General Description
Shure Microflex MX200 Series microphones are miniature electret condenser
microphones designed for miking choirs and performance groups. They are
typically suspended over the heads of the performers. Their high sensitivity
and wide frequency range make them suitable for recording, as well as sound
reinforcement applications. An attached 101 mm (4 in.) gooseneck allows
them to be easily aimed at the sound source.
•
Wide dynamic range and frequency response for accurate sound repro-
duction
•
Interchangeable cartridges that provide a choice of polar pattern for each
application
•
White or black finish that blends unobtrusively with most surroundings
Interchangeable Cartridges
Microflex microphones use interchangeable cartridges that allow you to choose the polar pattern for different installations.
Omnidirectional
Snap-Fit Windscreen
•
Snap into the groove below the cartridge.
•
To remove, spread the gap with a screwdriver or thumbnail.
•
Provides 30 dB of "pop" protection.
©2017 Shure Incorporated
R183
Supercardioid
Cartridge Polar Patterns
•
RF filtering
Model Variations
Microflex MX202 microphones are available in black or white with a choice
of in-line preamplifier or plate-mount preamplifier.
The polar pattern of the included cartridge is indicated by a model number
suffix:
/C Cardioid
/S Supercardioid
/N Cartridge not included
R184
MX200 Series
Overhead Microphones
R185
Cardioid
1/5
Advertisement
Related Manuals for Shure Microflex MX202W
Summary of Contents for Shure Microflex MX202W
- Page 1 MX200 Series Overhead Microphones General Description Shure Microflex MX200 Series microphones are miniature electret condenser • RF filtering microphones designed for miking choirs and performance groups. They are typically suspended over the heads of the performers. Their high sensitivity Model Variations and wide frequency range make them suitable for recording, as well as sound reinforcement applications.
-
Page 2: Preamp Gain
MX200 Series Overhead Microphones Shure Incorporated Preamp Gain If necessary, the preamplifier gain can be reduced by 12 dB. Contact an authorized Shure service center for information. R6 and R4 R13 and R16 RFI Filtering Important: Microphones must be used with the RK100PK and RK202PK plate-mounted preamp to optimize RF immunity. -
Page 3: Ceiling Tile Installation
MX200 Series Overhead Microphones Shure Incorporated Use the two supplied mounting clamps to hold the preamp in place on a wall or ceiling. Ceiling Tile Installation 1. Drill a 1/2 in. hole into the ceiling tile. CAUTION: To avoid tile damage, use a 1/2 in. augur bit and drill very slowly. -
Page 4: Specifications
MX200 Series Overhead Microphones Shure Incorporated Specifications Note: Yellowing of any plastic material can be caused from cigarette smoke, ultra violet rays, and other chemical interactions. Once plastic has yellowed, there typically is no cleaning method that will restore the whiteness. - Page 5 Shure Europe GmbH Headquarters Europe, Middle East & Africa Department: EMEA Approval Jakob-Dieffenbacher-Str. 12 75031 Eppingen, Germany Phone: +49-7262-92 49 0 Fax: +49-7262-92 49 11 4 Email: info@shure.de Shure Incorporated 5800 West Touhy Avenue Niles, IL 60714-4608 USA Phone: +1-847-600-2000 Email: info@shure.com...
