  • Page 1 Installer manual NIBE F470 Exhaust air heat pump IHB GB 1722-1 431434...
  • Page 2 Quick guide Navigation Ok button (confirm/select) Back button (back/undo/exit) Control knob (move/increase/reduce) A detailed explanation of the button functions can be found on page 39. How to scroll through menus and make different settings is described on page 41. Set the indoor climate INDOOR CLIMATE HOT WATER HEAT PUMP...

  • Page 3: Table Of Contents

    6 Commissioning and adjusting Preparations Filling and venting Start-up and inspection 7 Control - Introduction Display unit Menu system 8 Control - Menus Menu 1 - INDOOR CLIMATE Menu 2 - HOT WATER Menu 3 - INFO NIBE F470 Table of Contents |...

  • Page 4: Important Information

    Must not be punctured or burned. Be aware that the refrigerant may be odourless General Pipe installation should be kept to a minim- Chapter 1 | Important information NIBE F470...
  • Page 5 Markings, signs and similar that are bustible refrigerant, may not use potential not clear must be replaced. ignition sources in such a way that that can lead to risks of fire or explosions. NIBE F470 Chapter 1 | Important information...
  • Page 6 Chapter 1 | Important information NIBE F470...
  • Page 7 Decommissioning times. Compressed air and oxygen may not be used. Before performing this procedure, the technician must be familiar with the equipment and all its component parts. NIBE F470 Chapter 1 | Important information...
  • Page 8 Hoses must be in good condition and be close all shut-off valves in the equip- equipped with leak proof quick-couplings. Before using the collecting machine, check that it works correctly and has been well Chapter 1 | Important information NIBE F470...
  • Page 9 Maintenance and repair that requires the skill of another person must be carried out under the supervision of someone with the above expertise. NIBE F470 Chapter 1 | Important information...

  • Page 10: General

    It must be disposed of at a special waste station or dealer who provides this type of service. Improper disposal of the product by the user results in administrative penalties in accordance with current legis- lation. Chapter 1 | Important information NIBE F470...
  • Page 11 Setting trim valve, number of turns from closed position Electricity (page 21) Connections Main voltage Phase voltage Fuses heat pump Fuses property Outside sensor Room sensor Current sensor (only copper version) Safety breaker Earth circuit-breaker NIBE F470 Chapter 1 | Important information...

  • Page 12: Delivery And Handling

    Because water comes from F470, the floor coating is important. A waterproof floor or floor membrane is recommended. 20-55 mm 30 - 50 mm Because water comes from F470, it is good if the area ■ NOTE where the heating pump is located is provided with floor drainage.

  • Page 13: Supplied Components

    1. Remove the upper panel by pulling it straight out. 2. Remove the screws from the lower edge of the front panel. 3. Lift the panel out at the bottom edge and up. 4. Pull the panel towards yourself. NIBE F470 Chapter 2 | Delivery and handling...

  • Page 14: The Heat Pump Design

    QM21 EP13 BT22 BT21 HQ11 HQ10 XL33 XL32 BT20 XL31 W130 AA101 XL34 AA100 AA4-XJ3 AA4-XJ4 BT30 BT19 QM13 QN11 BT18 QM20 QM11 QM10 QM32 QM31 AA102 GQ10 GQ10 XL32 XL31 Chapter 3 | The heat pump design NIBE F470...
  • Page 15 Shunt motor with hand wheel Circulation pump EMC-filter QM10 Filler valve, hot water heater Switch QM11 Filler valve, climate system W130 Network cable for NIBE Uplink QM13 Filler valve 2, climate system QM20 Venting, heating medium Cooling components QM21 Venting, supply air coil Evaporator...

  • Page 16: Pipe And Ventilation Connections

    4 Pipe and ventilation connections System diagram General pipe connections F470 consists of a heat pump, water heater, immersion Pipe installation must be carried out in accordance with heater, fans, circulation pump and control system.F470 current norms and directives. is connected to the ventilation system and heating me- dium circuit.

  • Page 17: Dimensions And Pipe Connections

    XL1-XL2 Heating medium ext Ø (mm) XL3 Cold water ext Ø (mm) XL4 Hot water ext Ø (mm) XL5 Hot water circulation ext. Ø (mm) XL8 Docking ext. Ø (mm) WM2 Overflow water discharge (mm) NIBE F470 Chapter 4 | Pipe and ventilation connections...

  • Page 18: Symbol Key

    Meaning Connecting the climate system A climate system is a system that regulates indoor com- Shut-off valve fort with the help of the control system in F470 and for example radiators, under floor heating/cooling, fan coils Non-return valve etc. Mixing valve When connecting to a system with thermostats on all ■...

  • Page 19: Supply Air Battery

    If possible, choose a cold day to adjust the trim valve. Installation alternative F470 can be installed in several different ways, some of which are shown below. Further option information is available at www.nibe.eu and in the respective assembly instructions for the ac- cessories used.

  • Page 20: General Ventilation Connection

    General ventilation connection Ventilation flow Ventilation installation must be carried out in accordance Connect F470 so that all of the exhaust air, except kit- with current norms and directives. chen duct air (kitchen fan), passes the evaporator (EP1) in the heat pump. The lowest ventilation flow must To prevent fan noise being transferred to the ventilation comply with the applicable national standards.

  • Page 21: Electrical Connections

    ■ F470 is not switchable between 3x230V and 3x400V. F470 must be equipped with a separate earth-fault ■ breaker (30 mA). FD1-S2 If a miniature circuit breaker is used, this should have ■...
  • Page 22 Use a suitable tool to release/lock cables in the heat Removing the cover, immersion heater board pump terminal blocks. 1. Insert the screwdriver (A) and pry the catch carefully downwards (B). 2. Angle out the cover and remove it. Chapter 5 | Electrical connections NIBE F470...

  • Page 23: Connections

    20 cm from high voltage cables. Power connection F470 must be installed via an isolator switch with a AA1-X1 minimum breaking gap of 3mm. Minimum cable area must be sized according to the fuse rating used. Supplied cable (length approx.
  • Page 24 Connecting external operating voltage for Switching from 3x400 V to 1x230 V the control system F470 can be switched from 3x400 V to 1x230 V by con- necting the supply to L1 and L3. NOTE Only applies to power connection of 3x400V.
  • Page 25 Room sensor F470 is supplied with a room sensor enclosed (BT50). The room sensor has up to three functions: 1. Show current room temperature in F470's display. 2. Option of changing the room temperature in °C. 3. Makes it possible to change/stabilise the room temperature.

  • Page 26: Settings

    11.6 Output locking 17.9 20.3 F470 follows applicable building regulations (BBR). This *Factory setting means that the maximum power output (maximum in- The table displays the maximum phase current for the stalled electrical output for heating) can be locked in relevant power step for the heat pump.
  • Page 27 4.6* *Default value 3x400V 8.0* 10.3 *Default value 3x230V 8.0* 10.0 *Factory setting 3x400V 3x230V The image shows the dip-switch (AA1-S2) in the factory setting. NIBE F470 Chapter 5 | Electrical connections...

  • Page 28: Optional Connections

    AUX4 (X6:15-16) and AUX5 (X6:17-18). Selectable out- unit. The multi-core cable between the enclosure and puts are AA3:X7. F470 must have a cable area of at least 0.5 mm². soft in/outputs 5.4 Connect the cable to the input board (AA3) on terminal X4:1-4 block - where X4:1 is the common terminal block for the three current sensors.
  • Page 29 Switch for "SG ready" NOTE In systems with both under floor heating and NOTE radiators, NIBE ECS 40/41 should be used for This function can only be used in mains net- optimum operation. works that support the "SG Ready"-standard .
  • Page 30 Contact for activation of “temporary lux" External circulation pump, for example external pump ■ and shunt group. An external switch function can be connected to F470 for activation of the hot water function "temporary lux". External damper for anti-freeze. ■...

  • Page 31: Connecting Accessories

    Externt AA3-X7 Circulation pump Connecting accessories Instructions for connecting accessories are provided in the manual accompanying the accessory. See page 56 for the list of the accessories that can be used with F470. NIBE F470 Chapter 5 | Electrical connections...

  • Page 32: Commissioning And Adjusting

    The vent pipe from the container must be drained of water before air can be released. This means that the system is not necessarily bled despite the flow of water when the bleed valve (QM20) is opened. Chapter 6 | Commissioning and adjusting NIBE F470...

  • Page 33: Start-Up And Inspection

    There must be water in the climate system be- fore the switch is set to " ". 1. Set switch (SF1) on F470 to position " ". 2. Follow the instructions in the display's start guide. If the start guide does not start when you start the F470, start it manually in menu 5.7.
  • Page 34 (l/s) Available pressure Tillgängligt tryck (Pa) Fan output, exhaust air Effekt Output 100% 100% 40% 50% Airflow Luftflöde (l/s) Fan output, supply air Airflow Luftflöde (l/s) Effekt Output 100% Airflow Luftflöde (l/s) Chapter 6 | Commissioning and adjusting NIBE F470...
  • Page 35 Vent the coil using the venting screw (QM21) repeatedly in order to ensure the circulation NOTE through the coil. Select operating mode "auto" or "manual" when the heat pump is to run on recovery again. NIBE F470 Chapter 6 | Commissioning and adjusting...
  • Page 36 (PP), or three different constant pressure (CP) and four constant curves (CC). Press the switch once to see what speed is selected. To lock/unlock a setting, press and hold the button for 10 seconds. Chapter 6 | Commissioning and adjusting NIBE F470...
  • Page 37 0,05 0,15 0,25 0,05 0,15 0,25 Flow Flow Flöde Flöde (l/s) (l/s) Pump speed (CP) Pump speed (CC) LED indication LED indication *The pump is factory-set with constant pressure (CP) speed 3 NIBE F470 Chapter 6 | Commissioning and adjusting...
  • Page 38 If gurgling sounds can be heard from the heat pump or climate system, the entire system re- quires additional venting. See section "Venting the cli- mate system" on page 32 for information about venting the heat pump. Chapter 6 | Commissioning and adjusting NIBE F470...

  • Page 39: Control - Introduction

    The control knob can be turned to the right or left. You can: ■ scroll in menus and between options. ■ increase and decrease the values. ■ change page in multiple page instructions (for example help text and service info). NIBE F470 Chapter 7 | Control - Introduction...

  • Page 40: Menu System

    INDOOR CLIMATE HOT WATER Hot water temp. These two symbols indicate whether the compressor or addition is blocked in F470. These can, for example, be blocked depend- ing on which operating mode is selected Information about operation in menu 4.2, if blocking is scheduled in...
  • Page 41 To select another option: 1. Mark the applicable option. One of the options is pre-selected (white). 2. Press the OK button to confirm the selected op- tion. The selected option has a green tick. NIBE F470 Chapter 7 | Control - Introduction...
  • Page 42 (at the page number) has been marked. 2. Press the OK button to skip between the steps in the start guide. If the start guide is left on this page it closes automatically in 60 min Chapter 7 | Control - Introduction NIBE F470...

  • Page 43: Control - Menus

    * Accessory needed. Menu 3 - INFO Overview 3 - INFO 3.1 - service info 3.2 - compressor info 3.3 - add. heat info 3.4 - alarm log 3.5 - indoor temp. log NIBE F470 Chapter 8 | Control - Menus...

  • Page 44: Menu 4 - Heat Pump

    Menu 4 - HEAT PUMP Overview 4 - HEAT PUMP 4.1 - plus functions * 4.1.3 - internet 4.1.3.1 - NIBE Uplink 4.1.3.8 - tcp/ip settings 4.1.3.9 - proxy settings 4.1.4 - sms * 4.1.5 - SG Ready 4.1.6 - smart price adaption™...

  • Page 45: Menu 5 - Service

    Manual start of the start guide which is run the first time the heat pump is started. quick start Quick starting the compressor. NOTE Incorrect settings in the service menus can damage the heat pump. NIBE F470 Chapter 8 | Control - Menus...
  • Page 46 Default value: 60 °C F470 copper: 43 °C Set the maximum supply temperature for the climate F470 stainless steel: 42 °C system here. If the installation has more than one climate Setting range stop temp. economy: 15 - 55 °C system, individual maximum supply temperatures can Factory setting stop temp.
  • Page 47 "detect phase order" and pressing the OK but- ton. Here you can set transfer time between heating and hot water production in F470. During the transfer time the The results of these checks appear just below the menu compressor maintains the stop temperature that applied selection "detect phase order".
  • Page 48 The date, time and ID no. (unique to certain settings) and the new set value is shown for every change. NOTE The change log is saved at restart and remains unchanged after factory setting. Chapter 8 | Control - Menus NIBE F470...
  • Page 49 Language settings can be made regardless of this selec- tion. NOTE This option locks after 24 hours, restart of dis- play or program updating. NIBE F470 Chapter 8 | Control - Menus...

  • Page 50: Service

    1. Disconnect the overflow pipe from the safety valve When replacing components on F470 only re- (FL1) and connect a hose to a draining pump instead. placement parts from NIBE may be used.
  • Page 51 4. With the screw pressed in, turn the screwdriver in 74.32 3.105 any direction. 56.20 3.047 5. Start F470 by setting the switch (SF1) to mode " " 42.89 2.976 and check that the circulation pump functions. 33.02 2.889 25.61 2.789...
  • Page 52 Menu 7.1 - update firmware update firmware7.1 start updating choose another file This allows you to update the software in F470. NOTE For the following functions to work the USB The display unit is equipped with a USB socket that can...
  • Page 53 Setting range: 1 s – 60 min Factory setting range: 5 s Here you can choose how current measurement values from F470 should be saved onto a log file on the USB memory. 1. Set the desired interval between loggings.

  • Page 54: Disturbances In Comfort

    1.9.1 lected in the menu 5.1.4. "heating curve" needs adjusting up. "comfort mode" "luxury" selected in combination with ■ large hot water outlet. Enter menu 2.2 and select "economy" or "normal". – Chapter 10 | Disturbances in comfort NIBE F470...
  • Page 55 ■ Order/implement ventilation adjustment. – Fan speed in forced mode. ■ Enter menu 1.2 and select "normal". – External switch for changing the fan speed activated. ■ Check any external switches. – NIBE F470 Chapter 10 | Disturbances in comfort...

  • Page 56: Accessories

    Part no. 067 127 Stainless Part no. 084 050 Extra shunt group ECS 40/ECS 41 Compact 300 This accessory is used when F470 is installed in houses with Copper Part no. 084 030 two or more different heating systems that require different Enamel Part no.

  • Page 57: Technical Data

    12 Technical data Dimensions and setting-out coordinates Avoid routing pipes through the Undvik rördragning marked area inom markerat område Ø125 NIBE F470 Chapter 12 | Technical data...

  • Page 58: Technical Specifications

    Sound pressure levels Sound pressure level in the boiler room (L dB(A) 47.5-50.5 P(A) Pipe connections Heating medium ext Ø Hot water ext Ø Cold water ext Ø Docking ext Ø Ventilation Ø Chapter 12 | Technical data NIBE F470...
  • Page 59 A20(12)W55, exhaust air flow 31 l/s (110 m The value varies with the selected fan curve. For more extensive sound data including sound to channels visit www.nibe.eu. The value can vary with the room's damping capacity. These values apply at a damping of 4 dB.
  • Page 60 Sound pressure levels Sound pressure level in the boiler room (L dB(A) 47.5-50.5 P(A) Pipe connections Heating medium ext Ø Hot water ext Ø Cold water ext Ø Docking ext Ø Ventilation Ø Chapter 12 | Technical data NIBE F470...
  • Page 61 A20(12)W55, exhaust air flow 31 l/s (110 m The value varies with the selected fan curve. For more extensive sound data including sound to channels visit www.nibe.eu. The value can vary with the room's damping capacity. These values apply at a damping of 4 dB.

  • Page 62: Energy Labelling

    The reported efficiency of the package also takes the controller into account. If an external supplementary boiler or solar heating is added to the package, the overall efficiency of the package should be recalculated. Chapter 12 | Technical data NIBE F470...
  • Page 63 For heat pump combination heater Declared load profile for water heating Water heating energy efficiency ƞ Daily energy consumption 5.92 Daily fuel consumption elec fuel Annual energy consumption 1,299 Annual fuel consumption NIBE F470 Chapter 12 | Technical data...

  • Page 64: Electrical Circuit Diagram

    Electrical circuit diagram 3x400V, copper Chapter 12 | Technical data NIBE F470...
  • Page 65 NIBE F470 Chapter 12 | Technical data...
  • Page 66 Chapter 12 | Technical data NIBE F470...
  • Page 67 NIBE F470 Chapter 12 | Technical data...
  • Page 68 Chapter 12 | Technical data NIBE F470...
  • Page 69 NIBE F470 Chapter 12 | Technical data...
  • Page 70 3x400 V, stainless steel Chapter 12 | Technical data NIBE F470...
  • Page 71 NIBE F470 Chapter 12 | Technical data...
  • Page 72 Chapter 12 | Technical data NIBE F470...
  • Page 73 NIBE F470 Chapter 12 | Technical data...
  • Page 74 Chapter 12 | Technical data NIBE F470...
  • Page 75 NIBE F470 Chapter 12 | Technical data...
  • Page 76 3x230V Chapter 12 | Technical data NIBE F470...
  • Page 77 NIBE F470 Chapter 12 | Technical data...
  • Page 78 Chapter 12 | Technical data NIBE F470...
  • Page 79 NIBE F470 Chapter 12 | Technical data...
  • Page 80 Chapter 12 | Technical data NIBE F470...
  • Page 81 NIBE F470 Chapter 12 | Technical data...

  • Page 82: Item Register

    External connection options, 28 General, 21 Back button, 39 Load monitor, 28 Miniature circuit-breaker, 21 Cable lock, 22 NIBE Uplink, 28 Cold and hot water, 18 Optional connections, 28 Commissioning and adjusting, 32 Outdoor sensor, 24 Filling and venting, 32...
  • Page 83 Switch for external blocking of heating, 29–30 Installation alternative, 19 Symbol key, 18 Maximum boiler and radiator volumes, 16 Symbols, 4 Pipe dimensions, 17 Symbols on F470, 4 Setting out dimensions, 17 System diagram, 16 Supply air battery, 19 Symbol key, 18 Technical data, 57...

  • Page 87: Contact Information

    Tel: +7 831 419 57 06 E-mail: kuzmin@evan.ru www.nibe-evan.ru NIBE AB Sweden, Box 14, Hannabadsvägen 5, SE-285 21 Markaryd Tel: +46 (0)433 73 000 E-mail: info@nibe.se www.nibe.se For countries not mention in this list, please contact Nibe Sweden or check www.nibe.eu for more information.
  • Page 88 WS name: Frånluft WS version: a48 (working edition) Publish date: 2017-05-31 08:12 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 431434...
