry door seal will deflate. CAUTION: If the pressure regulator should require adjustment, do not exceed 5 psi. Damage to the seal may occur. 090419 Door Seal Regulator Equipment --- Section 5 The Executive 2005...
  • Page 212: Latch Adjustments

    • Eight Allen type screws (four on the top hinge and four on the bottom hinge) adjust the screen door to fit. The hinge should fit tightly to the trim of the door when the screen door is latched and the door is open. Section 5 --- Equipment The Executive 2005...
  • Page 213: Screen Door

    Located in Vanity Cabinet. Plungers Face-plate removed. Face-plate. 031081 031081b NOTE: If the chimes seem sluggish, the plungers can be cleaned with compressed air. Never oil chime plungers. Equipment --- Section 5 The Executive 2005...
  • Page 214: Keyless Entry

    • 559 - Locks entry door and bay doors if connected and arms keypad (flashes momentarily once every 15 seconds). NOTE: Due to preassigned codes, number(s) 5/6 cannot be used at the beginning of a new unlock code. 030883B Section 5 --- Equipment The Executive 2005...
  • Page 215: Keyless Entry Code Programming

    7. If the code was not accepted, repeat the procedure. WARNING: Ensure possession of entry door keys prior to testing new personal code. NOTE: These instructions are for motorhomes equipped with "keyless entry" only. Equipment --- Section 5 The Executive 2005...
  • Page 216: Key Fob

    To unlock the bay doors using the keyless entry system: • Enter the programmed unlock code. The entry door will unlock. • Within five seconds of the first sequence of numbers entered, press the number 9. Section 5 --- Equipment The Executive 2005...
  • Page 217: Slide-Out Operation

    Slide-out room, ensure there is sufficient clearance inside the motorhome. Never move the motorhome with any Slide-out room extended. CAUTION: Continuous operation of the Slide-out room can drain the batteries and damage the motor by overheating. Equipment --- Section 5 The Executive 2005...
  • Page 218: Main Room Slide-Out

    • Retract the leveling system or prepare the air leveling system for travel prior to oper- ating the Slide-out. • Turn the ignition switch OFF. The Slide-out room will not operate with the engine run- ning. Section 5 --- Equipment The Executive 2005...
  • Page 219 Several people (as many as eight) are needed to push in the room. • It may be necessary to contact a repair facility to have the problem diagnosed. Bay Door Safety Switch Equipment --- Section 5 The Executive 2005...
  • Page 220 Do not over tighten. 090342f Hydraulic Pump w/ 1 hydraulic slide Hydraulic Pump w/ 2 hydraulic slide Hydraulic Pump w/ 3 hydraulic slide Reservoir Cap RM01C007 RM01C0007c Release Nut Section 5 --- Equipment The Executive 2005...
  • Page 221: Bedroom Slide-Out

    Slide-out room and awning when extending the Slide-out room in snow, sleet, ice or freezing rain conditions. In such conditions, if the Slide-out room is extended, clear the awning and ensure free movement prior to operating the Slide-out room. Equipment --- Section 5 The Executive 2005...
  • Page 222: Manual Override - Electric Bedroom Slide-Out

    If the Slide-out room will not operate after verifying safety features, it will be necessary to manual- ly retract the Slide-out. WARNING: Do not work on the Slide-out system unless the battery is disconnected. Make sure the floor is clean before retracting the Slide-out room. Section 5 --- Equipment The Executive 2005...
  • Page 223: Wardrobe Slide-Out

    The Slide-out cover will automatically reach full extension when the Slide-out room is fully extended. NOTE: Water may pool on top of the extended cover. 030924b Water is removed when the cover retracts. Equipment --- Section 5 The Executive 2005...
  • Page 224: Window Awnings - Manual Carefree

    To Retract the Awning: • Hook catch rod on pull strap, remove pull strap from side strap hook and slowly allow awning to retract. • Remove catch rod from pull strap and store. 030792 Section 5 --- Equipment The Executive 2005...
  • Page 225: Care & Maintenance - Carefree

    "wet" the fabric so that it appears unable to repel water. Rinse the fabric thoroughly and test to see if it is water repellent after it dries. If leakage continues after repeating the washing and thoroughly rinsing, contact Carefree of Colorado concerning further maintenance. Equipment --- Section 5 The Executive 2005...
  • Page 226: Storm Precautions

    Awning run time should not exceed four to five minutes per hour. If the breaker trips, it will automatically reset in 30 minutes to one hour depending on ambient temperature. Section 5 --- Equipment The Executive 2005...
  • Page 227 If the awning still does not respond, the awning can be manually retracted by using the supplied telescoping crank handle. INFORMATION: Follow the instructions for manual awning retraction in the equipment manufactur- er’s manual. Equipment --- Section 5 The Executive 2005...
  • Page 228 • If the wind sensor retracts the awning, it is recommend to leave the awning in until winds subside. • Awning will not operate with the ignition key in the ON position. Section 5 --- Equipment The Executive 2005...
  • Page 229: Four-Channel Remote (Opt)

    • Remove switch plate. battery CR2430 • Remove switch unit from cabinet. • Remove back cover. • Lift tabs to release battery. 060240e • Replace with new battery and re-install. Remove back to replace battery. Equipment --- Section 5 The Executive 2005...
  • Page 230: Care & Maintenance - Girard

    030762 NOTE: Close the grill damper before installing the grill cover. Failure to close the damper may result in the cover blowing off while the motorhome is in motion. Section 5 --- Equipment The Executive 2005...
  • Page 231: Bathroom Fan

    Do not leave the fan switch in the active mode while the motorhome is stored or unat- tended for extended periods. High winds, unusual conditions or obstructions may pre- vent the fan cover from fully closing, resulting in leakage and serious damage. Equipment --- Section 5 The Executive 2005...
  • Page 232: Privacy Drapery Electric (Opt)

    Snap the new drive tire in place. • It may be necessary to adjust the motor on the wall bracket to get the drapery cord back into position. 030779b Rocker Switch Section 5 --- Equipment The Executive 2005...
  • Page 233: Power Sunvisor

    The pocket door rollers should be lubed with 070147 just a small drop of oil once a year to help increase the life of the rollers and improve the sliding of the door. Equipment --- Section 5 The Executive 2005...
  • Page 234: Seat Controls

    When the seat position is memorized the light will turn off. To Move Seat to a Stored Position: • Press the desired Memory Button once, the light will illuminate until the seat reaches its programmed position. 060197m Section 5 --- Equipment The Executive 2005...
  • Page 235: Swivel Seats

    • Fold seat belts out of the way. Sleeper to Sofa: • Lift the seat base up until seat and backrest are in a “V” shape. • Push down on seat base. 020222 Equipment --- Section 5 The Executive 2005...
  • Page 236: Dinette Bed Conversion (Opt)

    (1 or 2) hold down the MODE button again until the remote beeps. To return to mode select, at any time, press and hold the MODE button down until the remote beeps. Section 5 --- Equipment The Executive 2005...
  • Page 237 • Check air filter at back of pump monthly. Rinse with water to clean and let dry before installing. • Over time normal settling and impressions in cover will occur. Only the cover quilting is affected. Steam clean only, allow mattress cover to dry thoroughly. Do not dry clean. Equipment --- Section 5 The Executive 2005...
  • Page 238: Troubleshooting

    Pump Operates but Pressure Doesn't Storage Compartment Change: Check for kinks in hose or any visible obstructions between pump and mattress. NOTE: Do not disassemble pump. Internal components can be damaged and warranty will be voided. Section 5 --- Equipment The Executive 2005...
  • Page 239: Storage - Under Bed

    030797e WARNING: The motorhome must be level when sliding the drawer out of the bay compartment. The drawer can slide out abruptly and cause bodily harm when the motorhome is not level. Equipment --- Section 5 The Executive 2005...
  • Page 240: Power Super Slide (Opt)

    Lift the manual release lever on the power module. Push tray in and return arm to lock position. Powerslide Remote 080466 (Lock) Manual Override - Lever 080469 080466 Powerslide safety switch Section 5 --- Equipment The Executive 2005...
  • Page 241: Radio-Bedroom

    4. Press the MEMORY button again and the minute segments will flash. 5. Press the CD-TUNING SKIP |<< or >>| button to select the desired minute. 6. Press the MEMORY button once more. The flashing stops and the time is set. 031121 Equipment --- Section 5 The Executive 2005...
  • Page 242: Ladder - Rear

    • Push up on lower section of ladder to unlock hinge. • Lower ladder. Engage ladder legs with bottom locks. • Install clevis pin and hair pin clip. NOTE: Maximum weight capacity for the ladder is 300 lbs. 070189 070189b Section 5 --- Equipment The Executive 2005...
  • Page 243: Citizen Band (Cb) Radio

    Standing Wave Ratio (SWR) set- ting affect CB radio range. See OEM (Original Equipment Manufacturer) manual to adjust SWR. • No Power: Check 3 Amp fuse in Front Run Box. Equipment --- Section 5 The Executive 2005...
  • Page 244: Cell Phone Antenna

    • Press the SRC button for at least one second to Power ON the monitor. • Press the SRC button again to Power OFF the monitor. INFORMATION: For more detailed instructions on the monitor or receiver, refer to the Kenwood Monitor-Receiver instruction manual. Section 5 --- Equipment The Executive 2005...
  • Page 245: Kenwood Gps Navigation

    Caution Screen will follow. • The monitor is a touch screen display. Press the Agree label to enable the Current Position screen. • Press the MENU label to enable the main NAVIGATION MENU. 031052c 031051b Equipment --- Section 5 The Executive 2005...
  • Page 246: Aladdin™ System

    Pressing the joystick right will select that menu item. Pressing the joystick left goes to the previous 020195h screen. NOTE: Interior house power must be ON for the Aladdin™ screen to be displayed. Section 5 --- Equipment The Executive 2005...
  • Page 247 Joystick left or right selects the various COACHTANK/MISC STATUS digits. Joystick Up and Down changes the value. FRESH TANK GREY TANK BLACK TANK LP TANK BASEMENT TEMP 63.1 F OUTSIDE TEMP 55.7 F COMP HEADING 020209 Equipment --- Section 5 The Executive 2005...
  • Page 248: System Options

    "Calibration Successful" message to be displayed. A calibration that fails will display "Calibration Fail" and a failure code. NOTE: Other Aladdin™ functions and screens are discussed in respective sections of this manual. Section 5 --- Equipment The Executive 2005...
  • Page 249: Satellite Radio (Opt)

    All components of the entertainment system require 120 Volts AC to operate. Hook to shore power, start the generator or turn on the inverter. The satellite system requires 12 Volts DC to operate. Turn on the interior house power using the battery cut-off switch. Equipment --- Section 5 The Executive 2005...
  • Page 250: Television (Front) Lockout Feature

    The "hide-a-way" system uses a 120 Volt AC motor to lower and raise the television. A 12 Volt DC ignition safety lock prevents the television from lowering during travel. NOTE: The ignition must be off to raise or lower the TV. Section 5 --- Equipment The Executive 2005...
  • Page 251: Antenna Boost

    Worm gear damage or breakage may result. WARNING: Before raising antenna, make an outside visual inspection for any obstructions or overhead electrical wires. Damage to the antenna, severe shock, personal injury or death can occur from inadequate clearance. Equipment --- Section 5 The Executive 2005...
  • Page 252: Television/Entertainment System - Front

    Reading the individual component owner's manuals is strongly recommended. Many features and combinations for operating the entertainment system components are 031110 available. NOTE: Auxiliary components must be on. DVD/VCR Home Theatre System Combo Section 5 --- Equipment The Executive 2005...
  • Page 253 DVD/VIDEO button on the Home Theater System until DVD or VIDEO displays. Insert DVD or video tape and unit will automatical- ly begin playing. • Adjust the volume using the TV remote or the Home Theater System. 031078 Equipment --- Section 5 The Executive 2005...
  • Page 254 Behind drop down door on TV tuner in cabinet above co-pilot seat. NOTE: The flat screen TV requires adequate signal for proper operation. Audio is through the home theater system only. Section 5 --- Equipment The Executive 2005...
  • Page 255: Television/Entertainment System - Bedroom

    To Select VCR or DVD: • Turn on TV and VCR/DVD Player. • Push either VCR or DVD on the remote. • Select Video 2 on TV remote with TV/ Video button (*). Standard T.V Remote 030881f Equipment --- Section 5 The Executive 2005...
  • Page 256: Satellite System (Opt)

    This will enable either line of sight or control from another area. The IR setting requires the remote to have a direct line of sight to the satellite receiver. The RF set- ting allows the remote to operate the receiver from any room. 031055a Satellite Receiver Section 5 --- Equipment The Executive 2005...
  • Page 257: Tracvision System (Opt)

    The satellite antenna must be located in the selected satellite coverage area in order to receive a signal. 031027 Equipment --- Section 5 The Executive 2005...
  • Page 258: Instant On" Operation

    To turn off the TracVision SF system, press the POWER button. NOTE: It is highly recommended that the TracVision SF be turned OFF prior to moving the motorhome. TracVision SF will not track a satellite while the motorhome is in motion. Section 5 --- Equipment The Executive 2005...
  • Page 259: In-Motion System (Opt)

    • Turn on the Satellite Receiver. Located in cabinet above pilot seat. 031033 NOTE: Inclement weather conditions may adversely affect the satellite signal acquisition. Degraded audio and video signals through the receiver will result. Equipment --- Section 5 The Executive 2005...
  • Page 260: Universal Remote

    TV volume and CH to display component menu press ON. and display the adjust the channels. menu. All components TV menu. ANTAB selects will turn on. between antenna and shore cable. Section 5 --- Equipment The Executive 2005...
  • Page 261 From the MAIN Press DVD to Select DVD or Press FT TV to menu press ON. display DVD Video to play disc display component The components menu. or video tape. menu. will turn on. Equipment --- Section 5 The Executive 2005...
  • Page 262 • On the left of the MRF-200 is the power LED. The red status LED lights when the MRF-200 receives an RF signal from the MX-800. Back View 031113b Located in cabinet above co-pilot seat and in bedroom entertainment cabinet. Section 5 --- Equipment The Executive 2005...
  • Page 263: Bedroom Panel

    • Ceiling Lights = Turns on the bedroom ceiling lights. The switch works in conjunction with the bedroom switch located on wall. 060066j Located on bed cabinet above front night stand. NOTE: The generator switch is not affected by house battery power. Equipment --- Section 5 The Executive 2005...
  • Page 264 NOTES Section 5 --- Equipment The Executive 2005...
  • Page 265 The Executive 2005 Water Systems Section 6 WATER SYSTEMS - INTRODUCTION......267 DUMPING SYSTEM (OPT)...........288 WATER TANKS ............268 TOILET ................290 Measurements & Calibration........268 Cleaning & Maintenance ........291 Gravity Fill .............270 Drain Traps & Auto Vents........292 WATER - HOSE REEL ..........271 COLD WEATHER CONDITIONS ........293 City Hook-Up............271...
  • Page 267: Water Systems - Introduction

    040480m Water Pressure Regulator Attached to Hose Reel Water Systems --- Section 6 The Executive 2005...
  • Page 268: Water Tanks

    • Screen Color • Text Color ALADDIN MODEL 440 2.04 • Sensor Mode JOYSTICK F/M VERSION 2.01 • System Setup SCREEN COLOR: • Compass Calibration TEXT COLOR: SENSOR MODE: NORMAL SYSTEM SETUP COMPASS CALIBRATION Section 6 --- Water Systems The Executive 2005...
  • Page 269 Empty calibration must be done with the tank empty. All that is neces- sary is to enter the value of the raw data (displayed on the bottom of the calibration screen). 020218g Water Systems --- Section 6 The Executive 2005...
  • Page 270: Gravity Fill

    2. Insert potable water hose into inlet. 3. Fill tank until water overflows from inlet. 040393 Located to the rear of plumbing service center NOTE: Do not leave the gravity fill inlet unattended when in use. Section 6 --- Water Systems The Executive 2005...
  • Page 271: Water - Hose Reel

    Water Pressure Regulator the water hose to swell and burst. Attached to Hose Reel Tank Fill/City Hook-Up valve located in hose reel 040527 bay. Water Systems --- Section 6 The Executive 2005...
  • Page 272: Fresh Tank Fill

    Turning the key to the vertical position shuts that water line off. Each water line is 040429 labeled for easy reference. Snap the key into the key storage after use. Section 6 --- Water Systems The Executive 2005...
  • Page 273: Water Pump

    NOTE: The latching controller is located next to the water pump. Located on back of manifold mounting board in curbside 080374 water bay. Water Systems --- Section 6 The Executive 2005...
  • Page 274: Water Pump Troubleshooting

    • Is the inlet tubing and plumbing sucking in air at plumbing connections (vacuum leak)? • Check for proper voltage with the pump operating. • Check the pump housing for cracks or loose drive assembly screws. Section 6 --- Water Systems The Executive 2005...
  • Page 275: Pressure Accumulator Tank

    The amount of airflow and high-pressure from a compressed air system can quickly overcharge the tank, causing the internal bladder or tank to rupture. Water Systems --- Section 6 The Executive 2005...
  • Page 276: Water Filters

    • Turn on the water pump or city water. • Open the outside faucet at the plumbing service center and purge air from the filter assembly. • Check for leaks. 040360 Filters located in Curbside Water bay Section 6 --- Water Systems The Executive 2005...
  • Page 277: Galley Water Filter & Sanitizer (Opt)

    CAUTION: If a leak should occur, immediately shut off the valve labeled galley on the plumbing manifold. Contact a dealer for service. 040521i Filters located in Curbside Water Water Systems --- Section 6 The Executive 2005...
  • Page 278 Always turn off water supply with galley valve on the plumbing manifold and unplug power from right side of unit before removing cover, changing filters, servicing or maintaining. 040521 Top view with housing (Inside) cover removed Section 6 --- Water Systems The Executive 2005...
  • Page 279: Maintenance

    6. Replace the black ozone transfer tubing over the end of the ozone electrode assembly. 7. Replace the outer unit cover and restore power. WARNING: Ensure glass dielectric tube is pushed all the way up to the blue line before start-up. Water Systems --- Section 6 The Executive 2005...
  • Page 280 • If Green LED on unit does not illuminate, confirm that power is ON. If the power indica- tor still does not light and power is on, inspect resettable fuse on the side of the unit. Section 6 --- Water Systems The Executive 2005...
  • Page 281: Water Systems

    Use the same hose labeled for potable water to introduce the chlorine solution into the system. This will disinfect the potable water hose at the same time. Several flush- es will be required to remove chlorine residue from the potable hose. Water Systems --- Section 6 The Executive 2005...
  • Page 282: Faucets

    Build up of lime deposits, or debris on the faucet screen, will restrict or plug the flow of water coming from the faucets. All faucet screens should be checked and cleaned every two weeks of use. Section 6 --- Water Systems The Executive 2005...
  • Page 283: Soap Dispenser - Liquid

    • Lift dispenser pump out of bottle. • Use funnel to fill bottle with liquid Liquid Soap Dispenser & Funnel soap or lotion. 040528 Water Systems --- Section 6 The Executive 2005...
  • Page 284: Waste Water Systems

    CAUTION: Do not use any products that contain petroleum distillate or ammonia in place of RV odor controlling chemicals. Petroleum distillate or ammonia will damage the ABS plastic holding tanks and seals. Section 6 --- Water Systems The Executive 2005...
  • Page 285: Waste Drain & Sewage Tanks

    • Attach the other end of the hose to the drain serv- 040422A SEWER HOSE Plumbing Service ice. Restrain hose to prevent movement during use. Center on roadside • Open the (small) grey water valve. Water Systems --- Section 6 The Executive 2005...
  • Page 286: What To Put In Holding Tanks - Black Water Tank

    Ensure that there is enough liquid in the holding tanks prior to dumping the waste holding tanks to provide a smooth flow through the valve, drain pipe and drain hose. Empty the waste holding tanks weekly to prevent stagnation and overfilling. Section 6 --- Water Systems The Executive 2005...
  • Page 287: Tank Flush

    Secure the termination cap (required by law in some states). 12. If desired, add chemicals to the tanks to control odor. Follow the directions given by the manufacturer of the chemical. NOTE: Dump the black tank before driving. Water Systems --- Section 6 The Executive 2005...
  • Page 288: Dumping System (Opt)

    040517d • When the black tank is empty, turn Inserting sewer pipe adapter into sewer off the pump and leave the black connection. Drip Cap tank valve open. Section 6 --- Water Systems The Executive 2005...
  • Page 289 20 Amp fuse located on the rear run box at the curb side of the engine compart- ment R4 Circuit Board. R4 Circuit Board Rear Run Box in engine compartment Water Systems --- Section 6 The Executive 2005...
  • Page 290: Toilet

    NOTE: The toilet requires 12 Volt DC to operate. Low voltage will cause toilet malfunction or failure. Lift the lid to access the control switches. Flush Lever Toilet with lid removed 040449C Section 6 --- Water Systems The Executive 2005...
  • Page 291: Cleaning & Maintenance

    • Between closet flange and toilet: Confirm that flange screws are snug. Do not over tight- en screws. If leak continues, remove toilet and check flange height. Adjust, if necessary to 7/16" above floor. Replace flange seal if damaged. Water Systems --- Section 6 The Executive 2005...
  • Page 292: Drain Traps & Auto Vents

    The auto vent, if stuck in the open position, can allow grey odors to enter the motorhome. 070152 Some auto vents can double as "clean outs" in the event the line needs to be snaked out. Section 6 --- Water Systems The Executive 2005...
  • Page 293: Cold Weather Conditions

    FDA approved RV antifreeze. When plumbing lines are drained, antifreeze is not necessary, and the decision to use antifreeze is left to the motorhome operator. NOTE: ONLY FDA approved RV antifreeze should be used to winterize the water systems in the motorhome. Water Systems --- Section 6 The Executive 2005...
  • Page 294: Using Air Pressure

    Instructions for this procedure can be found in the Aqua-Hot owner’s manual. 4. Locate filters in bay. Remove filters, replace canister and re-install filter bowls. Remove optional Ozone Water filters in same manner. 040360 Filters located in curbside Water bay Section 6 --- Water Systems The Executive 2005...
  • Page 295 Pour the last water position pint into the washer/dryer drain. 040527c WARNING: Ensure the water is not hot when draining the low-point drain lines. Hot water from the lines can cause burn injuries. Water Systems --- Section 6 The Executive 2005...
  • Page 296: Using Nontoxic Antifreeze

    10 gallons of FDA approved RV anti-freeze into the fresh water tank. The valve between water pump and fresh water tank must be in the open position. 040393 Located to the rear of the Plumbing Service Center Section 6 --- Water Systems The Executive 2005...
  • Page 297: De-Winterization

    Operate all faucets, one at a time, until clear water is present. CAUTION: The first two trays of ice from the icemaker may contain contaminants. Discard and replenish the icemaker as necessary. Water Systems --- Section 6 The Executive 2005...
  • Page 298: Service Center

    8. City Water Connection 19. Termination Outlet 9. Fresh Tank Fill/City Water Valve 20. Black Tank Dump Valve 10. Black Tank Flush Connection 21. Fresh Tank Drain 11. Faucet 22. Sanitizer Holder Section 6 --- Water Systems The Executive 2005...
  • Page 299: Typical Water Bay

    TYPICAL WATER BAY 040496c Water Systems --- Section 6 The Executive 2005...
  • Page 300: Water Systems Diagram

    WATER SYSTEMS DIAGRAM 040487m Typical Water System Layout Section 6 --- Water Systems The Executive 2005...
  • Page 301 NOTES Water Systems --- Section 6 The Executive 2005...
  • Page 302 NOTES Section 6 --- Water Systems The Executive 2005...
  • Page 303 The Executive 2005 LP-Gas Systems Section 7 LP-GAS SYSTEMS ............305 LP-GAS DETECTOR .............306 Testing ..............307 Alarm ..............308 Maintenance............308 LP-GAS EMERGENCY PROCEDURES - CHECKLIST..309 LP-GAS TANK..............309 Measurement ............309 Tank Capacity............310 Tank Filling ............310 Tank Operation ............312 LP-GAS FUNDAMENTALS ...........312 LP-GAS REGULATOR ..........314 LP-GAS HOSE INSPECTION ........316...
  • Page 305: Lp-Gas Systems

    All fit- tings tested should be thoroughly rinsed and dried after testing. Never attempt to adjust LP-Gas regulators. Only qualified service personnel should perform any main- tenance or repair to the LP-Gas system. LP-Gas Systems --- Section 7 The Executive 2005...
  • Page 306: Lp-Gas Detector

    The LP-Gas detector only indicates the presence of propane gas at its sensor. Combustible levels of LP-Gas may be present in other areas. This detector is intended for the detection of LP-Gas ONLY. Section 7 --- LP-Gas Systems The Executive 2005...
  • Page 307: Testing

    WARNING: Test the operation of this detector after the motorhome has been in storage, before each trip and at least once per week during use. 030646b LP-Gas Systems --- Section 7 The Executive 2005...
  • Page 308: Alarm

    2. Do not spray cleaning agents or waxes directly onto the front panel. This action may dam- age the sensor, cause an alarm or cause a detector malfunction. Section 7 --- LP-Gas Systems The Executive 2005...
  • Page 309: Lp-Gas Emergency Procedures - Checklist

    LP-Gas tank. A small gauge is located on the LP-Gas tank. This non-adjustable gauge provides a quick view of the LP-Gas level. The Aladdin System will also provide ™ a percentage full reading on the COACH TANK/MISC STATUS screen. 020199 050256b LP-Gas Systems --- Section 7 The Executive 2005...
  • Page 310: Tank Capacity

    Gas will stop vaporizing as the LP-Gas tank temperature approaches - 40º F. WARNING: Extinguish all sources of heat, sparks, flames and smoking materials within a 50' radius during the refueling process. Section 7 --- LP-Gas Systems The Executive 2005...
  • Page 311 Pressure inside LP-Gas tanks can reach over 200 psi when exposed to direct sunlight. A high-pressure safety relief valve will purge excess high pressure, if necessary. LP- Gas will stop vaporizing as the LP-Gas tank temperature approaches -44º F. LP-Gas Systems --- Section 7 The Executive 2005...
  • Page 312: Tank Operation

    27.7 in. Water Column = 1 lb. per sq. in. pressure. The above capacities allow for 20% vapor space on each cylinder. Data taken from the National Fire Prevention Association (NFPA). Pamphlet #58-1998. Section 7 --- LP-Gas Systems The Executive 2005...
  • Page 313 The above information is not a complete guide for the use of LP-Gas tanks or appliances. In cold climates keep fuel levels above 50% in order to keep vapor- ization of LP-Gas at the highest level. LP-Gas Systems --- Section 7 The Executive 2005...
  • Page 314: Lp-Gas Regulator

    To Prevent Freeze Up: • Ensure the LP-Gas tank is totally free of moisture prior to filling. • Ensure the tank is not overfilled. • Keep the valve closed when the tank is empty. Section 7 --- LP-Gas Systems The Executive 2005...
  • Page 315 LP-Gas appliances until the LP-Gas pressure is checked and a leak down test is performed! Type 2 Manometer at Rest 050259a U-Tube Testing Layout 050260 Manometer Gauge for Testing Type 1 LP-Gas Systems --- Section 7 The Executive 2005...
  • Page 316: Lp-Gas Hose Inspection

    (10) years. The manufacturer of the LP-Gas supply lines recommended this schedule after per- forming extended testing and determining that the failure rate may increase after this period of time. The motorhome manufacturer recommends following these guidelines to assure continued safety and dependable use. Section 7 --- LP-Gas Systems The Executive 2005...
  • Page 317: Lp-Gas Distribution Lines

    Inspect the rubber flexible lines, twice a year, for abrasions, tears, kinks or other signs of damage. If a gas leak is suspected, get the system inspected and repaired by a qualified service technician as soon as possible. LP-Gas Tank 050257o Typical LP-Gas System Layout LP-Gas Systems --- Section 7 The Executive 2005...
  • Page 318: Lp-Gas Consumption

    LP-Gas regulators without the use of proper equipment. Improper LP-Gas reg- ulator adjustment will affect the performance of LP-Gas operated appliances. Incorrect flame or explosion can occur. Only qualified personnel should perform any maintenance or repair to the LP-Gas system. Section 7 --- LP-Gas Systems The Executive 2005...
  • Page 319: Lp-Gas Safety Tips

    (one of the most important items). There is a required 12 year re-qualification. The final piece of information is Dip Tube (DT) length. This is part of the overfill pro- tection and maximum liquid allowance in the cylinder. LP-Gas Systems --- Section 7 The Executive 2005...
  • Page 320 • Never use gas ranges or ovens for heating purposes. • Always have pot handles turned inward. • Ensure children understand never to turn or play with the knobs on the front of the propane gas range. Section 7 --- LP-Gas Systems The Executive 2005...
  • Page 321 NOTES LP-Gas Systems --- Section 7 The Executive 2005...
  • Page 322 NOTES Section 7 --- LP-Gas Systems The Executive 2005...
  • Page 323 The Executive 2005 Electrical Systems - House Section 8 HOUSE ELECTRICAL - INTRODUCTION.......325 DISTRIBUTION PANELS - HOUSE 250/120 ....359 BATTERY DISCONNECT - HOUSE........326 Circuit Breaker............360 BATTERY CUT-OFF SWITCH........327 GFCI BREAKERS & OUTLETS........361 SHORE POWER HOOK-UP...........327 DISTRIBUTION PANEL - HOUSE 12 VOLT ....362 Power Cord Reel (OPT) .........331...
  • Page 325: House Electrical - Introduction

    500 feet above sea level. This figure will decrease slightly at higher altitude. Ambient temperature also effects total maximum output. The amount of AC electrical load applied to the generator determines fuel consumption. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 326: Battery Disconnect - House

    5. Disconnect the wiring from the alternator. 6. Do not connect welding cables to electronic control components. 7. Attach the welding ground cable no more than two feet from the part to be welded. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 327: Battery Cut-Off Switch

    Serious personal injury or death may occur. If there is no power to the motorhome inform the park manager. It is the park manager's responsibility to fix problems with the shore power hook-up. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 328 • After the connection is made, turn the shore power breaker on. The transfer switch should make an audible click. • Go inside the motorhome and check the AC voltage using the Aladdin™ screen. 060043 060212 Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 329 Use the Inverter/Charger or start the generator, if AC power is needed. NOTE: Three types of shore power outlets most commonly used are shown in the illustration. 060121c Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 330 Always install the adapter to the cord prior to making the connection to the outlet. 060164 Typical 50-30 Amp Adapter. 060174 30-20 Amp adapter. Adapts the 30 Amp shore cord to a 20 Amp shore power outlet. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 331: Power Cord Reel (Opt)

    Use caution when working with metal tools. If the tool con- tacts a battery terminal or metal connected to it, a short circuit could occur causing personal injury, explosion or fire. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 332: Ac120 Volt & Amp Meters

    AC loads into the outlets when hooking to shore power or starting the generator. If voltage from shore power is below or above acceptable levels, start the generator and disconnect from shore service until shore power supply voltage becomes stable. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 333: Generator - 240 Volt Ac

    • Generator remote switch on the dash. • Generator control panel located on the generator. • Bedroom control panel. • Inverter panel. 060144i 060144i Panel Location at Generator Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 334: Pre-Start Checks

    WARNING: When the motorhome is parked, position the dash air conditioner vent control in the OFF position to prevent exhaust gases from entering the motorhome during generator operation. 080357 Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 335: Stopping The Generator

    For this reason it may be nec- essary to operate some appliances in sequence when air conditioners or other large motor loads are on. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 336: Generator Fuel

    The motorhome manufacturer does not cover damage to the generator caused by fuel contamination, or to appliances due to erratic AC voltage. AVERAGE FUEL CONSUMPTION DIESEL 10,000 WATTS (gal./hr.) No Load Half Load Full Load Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 337: Resetting The Circuit Breaker

    NOTE: Avoid short run periods of the generator. Run the generator set under a load for a minimum of one-half hour. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 338: Generator - Auto Gen Start (Rc7 Gs)

    Down arrow. Use Setting to change the value. When the program is set it may be necessary to slightly adjust the program profile to fit a particular need. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 339 • Begin Generator Quiet Time = This is the time when the generator will stop operation. 19:00 is 7:00 PM. • End Generator Quiet Time = This is the time when the generator can start. 09:00 is 9:00 • Select Generator = Onan Quiet Diesel. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 340 • Set the generator Start and Stop points back to Manual ON/OFF, or switch off the house and chassis main battery disconnects to erase the clock time and generator start/stop pro- gramming. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 341: Inverter - 3000 Watt

    • Automatic generator start. • Fully adjustable battery charge rates. • Adjustable fuel gauge cut-out. • Adjustable charging curves for different battery types. • Adjustable power sharing. 060032h • Meters Menu. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 342: Stand-By Operation

    The time it takes to charge the batteries to a full state of charge is dependent upon the inverter set-up parameters and actual state of charge of the batteries. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 343: Battery Temperature Sensor

    AC power to most outlets and appliances. When the inverter receives AC power, the internal battery charger "ramps up" battery charging voltage. After approximately 20 seconds, the relay engages, allowing AC power to pass through the inverter to the sub-panel. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 344: Meters Menu

    Avg Shunt Amps: Measures the DC current either charging or discharging. Most of the house DC current usage is monitored by the inverter. Battery Voltage: Monitors the house battery voltage. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 345: Programming The Inverter

    • Release the buttons. The programming mode has been entered when the Search Sense is displayed. • Use the up and down arrows to scroll though available field settings. • Use the right-pointing arrow to scroll through available settings for selected field. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 346 Battery types differ in chemical composition. Chemical types require charging characteristics at differ- ent voltages. Selection of available battery types are: • AGM (Absorb Glass Matte) • Gel Cell • Liquid Lead Acid Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 347 The Fuel Gauge will read 0 when the Fuel Gauge Cutout pre-programmed voltage reach- es 50% SOC. NOTE: The remaining field items are used to program the Automatic Generator Start param- eters. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 348: Re-Booting The Inverter

    5. Switch house and chassis main battery disconnects to the ON position. 6. Turn the main switch on the inverter to the ON position. 7. Connect the shore power cord or start the generator. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 349: Inverter-Sine Wave (Opt)

    When hooked to shore power or operating the generator, press the red button to enter a charge mode by selecting "On" or "Chg" in the main menu. Failure to enter either mode will result in dead batteries. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 350: Remote

    There are 14 main headings listed in the programming field, referred to as Menu Headings. Most of the Menu Headings have several sub-headings. Sub-headings are referred to as Menu Items. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 351 When hooked to shore power, or operating the generator, use the red button to enter a charge mode by selecting either On or Chg in the main menu. Failure to enter a Charge mode will result in dead house batteries. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 352: Programming & Resetting

    • Using the eraser end of a pencil or a pen, press the “Reset to Factory Default” button on the remote. NOTE: The main switch on the inverter remains ON. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 353: Stand-By Operation

    To Begin Battery Charging: • Hook to shore power or start the generator. • Press the red button on the inverter remote until the cursor indicates either CHG or On. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 354: Battery Temperature Sensor

    Load Amps AC - Displays the total number of AC amps of the pass through relay. Battery Actual Volts DC - Displays the DC battery voltage at the inverter when hooked to shore power or operating the generator. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 355: Automatic Generator Start Programming

    Start Quiet Time is the time you want the generator to stop running or not start at or after quiet time begins. Using the Set Point buttons to set the hour and minute (24 hour clock) the generator will start quiet time. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 356 Set Load Stop Delays Min - This is the time period the generator continues to operate after the generator started from the setting in the Set Load Start amps AC menu item. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 357 Mode.” Use the green button to scroll to Off. Setting the time and minute to 00:00 defeats this func- tion. Gen Starting Details: 11. Use the down arrow on the Menu Headings button to scroll to menu heading number 13, Gen Starting Details. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 358: Inverter Facts

    (-) terminal of the battery when being jumped. A spark may cause an explosion of the gases that surround the battery. Connect only to chassis, away from the battery. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 359: Distribution Panels - House 250/120

    Certain testing proce- dures may require the AC power to be on. Only qualified personnel with electrical backgrounds should attempt any testing procedures. 060142b GFCI Breakers Sub-panel: 120 Volt AC - Typical. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 360: Circuit Breaker

    For example: The electrical item is rated at 1370 watts. Divide that by the operating voltage of 115 Volts which equals 11.913 Amps. Use this for- mula to calculate the amount of load to the available power supply. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 361: Gfci Breakers & Outlets

    “click.” The breaker or outlet will not trip if AC power is not present at the device. If power is present and the device will not trip, replace it before using that circuit. NOTE: One milliamp is 1/1000 of one amp. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 362: Distribution Panel - House 12 Volt

    Shorting a battery cable to ground with a battery at a reasonable state of charge can result in a fire or serious personal injury from a burn. ATO Fuse 060086B Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 363: Tools Of The Trade

    If the fuse repeatedly blows after replacing it do not continue to replace it. Have the problem diagnosed and corrected by a qualified technician. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 364: Battery

    The starting batteries are located in the engine compartment. Periodically inspect the mount- ing hardware and trays. Trays and hardware should be tight and clean with no corrosion. 080460 Battery with cover. Battery with cover removed. Cut plastic to remove cover. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 365: House Batteries

    Do not allow these types of chemicals to get on the paint finish. If the chemicals splatter on to the painted surfaces, immediately rinse the surface using plenty of water and a mild automotive detergent. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 366: Battery Maintenance

    A battery can be tested and monitored several ways. The Aladdin System shows the voltage of the house batteries at a quick glance. The most efficient way of testing the LLA batteries is to check the electrolyte solution using a hydrometer. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 367 In case of eye contact, seek immediate medical aid. Never add acid to a battery once the battery has been placed in service. Doing so may result in hazardous splattering of electrolyte. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 368: Battery Voltage & Current

    Hopefully, this explanation will clarify why a battery measured at rest can indicate close to its rated voltage but will not run a load. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 369: Battery Charge Time & Consumption Rate

    17.6 Amps DC. If the battery bank capacity is rated at 500 Ahrs., actual elapsed time to the suggested 50% state of charge would net viewing time for the television at approximately 13 hours in ideal condi- tions. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 370: Solar Panel (Opt)

    Combiner Box: The Combiner Box, located on the side of the refrigerator vent on the roof, has four standard "knock outs" to allow for installation of additional solar panels. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 371: Charge Controller

    Allows weaker battery cells a chance to catch up with stronger cells. To assure all LLA battery cells are at an equal state of charge, a delay timer is activated to allow a short duration of slightly higher voltage. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 372: Solar Panel Care

    Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 373: Lights - Interior Halogen

    MP# 16615157 MAP LIGHT 12V 6W 38886K STEPWELL LIGHTS Vista Manufacturing 90416 WALL LAMPS 120V 40W 6-16.5 (2”) DINETTE/BEDROOM LAMP 12V 912 or 921 * MP = Monaco Part Number Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 374: All Electric (Opt)

    The shore power requirement of an All Electric motorhome, in most situations, will exceed 20 Amp shore power service. It is strongly recommended to hook to 30 Amp service or start the generator. Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 375: Overview

    Write down the figures to approximate dis- charge time of the battery bank. NOTE: When using the inverters as the power source the analog meters do not operate. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 376: Remotes

    12.5 Volts. Battery Type - Charge voltage is automatically selected when programming the battery type of the Master remote in the programming menu heading “Battery Type.” Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 377: House Batteries

    These voltage levels are approximate and give an indication of the state of charge of a battery at rest. As the battery ages these voltage measure- ments will be lower. Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 378 DOD cycles. NOTE: For optimum battery life, the batteries should not be cycled lower than 60% state of charge. Battery Depth Discharge % Chart Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 379: Main Battery Disconnect

    The alternator will maintain the battery charge during travel, supplying the DC current necessary to operate running lights or other DC load Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 380: Wiring Systems Interfaced

    Wiring Systems Interfaced Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 381 NOTES Electrical Systems - House --- Section 8 The Executive 2005...
  • Page 382 NOTES Section 8 --- Electrical Systems - House The Executive 2005...
  • Page 383 The Executive 2005 Electrical Systems - Chassis Section 9 CHASSIS ELECTRICAL - INTRODUCTOIN....385 BATTERY DISCONNECT - CHASSIS......385 BATTERY - CHASSIS...........386 FUSES & CIRCUITS ............387 Rear Start Switches..........388 Isolator Relay ............389 Relays..............389 ALTERNATOR ..............392 Alternator Testing Procedure ........393 STEERING COLUMN & SMART WHEEL.......394 Smart Wheel Operation..........394...
  • Page 385: Chassis Electrical - Introductoin

    If possible, leave the motorhome plugged into an AC source with the battery disconnect switch on to help prevent the possibility of dead batteries. 080240 Battery Disconnect Located in Engine Compartment Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 386: Battery - Chassis

    Perform a charging system and current draw check if the battery is exhibiting abnormal hydrometer readings. NOTE: Replacement batteries should have the same cold cranking amp (CCA) rating. 080460 Battery with cover removed. Cut plastic to remove cover. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 387: Fuses & Circuits

    RV techni- cian before any future use to diagnose and repair the poten- tial problem. Circuits are identified with a label adjacent to the fuse. Rear Run Box in engine compartment. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 388: Rear Start Switches

    • Move switch to the center OFF position, to turn the engine off. • Check the rocker switch to confirm it is in the position desired. • For normal operation, place the switch to FRONT. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 389: Isolator Relay

    87 or 87a relay. These current ratings differ, and if mixed, will create prob- lems. Ensure the replacement relay is of the current rating to assure proper operation. AC Relays 080406 Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 390 5. Using an 87a relay, the 30 post and the 87a post are common. When the coil is tripped, the 87a post becomes inactive and the 30 post becomes common to the 87 post located on the outside of the relay. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 391 When the power is removed, the field collapses. A momentary high voltage discharge will occur. This is how an ignition coil works. EXAMPLE: 080405d Singe Pole, Single Throw Relay. 080405 Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 392: Alternator

    Standard is 200 Amp and All-Electric is 270 Amp. CAUTION: Long-term use of the inverter to operate the microwave while in transit will damage the alternator. Use the generator to operate the microwave while in transit. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 393: Alternator Testing Procedure

    The alternator is not a battery charger. It is designed to maintain proper electrical sys- tem voltage. A battery with a low state of charge, or a dead battery, may overheat and damage the alternator. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 394: Steering Column & Smart Wheel

    When headlights are ON, pressing the switch will turn them off as long as the switch is pressed. Similarly, when the headlamps are OFF, pressing the switch causes the headlights to illuminate as long as the switch is pressed. 090270 Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 395 The transmission will not shift into gear if the engine RPM is at or above 900. The dis- play will flash "6" indicating the engine RPM is excessive. Select "N" and lower the engine RPM. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 396: Wiper Function

    To extend the wipe interval, press the intermittent button twice more, or switch the wipers off and use the same method to set the desired interval. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 397: Tilt & Telescope

    • Selects the forward DRIVE range by pressing D. The highest forward gear (6) appears on the display and the transmission will shift to the first gear. Gear “6” will remain on the display through subsequent upshifts or downshifts. 080355c Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 398: Parking Brake

    It is advised to fabricate a device to be placed under the parking brake handle preventing small children and pets from releasing the brake when parked. A wooden clothespin clasped to the shaft will be suitable. park brake.eps Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 399: Leveling Controls

    The control features a multiple warning system with flashing lights and a “bong” alarm to alert of a jack down. NOTE: Hydraulic leveling works only with ignition in ACC position. 080261b Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 400: Dash - Indicator Lamps

    6. STEP OUT - Entry step is in the extended position. Alerts driver to possible problem with entry step. 7. GEN DOOR - The generator door is open. 8. CRUISE - Cruise control is activated. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 401: Gauges

    12. ENGINE OIL PRESSURE (0 - 120 PSI) - Indicates oil pressure, not the amount of oil in the engine. Please refer to manufacturer's instructions for specific pressure recommen- dations. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 402 • Low Oil Pressure • Odometer • Low Coolant Level • Trip Odometer 1 • Low Battery • Trip Odometer 2 • High Battery • Engine Hours • Low Fuel • Clock Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 403: Operation

    3. Press to change minutes. Press to change hours. 4. After clock is set press and hold M until clock stops flashing. NOTE: Time is displayed as a 24 hour clock. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 404: Switches

    It may be necessary to remove the wire from the battery boost solenoid and perform a continuity check from the front to the rear of the motorhome. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 405 Turns on forward halogen lights over front seats. CARGO LIGHTS: Turns on roadside compartment bay lights. DIMMER/RHEOSTAT: Controls dash switch backlighting when headlight switch is on. DRVR SHADE: 060209 Operates the power sun visor located driver’s side. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 406 Turns on the heaters in outside rear view mirrors. The mirror heaters should be used when defog- ging or deicing is needed. Mirror heat should not be left in the ON position unless continuous fog- ging conditions occur. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 407 PORCH LIGHT: Controls porch light. STEP: Turns power on or off to step. To leave the step extended when parked, open the door. After the step extends, turn the switch off. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 408: Dash Air Conditioner & Heater Controls

    This switch directs air flow by opening or closing damper doors. Use the Mode Control Switch to direct airflow where it is needed to maximize comfort in the cockpit area. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 409 Controls the speed of the blower motor, which is one of the best and most effective ways of control- ling the temperature. The switch provides four speeds in all modes except OFF. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 410 The control module then drives the motor to within one-half volt of the control poten- tiometer voltage. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 411: About Refrigerants

    An ultraviolet or UV Blue Light is used for leak detection. The only suitable compound for use with R134a is PAG. The total amount of PAG within the refrigerant system is approximately 18% of the total refrigerant in the system. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 412 HIGH-SIDE gauge will be around 200 PSIG. NOTE: All systems are charged at the factory with 4.0 lbs of R134a. A fluorescent dye has been added for leak detection. psi gauge_temp.eps Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 413 Evaporator - A tube core and fins are used in the evaporator similar to the condenser. Air is blown through the fins to allow the evaporator to cool and reduce the pressure. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 414 8. Compressor Clutch is inoperative, will not engage. 9. Expansion Valve is faulty or frozen. 10. Thermostat control is faulty. 11. Mode control switch is faulty. 12. Compressor is faulty. 13. Loss of refrigerant. Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 415: System Control Center

    ABS functions. The Tag Axle ABS module is located above the transmis- sion tail shaft housing. The ATC (Automatic Traction Control) system is also part of the ABS system. Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 416: Diagnostic Plug Location

    Protection System Faults and Maintenance Indicators. All faults recorded will be ACTIVE or INAC- TIVE. Not all faults will light an indicator when they are ACTIVE. Diagnostic Plug (Engine) 090280B Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 417: Aladdin™ Engine Display

    TURBO BOOST PRESS S HEADING 1:23 AM ROAD SPEED ENGINE SPEED ENGINE COOLANT TEMP TRANS OIL TEMP SE HEADING 1:23 AM PERCENT LOAD INST FUEL MILEAGE FUEL RATE TURBO BOOST PRESS XXXX Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 418: Bulb Usage Chart - Exterior

    DOCKING LIGHTS Hella 893 12V 37.5W TROUBLE LIGHT R1910YF TURN SIGNAL - MIRROR GROTE 4641 AMBER GRAB HANDLE - EXTERIOR GE 194 PORCH LIGHT F8T5CW COMPARTMENT BAY LIGHTS GE 1141 Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 419: Engine "No Start" - Flow Chart

    ENGINE “NO START” - FLOW CHART Electrical Systems - Chassis --- Section 9 The Executive 2005...
  • Page 420 NOTES Section 9 --- Electrical Systems - Chassis The Executive 2005...
  • Page 421 The Executive 2005 Chassis Information Section 10 CHASSIS - INTRODUCTION..........423 CHARGE AIR COOLER .............488 AIR SUPPLY SYSTEM............425 BRAKE - AUXILIARY (ENGINE BRAKE)......489 Air Governor..............426 TRANSMISSION .............490 Air Storage Tanks ............426 Shift Selector.............490 Air Fittings..............427 Transmission Check Indicator ........492 Air Coupler - Universal..........428 Periodic Inspections ..........493...
  • Page 423: Chassis - Introduction

    5. Disconnect the wiring from the alternator. 6. Do not connect welding cables to electronic control components. 7. Attach the welding ground cable no more than two feet from the part to be welded. Chassis Information --- Section 10 The Executive 2005...
  • Page 424 Each air bag is paired with a Bilstein gas shock absorber. The suspension control arms attach to the frame through bushings, which require no lubrication. The preset suspension ride height automat- ically maintains the proper suspension height throughout the load range. Section 10 --- Chassis Information The Executive 2005...
  • Page 425: Air Supply System

    A discharge line from the dry side of the front air tank charges the rear air tank. Discharge lines use inline check valves to prevent a back flow of compressed air. 090404 Typical Air System Layout Chassis Information --- Section 10 The Executive 2005...
  • Page 426: Air Governor

    Remember to close the tank drain valves. Both air tanks have a pressure relief valve which are set to release at approximately 150 psi. Drain 090435 Located Generator Compartment on curbside. Section 10 --- Chassis Information The Executive 2005...
  • Page 427: Air Fittings

    The cavity of the positive tub- ing stop provides support to prevent leakage. WARNING: Do not remove air hoses from fittings while system is pressurized. Serious personal injury may occur. 090466 090466 Chassis Information --- Section 10 The Executive 2005...
  • Page 428: Air Coupler - Universal

    120 psi. Maximum outlet air pres- sure is achieved when the air system completes the fill cycle indicated by the purge cycle of the air dryer. Section 10 --- Chassis Information The Executive 2005...
  • Page 429: Air System - Charging (External)

    • The air dryer prevents water accumulation in air lines that could damage seals and valves and wash away lubricants. • The air dryer also prevents water in the air lines that can freeze and damage air system components. Chassis Information --- Section 10 The Executive 2005...
  • Page 430 86° F. The fuse for the heater is located in the front electric bay, roadside. WARNING: Remove all pressure from the air system before disconnecting any component, including the desiccant cartridge. Pressurized air can cause serious personal injury. Section 10 --- Chassis Information The Executive 2005...
  • Page 431: Desiccant Cartridge

    Preventive maintenance. Every two to three years. Contaminated cartridge. Desiccant When compressor is replaced. Saturated or contaminated car- Cartridge Water in supply tank. tridge, high duty cycle (wrong application of air dryer). Chassis Information --- Section 10 The Executive 2005...
  • Page 432: Desiccant-Type Air Dryer

    5. When the regeneration valve opens, the dry system air flows back through the dryer. A small charge of air from the front air tank backflows through the filter. The backflow dries the desiccant, preparing it for the next cycle. Section 10 --- Chassis Information The Executive 2005...
  • Page 433: Air Spring Inspection

    The approved cleaning method is to use soap and water, methyl alcohol, ethyl alcohol and iso- propyl alcohol. Unapproved cleaning methods include all organic solvents, open flames, abrasive and direct pressurized steam cleaning. 090269 Chassis Information --- Section 10 The Executive 2005...
  • Page 434: Height Control Valves

    Shock absorbers and air springs are in travel centers at proper ride height. The ignition must be on for the suspension to operate when equipped with HWH air leveling. Section 10 --- Chassis Information The Executive 2005...
  • Page 435: Adjusting Ride Height

    7. Re-check the front suspension height after adjusting the rear height control valves. NOTE: Do not modify length of the linkage rods. Make any necessary adjustments using eccentric slot on the ride height control valve. Chassis Information --- Section 10 The Executive 2005...
  • Page 436: Brake Systems

    In the event of air loss, while the vehicle is under operation, the park brake will automatically apply (this occurs at approximately 30 psi) acting as an automatic emergency brake system. Section 10 --- Chassis Information The Executive 2005...
  • Page 437: Brake Adjustment/Slack Adjuster

    If any loss of braking effectiveness or abnormal braking indications are noticed, the brakes and slack adjusters should be inspected by a qualified brake technician. Chassis Information --- Section 10 The Executive 2005...
  • Page 438: Brake Systems - Back-Up

    In case of all compressed air charge escaping from the front air tank, the operator will still have full use of the rear brakes. Section 10 --- Chassis Information The Executive 2005...
  • Page 439: Abs/Atc System (Anti-Lock Brakes)

    • The braking force is applied at a level which minimizes the stopping distances while maintaining as much lateral stability as possible. 090307 Chassis Information --- Section 10 The Executive 2005...
  • Page 440 • Reducing engine torque to the drive wheel if road speed is above 25 mph. • Reducing engine torque and activating drive axle brake controls if road speed is below 25 mph. If the brake control activates, it remains active regardless of road speed. 090372 Section 10 --- Chassis Information The Executive 2005...
  • Page 441: Front Axle

    30,000 miles. Have the steering system checked for damage after a severe impact, such as strik- ing large potholes or curbs, and front-end collisions. Observe the alignment of the steering wheel; a change in the alignment may indicate damage to the steering components or suspension. Chassis Information --- Section 10 The Executive 2005...
  • Page 442: Alignment

    • “Positive” camber is an outward tilt of the wheel at the top. • “Negative” camber is an inward tilt of the wheel at the top. 090267 Section 10 --- Chassis Information The Executive 2005...
  • Page 443 Incorrect toe settings, where toed-in or toed-out, can have a significant affect on tire wear. The toe setting is adjusted by lengthening or shortening the cross tube. 090265 Chassis Information --- Section 10 The Executive 2005...
  • Page 444 Decreasing the angle may result in the motorhome wandering or poor steering return to center. The caster angle is determined by the installed position of the steer axle. 090266 alignment spec chart.eps Section 10 --- Chassis Information The Executive 2005...
  • Page 445: Lubrication Maintenance Safety

    Steering Components Steering Components.eps Axle Beam Steering Box Steering Drive shaft Universal Joints Slip Yoke Ball Joint Steering Column Steering Wheel Steering Spindle Spindle Kingpin Centerlink Pitman Arm Drag Link TYPICAL STEERING COMPONENTS Chassis Information --- Section 10 The Executive 2005...
  • Page 446: Steering Column

    Greasing interval is yearly or every 30,000 miles. Steering Box Slip Yoke Front Seal 090349 Steering U-Joint Wheel Splines LUBRICATION POINTS U-Joint Steering Drive Shaft Rear Air Hole Section 10 --- Chassis Information The Executive 2005...
  • Page 447: Drag Link

    The center link is located on the backside of the steer axle. The center link attaches the two wheels together causing the right front to track with the left front. Greasing interval is every six months or 5,000 miles. GREASE FITTINGS CENTER LINK 090354 (BOTTOM VIEW) Chassis Information --- Section 10 The Executive 2005...
  • Page 448: Steering Spindles

    2 or 3 multipurpose chassis lube and use only a hand operated grease gun on the fitting. Add grease until it begins to extrude past the sector shaft dirt and water seal. Section 10 --- Chassis Information The Executive 2005...
  • Page 449 Inspect for signs of leakage when performing fluid level checks. Changing the hydraulic filter in the engine compartment at regular intervals will help ensure trou- ble-free operation. Zerk Fitting: located under dust cap. 090403b Back of Steering Box Chassis Information --- Section 10 The Executive 2005...
  • Page 450: Drive Axle & Drive Shaft

    • Re-install the fill plug and tighten to 35 to 50 ft. lbs. NOTE: When checking the lube level also check the housing breathers on top of axle housing. Clean the breathers if dirty or replace them if damaged. Section 10 --- Chassis Information The Executive 2005...
  • Page 451 NOTE: It will be necessary to move the motorhome forward or backward to access all fittings on the drive shaft. Chassis Information --- Section 10 The Executive 2005...
  • Page 452 Rotating shafts can be dangerous. Rotating shafts can snag clothes, skin, hair, hands, etc. causing serious injury or death. Do not work on or near a shaft “with or without a guard” when the engine is running. 090341 Section 10 --- Chassis Information The Executive 2005...
  • Page 453: U-Joint Angles, Phasing & Drive Shaft Balance

    Among the most common causes of U-joint and slip joint damage is lack of lubrication. To keep the motorhome operating smoothly and economically, the drive shaft must be carefully checked and lubri- cated at regular intervals. 090336 modified Chassis Information --- Section 10 The Executive 2005...
  • Page 454: Lubrication Maintenance

    If extra clearance is desired, moving the lift chain up one link on each side can increase ground clearance with the tag axle in the raised position. 060066 Lighted Switch 080375 Section 10 --- Chassis Information The Executive 2005...
  • Page 455 • Locate the full and add mark on the outside of the clear plastic cover. BELOW 0.25" - ADD OIL • If the lubricant is low, add recommended fluid to proper level. Chassis Information --- Section 10 The Executive 2005...
  • Page 456: Oil Lube Intervals

    The operating conditions for which the shock absorber must endure will deter- mine the life span. However, since the only moving part is the piston rod, there are no springs, hinges or pins to wear out, get weak or deteriorate. 090315 Section 10 --- Chassis Information The Executive 2005...
  • Page 457: Leveling - Air

    Emergency Stop = Turns the control panel off except when the ignition is in the on position and the park brake is released. Raise = Press this button with the ignition ON or in the accessory position to inflate the air springs using system air pressure. Chassis Information --- Section 10 The Executive 2005...
  • Page 458 When yellow level lights are extinguished, the motorhome is level. Red Warning Indicator Lamps = Illuminate when system is set to Manual or Automatic Level to indicate that the Height Control Valves (HCV) are inoperable. Section 10 --- Chassis Information The Executive 2005...
  • Page 459 When the reset light is illuminated, the motorhome will return to ride height if the ignition is in the on position. Warning Lamp & Reset Panel located in Roadside Electrical bay. 090454 Chassis Information --- Section 10 The Executive 2005...
  • Page 460: Automatic Air Leveling

    ON position. NOTE: If the system is turned off, the processor will not make any adjustments and an off level condition may occur over time. Section 10 --- Chassis Information The Executive 2005...
  • Page 461: Manual Air Leveling

    • The system will not be in the sleep mode if the coach was leveled in the manual level mode. NOTE: Level the motorhome side-to-side before leveling the motorhome front to rear. Chassis Information --- Section 10 The Executive 2005...
  • Page 462 The motorhome will raise approximately 4". This is helpful when negotiating driveways. CAUTION: Do not rely solely upon the travel light. It is the motorhome operator's responsi- bility ensure the air suspension system is ready for travel. Section 10 --- Chassis Information The Executive 2005...
  • Page 463: Leveling - Hydraulic (Opt)

    Hydraulic lines are under high pressure. Oil leaks may cut and penetrate the skin causing serious injury. CAUTION: DO NOT move the motorhome while jacks are in contact with the ground or extended. Damage to the jacks may occur. Chassis Information --- Section 10 The Executive 2005...
  • Page 464 If blocking up a rear jack pad to gain added clearance when the motorhome is on a slope, place a wheel chock at the opposite set of rear wheels to prevent the motorhome from rolling. Section 10 --- Chassis Information The Executive 2005...
  • Page 465 The leveling system has safety features to prevent a jack from extending during travel. The control panel will not activate until these safety features are in place. • Turn the ignition switch to the ACC position. • Place the transmission in Neutral. • Apply the parking brake. Chassis Information --- Section 10 The Executive 2005...
  • Page 466: Manual Leveling

    60 psi. With the ignition on, push and hold the Air Dump switch to lower the sus- pension. • Turn on the jack control Power switch. • Each yellow light and rocker switch combination corresponds to each jack as positioned on the chassis. Section 10 --- Chassis Information The Executive 2005...
  • Page 467: Automatic Leveling

    When the jacks are extended, a red Jacks Down warning light will blink and the bong alarm will sound. The alarm will sound if the jacks are down and ignition switch is turned ON. Chassis Information --- Section 10 The Executive 2005...
  • Page 468: Retracting Leveling Jacks

    The jacks retract by the weight of motorhome and the retract springs on each jack. The bot- tom green light will begin blinking and all jacks will retract. This operation is on a four-minute timer. After four minutes, the green light will stop blinking and go out. Section 10 --- Chassis Information The Executive 2005...
  • Page 469: Manual Retract Valves

    • When the jacks are fully retracted, rotate all the valves fully clockwise. In case one of the jacks is not holding pressure, one of the manual retract valves may not be fully tight- ened. 020027 Chassis Information --- Section 10 The Executive 2005...
  • Page 470: Maintenance

    Slowly fill the reservoir with fluid until the bong alarm stops. 5. Replace the reservoir cap. 6. To retract the extended jack, push the RETRACT button. 7. Turn the jack control Power switch OFF. 8. Turn OFF the ignition switch. Section 10 --- Chassis Information The Executive 2005...
  • Page 471: Engine - General Information

    INFORMATION: It is the responsibly of the owner to operate the engine in a safe manner. Consult the engine manufacturers owners manual for detailed operating and maintenance instructions. Chassis Information --- Section 10 The Executive 2005...
  • Page 472: Engine Diagram

    3. Tag Axle Regulator 9a. Fuel Control Panel 4. Air Filter Minder 10. Alternator 5. Thermovalve (for hydraulic fans) 11. Engine Oil Dipstick 6. Charge Air Cooler 12. Engine Oil Fill Tube Section 10 --- Chassis Information The Executive 2005...
  • Page 473 22. Engine Diagnostic Plug 15. Chassis Batteries 23. Light Reel - 12 Volt. 16. Air Governor 24. Pre strainer = Diesel fuel 17. Air Conditioning Compressor 18. Chassis Batteries Disconnect 19. Hydraulic Oil Dipstick Chassis Information --- Section 10 The Executive 2005...
  • Page 474: Cummins Isx (Opt)

    2. Back-up Alarm 9. Alternator 3. Tag Axle Regulator 10. Engine Oil Dipstick 4. Air Filter Minder 11. Engine Oil Fill 5. Hydraulic Fan Control Module 12. Hydraulic Oil Filter 6. Charge Air Cooler Section 10 --- Chassis Information The Executive 2005...
  • Page 475 20. Engine Front/Rear Start Switch 14. Air Governor 21. Light Reel 15. Air Conditioning Compressor 22. Engine Diagnostic Plug 16. Hydraulic Oil Dipstick 23. Pre-straine: Diesel fuel 17. Hydraulic Oil Reservoir 18. H2O Purge Bottle Chassis Information --- Section 10 The Executive 2005...
  • Page 476: Detroit Diesel (Opt)

    11. Coolant Reservoir 4. Radiator 12. Fuel Control Panel 5. Air Filter Minder 13. Primary Fuel Filter 6. Tag Axle Regulator 14. Prestrainer: Diesel Fuel 7. Thermovalve (for hydraulic fans) 15. Alternator Section 10 --- Chassis Information The Executive 2005...
  • Page 477 19. Air Filter 27. Engine Oil Fill Tube 28. Chassis Battery Disconnect 20. Reel Light 29. Hydraulic Oil Dipstick 21. Back-up Alarm 22. Rear Run Box 30. Hydraulic Oil Reservoir 23. Rear Start Switch Chassis Information --- Section 10 The Executive 2005...
  • Page 478: Starting Procedure

    15º F. If the engine has normalized to a temperature below 15º F it will be necessary to pre-heat the engine before start- ing. Section 10 --- Chassis Information The Executive 2005...
  • Page 479 3. Allow the engine to idle until it sufficiently warms for operation. Utilize the fast idle fea- ture to quicken the process. Wait to operate the motorhome for at least three minutes or until the coolant temperature begins to move. Chassis Information --- Section 10 The Executive 2005...
  • Page 480: Engine Oil

    The use of synthetic oils should not be used to extend drain intervals. Extended oil change intervals can decrease engine life and possibly affect the engine warranty. Section 10 --- Chassis Information The Executive 2005...
  • Page 481 Supplemental additives are generally not necessary and can be harmful. NOTE: Engine damage resulting in the use of supplemental oil additives is not covered by Detroit Diesel Corporation warranty. NOTE: The engine does not require a "break-in" procedure. Chassis Information --- Section 10 The Executive 2005...
  • Page 482: Engine Shutdown

    Engine warning light will illuminate and the engine will begin to de-rate in power output. Continued operation will result in engine damage. NOTE: Consult the engine manufacturer owners guide for more detailed information. Section 10 --- Chassis Information The Executive 2005...
  • Page 483 Stop the motorhome and inspect the coolant level before continued operation. INFORMATION: Refer to the Engine Manufacturer Owner’s Manual for details on engine coolant maintenance. Site glass for coolant inspection 090447 Cummins ISX Engine Coolant Reservoir Chassis Information --- Section 10 The Executive 2005...
  • Page 484 • The coolant level in the reservoir is visible in sight glass as green. INSPECTION: Stop the motorhome and inspect the coolant level before continued operation. Section 10 --- Chassis Information The Executive 2005...
  • Page 485: Coolant Additives - Sca

    Refer to the OEM engine manual for maintenance instructions. Engine coolant must be changed every two years. The correct filter is determined by the total cool- ing system capacity. Refer to the Cummins manual for additional information. Chassis Information --- Section 10 The Executive 2005...
  • Page 486 Refer to OEM manual for maintenance instructions. Coolant must be changed every two years. NOTE: The correct filter is determined by Detroit Diesel Corporation. Refer to the Detroit Diesel Operators Guide for additional information. Section 10 --- Chassis Information The Executive 2005...
  • Page 487 If the engine is overheated, never pour cold coolant into a hot engine. The sudden change in tem- perature may crack the cylinder head or block. If the engine is hot, fill slowly to prevent rapid cooling and distortion of engine castings. Chassis Information --- Section 10 The Executive 2005...
  • Page 488: Charge Air Cooler

    If the motorhome develops an oil leak, there is a possibility that the oil will coat the fins of the CAC. Dust will adhere to the oil film and eventually clog the fins, greatly reducing cooling effi- ciency. When the oil leak is repaired, the CAC must be thoroughly cleaned. Section 10 --- Chassis Information The Executive 2005...
  • Page 489: Brake - Auxiliary (Engine Brake)

    Located on the left console is a HI/LOW switch. The HI/LOW switch allows for the selection of different levels of engine braking power. Selecting LOW activates the engine brake on three cylin- ders. Selecting the HI setting activates the engine brake on six cylinders. Chassis Information --- Section 10 The Executive 2005...
  • Page 490: Transmission

    The electronic control system optimizes shift quality by using “Adaptive Shifting.” A wide variety of varied shift conditions is required before opti- mizing shift quality. Generally, five typical shifts of a consistent shift type is needed to optimize shift quality. Section 10 --- Chassis Information The Executive 2005...
  • Page 491 The transmission will not shift into gear from Neutral if the engine RPM is at or above 900. The display will flash “6” indicating the engine RPM is excessive. Select “N” and lower the engine RPM. Chassis Information --- Section 10 The Executive 2005...
  • Page 492: Transmission Check Indicator

    A maximum of five codes, D1 to D5, may be listed at one time. The highest priority code will be listed in D1. The MODE button will enable selection of sequential codes. Section 10 --- Chassis Information The Executive 2005...
  • Page 493: Periodic Inspections

    3. Unusual transmission-related sounds (changes in sound caused by normal engine thermo- static fan cycling, while climbing a long grade with a heavy load, have been mistaken for transmission-related sounds). 4. The CHECK TRANS light comes on frequently. Chassis Information --- Section 10 The Executive 2005...
  • Page 494 • If an "o" "L" "-" followed by a number displays, the oil level sensor could not read the level due to one of condi- tions listed in the “Common Oil Level Fault Codes” chart. Section 10 --- Chassis Information The Executive 2005...
  • Page 495: Transmission Lubricating Fluid

    Local conditions, severity of operation or duty cycle will dictate more or less frequent service intervals. INFORMATION: Refer to the Allison transmission owner’s manual or contact an authorized Allison service center for change intervals. Chassis Information --- Section 10 The Executive 2005...
  • Page 496: Fluid Levels - Cold Check

    • Ensure that fluid level checks are consistent. Check the level more than once. If readings are not consistent, ensure the transmission breather is clean and not clogged. If readings are still not consistent, contact the nearest Allison distributor or dealer. Section 10 --- Chassis Information The Executive 2005...
  • Page 497: Fuel System

    The engine pickup tube is cut at a 45° angle to allow optimum flow to the engine. The generator and Aqua-Hot intake tubes are set to approximately ¼ of a tank. This will prevent depleting the fuel supply while dry camping. Fuel Sending Unit 090335 b Chassis Information --- Section 10 The Executive 2005...
  • Page 498: Fuel Sender

    This should cause the reading to be above full. Adjust slowly, rotate counter- clockwise, until the full mark on the gauge is reached. The intent is to always adjust downscale rather than upscale. Section 10 --- Chassis Information The Executive 2005...
  • Page 499: Fuel Lines & Hoses

    NOTE: It is recommended to wear gloves and old clothing when working with diesel fuel. Avoid getting fuel in the interior of the motorhome. Chassis Information --- Section 10 The Executive 2005...
  • Page 500 9. Install filter onto housing. Tighten an additional three-quarter to one full turn after seat contacts base. Install discharge line to bottom of filter. NOTE: Over tightening may result in damage to the unit. 090261B Control Panel Section 10 --- Chassis Information The Executive 2005...
  • Page 501 The Drain Water function will operate only when water is detected in the primary fuel filter. NOTE: Always carry an extra Racor element as one tank full of excessively contaminated diesel fuel can plug a filter. Chassis Information --- Section 10 The Executive 2005...
  • Page 502: Rear Start Switches

    Using incorrect hydraulic system fluid weights in cold temperatures will raise the hydraulic system operating pressure and may damage the hydraulic cooler. 100188 Typical System: May vary with engine type. Section 10 --- Chassis Information The Executive 2005...
  • Page 503: Hydraulic Pump

    Hydraulic system pressure increases due to the viscosity of the fluid. Although the hydraulic pump is equipped with pressure relief valves, the thick oil on the return line can exceed the operating pressure of the hydraulic cooler. Chassis Information --- Section 10 The Executive 2005...
  • Page 504: Hydraulic Fan System

    This process will continue until coolant temperature inside the radiator reaches approximately 199º F. At this temperature, hydraulic fluid flow through the thermovalve is stopped, moving the spool valve to full open position. Section 10 --- Chassis Information The Executive 2005...
  • Page 505: Electric Thermovalve (Isx Engine)

    Power to the override valve is removed, hydraulic fluid flow signal is stopped and internal spool of the switching valve moves to full open position. The high pressure fluid is directed to fan motors cooling the radiator. Chassis Information --- Section 10 The Executive 2005...
  • Page 506: Fan Motor

    When the engine is running, use the sight gauge to check the filtering process. Change the filter if the indicator is in the red zone with the engine running. 090393 Section 10 --- Chassis Information The Executive 2005...
  • Page 507: Hydraulic Reservoir

    Look underneath the motorhome for signs of fluid leakage. Avoid untimely and costly failures by having leaks repaired. Change the hydraulic oil filter every 15,000 miles or once a year. NOTE: Use Dexron III ® transmission fluid when adding oil. 090263 Steering/Fan Reservoir Chassis Information --- Section 10 The Executive 2005...
  • Page 508: Air Filter

    When the desired change-out point is reached, the air filter should be replaced and the service indicator reset by pushing the Reset button on the top of the minder. 080105b Section 10 --- Chassis Information The Executive 2005...
  • Page 509: Egr Filter (Detroit Only)

    NOTE: Maintenance schedules are based on normal operating conditions and use. Operating under unusual or adverse condition shortens service intervals. NOTE: Engine and transmission service intervals are listed in their respective manuals. Chassis Information --- Section 10 The Executive 2005...
  • Page 510 "meets or exceeds" in accordance with the manufacturer specifi- cations. Section 10 --- Chassis Information The Executive 2005...
  • Page 511 • Wrap the nozzle with a paper towel or rag to prevent contamination and accidental soiling of other areas. Chassis Information --- Section 10 The Executive 2005...
  • Page 512 Typical Zerk Fitting. 090418 NOTE: Some grease fittings may not be accessible until the steering wheel is turned or the motorhome is moved slightly. Section 10 --- Chassis Information The Executive 2005...
  • Page 513: Lubrication Charts

    Check Before Each Trip + Daily Enroute Tire Pressure Steering Box Grease-1 Fitting Twice a Year Refer to Service Manual Refer to OEM Manual Generator Batteries Inspect Bi-Monthly Apply 10,000 or Quarterly Chassis Information --- Section 10 The Executive 2005...
  • Page 514 20 miles bi-monthly. It is important to remember the generator maintenance interval is based on hours of usage. Consult the Cummins Owner’s Manual for the generator service interval. Section 10 --- Chassis Information The Executive 2005...
  • Page 515: Cummins - Isx (Opt)

    Before Each Trip & Enroute Daily Grease-1 Fitting Steering Box Twice a Year Generator Refer to Service Manual Refer to OEM Manual Inspect Bi-Monthly Batteries Slack Adjuster/S-Cam Grease-3 Fittings ea. 10,000 or Quarterly Chassis Information --- Section 10 The Executive 2005...
  • Page 516 20 miles bi-monthly. It is important to remember the generator maintenance interval is based on hours of usage. Consult the Cummins Owner’s Manual for the generator service interval. Section 10 --- Chassis Information The Executive 2005...
  • Page 517: Detroit Diesel Series 60 (Opt)

    Before Each Trip + Daily Enroute Grease-1 Fitting Twice a Year Steering Box Refer to Service Manual Generator Refer to OEM Manual Inspect Bi-Monthly Batteries Apply 10,000 or Quarterly Drain / Replace Monthly/Annualy EGR Filter Chassis Information --- Section 10 The Executive 2005...
  • Page 518 20 miles bi-monthly. It is important to remember the generator maintenance interval is based on hours of usage. Consult the Cummins Owner’s Manual for the generator service inter- val. Section 10 --- Chassis Information The Executive 2005...
  • Page 519: Specifications Charts

    This chart reflects product specifications available at the time of printing. Therefore any floor plans introduced thereafter may not be reflected in the chart. All other information contained throughout the manual will still apply. Chassis Information --- Section 10 The Executive 2005...
  • Page 520: Engine Specifications

    4lbs. 134 A Hydraulic Oil 50 - 55 Qts. 50 - 55 Qts. 50-55 Qts. Rear End 15 Qts. Approx. 15 Qts. Approx. 15 Qts. Approx. Generator Specifications 10 Kw Generator Specifications 060148 Section 10 --- Chassis Information The Executive 2005...
  • Page 521: Belts & Filters

    Filter and belt numbers were correct at the time of printing. Verify the numbers at time of removal. The manufacturer will not be responsible for incorrect filter or belt usage. Please refer to the engine manufacturer’s operating instructions for specific mainte- nance information. Chassis Information --- Section 10 The Executive 2005...
  • Page 522: Battery Specification Chart

    Voltage Reading: Battery fully charged at rest for one hour. Battery Charge Voltage chart.eps Engine Cold Cranking Amp Requirements 1800 VOLTS 1850 VOLTS Series 60 1800 VOLTS CCA Rating are at 0º F. These are the minimum requirements. Section 10 --- Chassis Information The Executive 2005...
  • Page 523: Metric/U.s. Conversion Chart

    METRIC/U.S. CONVERSION CHART Chassis Information --- Section 10 The Executive 2005...
  • Page 524: Maintenance Records

    Any additional information from “Owner Checks and Services” or “Periodic Maintenance” can be added on the following record pages. In addition, retain all maintenance receipts. The owner information portfolio is a convenient place to store them. Section 10 --- Chassis Information The Executive 2005...
  • Page 525 Chassis Information --- Section 10 The Executive 2005...
  • Page 526 Section 10 --- Chassis Information The Executive 2005...
  • Page 527 Chassis Information --- Section 10 The Executive 2005...
  • Page 528 Julie Slagle - IN Fran Weisenstein - IN TECHNICAL ILLUSTRATIONS Kelly Stroble, Aaron Graham, Josh Means The Executive 2005 Technical Writer James Magee The Executive 2005 Layout Aaron Graham The Executive 2005 Cover Design Aaron Graham PRINTING Holiday Graphics - IN...
  • Page 529 The Executive 2005 Index...
