Summary of Contents for Dometic CoolPower MPS50
- Page 1 ENERGY & LIGHTING COOLPOWER MPS50 Mains rectifier Installation and Operating Manual...
-
Page 3: Table Of Contents
MPS50 Please read this instruction manual carefully before installation and first use, and store it in a safe place. If you pass on the product to another person, hand over this instruction manual along with it. Contents Explanation of symbols ......... . .4 General safety instructions . -
Page 4: Explanation Of Symbols
Explanation of symbols MPS50 Explanation of symbols DANGER! Safety instruction: Failure to observe this instruction will cause fatal or serious injury. WARNING! Safety instruction: Failure to observe this instruction can cause fatal or serious injury. CAUTION! Safety instruction: Failure to observe this instruction can lead to injury. NOTICE! Failure to observe this instruction can cause material damage and impair the function of the product. - Page 5 MPS50 General safety instructions General safety DANGER! • In the event of fire, use a fire extinguisher which is suitable for electrical devices. WARNING! • Only use the device as intended. • Ensure that the red and black terminals never come into contact. •...
- Page 6 General safety instructions MPS50 • Never pull the plug out of the socket by the connection cable. • Store the device in a dry and cool place. Safety when installing the device DANGER! • Never mount the device anywhere where there is a risk of gas or dust explosion.
- Page 7 MPS50 General safety instructions CAUTION! • Lay the cables so that they cannot be tripped over or damaged. NOTICE! • Use ductwork or cable ducts if it is necessary to lay cables through metal panels or other panels with sharp edges. •...
-
Page 8: Scope Of Delivery
Scope of delivery MPS50 NOTICE! • Make sure the air inlets and outlets of the device are not covered. • Ensure good ventilation. Scope of delivery • Mains rectifier • Operating manual Proper use The MPS50 mains rectifier is for operating coolers and refrigerators with BDF50 compressors at 110 –... -
Page 9: Technical Description
MPS50 Technical description Technical description The mains rectifier can operate all coolers and refrigerators with BDF50 compressors at 110 – 240 Vw. With a 110 – 240 Vw mains connection, the rectifier automatically switches from battery to mains operation. When disconnected from the 110 – 240 Vw mains supply, the rectifier automatically switches back to battery operation. -
Page 10: Mounting The Mains Rectifier
Mounting the mains rectifier MPS50 Mounting the mains rectifier If you wish to mount the mains rectifier in a fixed position, please observe the following mounting instructions: • Do not mount the device – In wet or damp environments – In the vicinity of combustible materials –... -
Page 11: Using The Mains Rectifier
MPS50 Using the mains rectifier Using the mains rectifier 12/24 V WARNING! Do not reverse the polarity. If the poles are reversed device may over- heat and be damaged. NOTICE! Replace defective fuses with new ones of the same rating (12 A slow- blow). -
Page 12: Maintaining And Cleaning The Mains Rectifier
Maintaining and cleaning the mains rectifier MPS50 ➤ Fit wire sleeves to the ends of wires which you wish to connect to the mains rectifier. ➤ Connect the battery using the B+ and B– terminals on the front plate (fig. 3, page 12). -
Page 13: Guarantee
MPS50 Guarantee Guarantee The statutory warranty period applies. If the product is defective, please contact the manufacturer's branch in your country (see the back of the instruction manual for the addresses) or your retailer. For repair and guarantee processing, please include the following documents when you send in the device: •... -
Page 14: Technical Data
Technical data MPS50 Technical data CoolPower MPS50 Reference number: 9109002476 Rated input voltage: 110 – 240 Vw, 50/60 Hz Input voltage range: 100 – 250 Vw Input current: Rated output voltage: 27,0 Vg Rated output current: Peak output current: 18 A... - Page 16 Dometic (Pty) Ltd. Dometic Branch Office Belgium MEXICO Regional Office Zincstraat 3 Dometic Mx, S. de R. L. de C. V. South Africa & Sub-Saharan Africa B-1500 Halle Circuito Médicos No. 6 Local 1 Unit 6-7 on Mastiff Linbro Park ...
