PORTABLE GAS BBQ
MORSØ FORNO GAS
SQ-330
• Powerful stainless steel burner with rotary
ignition for easy lighting
• Satin enamel cast iron cooking surface –
easy to cook on and wash up
• Durable die cast aluminium bowl and hood
• Integrated temperature gauge for maxi-
mum control when cooking
Important: Retain these instructions for future use.
0051-16
• High dome hood – 17cms – allows you to
cook roasts easily
• Stand available as an optional extra (sold
separately)
• Supplied with hose and regulator so it's
ready to use with a POL gas cylinder
• Gas certified to CE standards
UK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FORNO GAS and is the answer not in the manual?

Questions and answers

Related Manuals for Morso FORNO GAS

Summary of Contents for Morso FORNO GAS

  • Page 1 PORTABLE GAS BBQ MORSØ FORNO GAS SQ-330 • Powerful stainless steel burner with rotary • High dome hood – 17cms – allows you to ignition for easy lighting cook roasts easily • Satin enamel cast iron cooking surface – • Stand available as an optional extra (sold...

  • Page 2: Read Me First

    READ ME FIRST Gas leak testing It is important that you leak test the BBQ before first use and every time the gas cylinder is refilled and reconnected to the BBQ. To Complete Leak Test • Make sure all the control knobs are OFF. •...

  • Page 3: General Information

    GENERAL INFORMATION Hose & Regulator Safety IMPORTANT The regulator and hose assembly supplied with the barbecue are suitable for Propane Gas or Universal L.P.G. only. Read these instruction carefully prior to The pressure regulator and hose assembly use. Familiarise yourself with the ap- supplied with the barbecue must me used.
  • Page 4 GENERAL INFORMATION • Never lean over cooking surface when lighting. • Never alter or modify the regulator or gas supply as- sembly. • This barbecue must not be used indoors. • Only use in well ventilated areas. • CARBON MONOXIDE HAZARD - USING THIS AP- FOR YOUR SAFETY PLIANCE IN AN ENCLOSED SPACE MAY CAUSE Failure to comply with these instructions could...
  • Page 5 Location of your Barbecue DO NOT use your barbecue in garages, porches, sheds, breezeways, or other enclosed areas. Your barbecue is to be used OUTDOORS. The barbecue is not intended to be installed in or on recreational vehicles and/or boats and should not be placed under any surface that will burn.

  • Page 6: Exploded Diagram

    LISTE OVER DELE EXPLODED DIAGRAM PARTS LIST Part Description Part Description Temperature Gauge Base Rubbet gasket Lid Handle Buckle Ignition needle Burner Bowl Overheating protection Adapter Cooking Grate Valve Sheet metal Knob Heat Insulator Fat Cup Fat Cup Support...

  • Page 7: Connecting The Gas Cylinder

    MONTAGEVEJLEDNING ASSEMBLY INSTRUCTIONS Remove any transit protection material. STEP 1 Attach the lid handle using the fasteners as shown. CONNECTING THE GAS CYLINDER There are two different types of gas that can be used on your gas bbq depending on where you live, that being either butane or propane gas.

  • Page 8: Lighting Procedure

    GARANTI GENERAL INFORMATION CONNECTING & DISCONNECTING LIGHTING PROCEDURE TO GAS SOURCE Burner Operation & Ignition System Check Familiarise yourself with the general information and safety guidelines located at the front of this manual. 1. With cylinder valve in ‘OFF’ position check the ig- niter by pushing in and rotating the control knob anti-clockwise.

  • Page 9: Operation

    DATA PÅ MORSØ FORNO GAS OPERATION BURNER OPERATION & IGNITION SYSTEM CHECK Problem Possible Reason Solution Control knob is closed Turn knob to high when lighting Burner will not ignite The ignition needle is faulty Use a long barbecue match inserted through...

  • Page 10: Care And Maintenance

    TILSLUTNING AF FLASKE MED FLYDENDE PROPANGAS. CARE & MAINTENANCE Cleaning the Cooking Surface As with all appliances, proper care and maintenance will keep them in top operating condition and prolong their After cooking, turn burner control to ‘OFF’ and let bar- life.

  • Page 11: Safe Appliance Locations

    KONTROL AF GAS LÆKAGE SAFE APPLIANCE LOCATIONS This appliance shall only be used in an above ground open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. Any enclosure in which the appliance is used shall comply with the following: An enclosure with walls on all sides, but at least one permanent opening at ground level and no overhead cover.
  • Page 12 For any queries or assistance call: Customer Service Denmark 45 96 69 19 00 Åbningstid: Monday to Friday 8.00 am - 3.30 pm. Keep your purchase receipt, this will be required to make any claims under the 12 month warranty. www.morsoe.com 21.03.2018...
