Instructions for Using
EN
Robotic Pool Cleaner Classic 4 / Top 4 - UNI
User Instructions
Contents
1. INTRODUCTION ....................................................................... 2
2. SPECIFICATIONS ...................................................................... 2
3. WARNINGS AND CAUTIONS ................................................... 2
3.1. Warnings ............................................................................ 2
3.2. Cautions ............................................................................. 2
4. POOL CLEANER PARTS ............................................................ 3
5. USING THE POOL CLEANER .................................................... 4
5.1. Setup.................................................................................. 4
5.2. Putting the Pool Cleaner into the pool .............................. 5
5.3. Removing the Pool Cleaner from the pool ........................ 6
6. CLEANING THE FILTER BAG OR CARTRIDGES ....................... 7
6.1. Removing and cleaning the filter bag ................................ 7
6.2. Replacing the filter bag ..................................................... 8
6.3. Cleaning the filter cartridges ............................................. 8
6.4. Cleaning the impeller ........................................................ 10
7. OFFSEASON STORAGE ............................................................ 10
8. TROUBLESHOOTING ................................................................ 11
1
Advertisement
Table of Contents
Related Manuals for Maytronics Classic 4-UNI
Summary of Contents for Maytronics Classic 4-UNI
-
Page 1: Table Of Contents
Robotic Pool Cleaner Classic 4 / Top 4 - UNI User Instructions Contents 1. INTRODUCTION ............... 2 2. SPECIFICATIONS ..............2 3. WARNINGS AND CAUTIONS ........... 2 3.1. Warnings ................2 3.2. Cautions ................2 4. POOL CLEANER PARTS ............3 5. -
Page 2: Introduction
Thank you for purchasing a Maytronics Robotic Pool Cleaner. We are sure that your Maytronics Robotic Pool Cleaner will provide you with reliable, convenient and cost effective pool cleaning. Its reliable iltration in all pool conditions, active brushing, and all-surface climbing brush enhance maximum pool hygiene. -
Page 3: Pool Cleaner Parts
4. POOL CLEANER PARTS Robotic Pool Cleaner Classic 4 - UNI Robotic Pool Cleaner Top 4 - UNI Brushes C o m b i ned B r us h C o m b i ned B r us h All surface climbing brush, All surface climbing brush, ideal for most pools surfaces ideal for most pools surfaces... -
Page 4: Using The Pool Cleaner
5. USING THE POOL CLEANER The Pool Cleaner is very easy to use. Just follow the simple steps to get started, and your Pool Cleaner is ready to go. 5.1. Setup Before using the Pool Cleaner for the irst time perform the following steps: Unwind the cable and stretch it out completely so that it has no kinks. -
Page 5: Putting The Pool Cleaner Into The Pool
5.2. Putting the Pool Cleaner into the pool If your Pool Cleaner is equipped with brushes that contain sponges, dip the brushes in the water and squeeze them so that they will absorb water the irst time you use the Pool Cleaner, or if the brushes have dried out between uses. -
Page 6: Removing The Pool Cleaner From The Pool
5.3. Removing the Pool Cleaner from the pool Turn OFF and unplug the power supply. CAUTION Using the loating cable, bring the Pool Cleaner to the pool’s edge. Using the handle, remove the Pool Cleaner from the pool. 10cm/4in DO NOT PULL THE POOL CLEANER FROM THE POOL USING THE CABLE. CAUTION Place the Pool Cleaner on the edge of the pool and let the water drain out. -
Page 7: Cleaning The Filter Bag Or Cartridges
6. CLEANING THE FILTER BAG OR CARTRIDGES Depending on the model, your Pool Cleaner may be equipped with a ilter bag or cartridges. It is recommended to clean the ilter bag or cartridges after each cleaning cycle. 6.1. Removing and cleaning the filter bag Unplug the power supply. -
Page 8: Replacing The Filter Bag
6.2. Replacing the filter bag Put the ilter bag over the frame so that the strap is in the middle of the shortest side. Make sure that ilter bag is positioned properly on the frame. 6.3. Cleaning the filter cartridges Note: Don’t let the filter cartridges dry out before cleaning. - Page 9 Clean the ilters with a hose. Insert the ilters with the plastic backing facing out. Insert the cartridge unit. Robotic Pool Cleaner Classic 4 / Top 4 - UNI User Instructions...
-
Page 10: Cleaning The Impeller
6.4. Cleaning the impeller If you notice debris trapped in the impeller open the impeller and remove the debris. Unplug the power supply. CAUTION Using a screwdriver, remove the two screws on the impeller cover and remove it. Clear any debris that may be in the impeller. -
Page 11: Troubleshooting
8. TROUBLESHOOTING If the suggest solutions do not solve the problem contact your dealer Symptom Possible reason Corrective action 1. Cable twisting • Obstruction in pool • Remove obstruction in pool. or cable coils up • Excess cable in the pool •...
