OPERATING MANUAL (AS)
TELESCOPIC BOOMS
MODELS
SJ45T SJ66T
207522AB-A May 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SJ45T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Skyjack SJ45T

Summary of Contents for Skyjack SJ45T

  • Page 1 OPERATING MANUAL (AS) TELESCOPIC BOOMS MODELS SJ45T SJ66T 207522AB-A May 2018...
  • Page 2 This manual is based on Serial Number(s): SJ 45T 98 001 767 & Above SJ 66T 97 001 833 & Above Please refer to the website (www.skyjack.com) for older Serial Numbers. Skyjack Service Center Parts & Service (Europe) Unit 1 Maes Y Clawdd 3451 Swenson Ave.
  • Page 3 The Safety Alert Symbol identifies important safety messages on MEWP , safety signs in This Safety Alert Symbol means attention! manuals or elsewhere. When you see this symbol, be alert to the possibility of personal Become alert! Your safety is involved. injury or death.

  • Page 4: Table Of Contents

    Table of Contents Section 1 - About Your MEWP ........................ 5 Read and Heed ..............................5 Safety Rules ................................6 Section 2 - Familiarization ........................11 Familiarization of Telescopic Boom Series ....................11 Component Identification ..........................12 Visual & Daily Maintenance Inspections ....................19 Function Tests ............................27 Winching and Towing Procedure ......................37 Emergency Lowering Procedures ......................39 Section 3 - Operation ...........................

  • Page 5: Read And Heed

    SKYJACK warrants each new SJT series work platform to be free of defective parts and workmanship for the first 24 months. Any defective part will be replaced or repaired by your local SKYJACK dealer at no charge for parts or labor.

  • Page 6: Safety Rules

    Common sense dictates the use of protective clothing when working on or near machinery. Use appropriate safety devices to protect your eyes, ears, hands, feet and body. Any modifications from the original design are strictly forbidden without written permission from SKYJACK. Electrocution Hazard This MEWP is not electrically insulated.
  • Page 7 Section 1 - About Your Aerial Platform Safety Rules Safety Precautions Know and understand the safety precautions before going on to next section. WARNING DO NOT • increase the lateral Failure to heed the following safety surface area of the platform. precautions could result in tip over, Increasing the area exposed to falling, crushing, or other hazards leading...
  • Page 8 Safety Rules Section 1 - About Your Aerial Platform Safety Precautions (Continued) Know and understand the safety precautions before going on to next section. • DO NOT operate an MEWP • BE AWARE of blind spots that has ladders, scaffolding or when operating the MEWP .
  • Page 9 MEWP . DO NOT • place materials on the guardrails or materials that exceed the confines of the guardrails unless approved by Skyjack. • DO NOT operate if MEWP is • distribute...
  • Page 10 Safety Rules Section 1 - About Your Aerial Platform Safety Precautions (Continued) Know and understand the safety precautions before going on to next section. WARNING Entering and exiting the MEWP should only be done using the three points of contact. •...

  • Page 11: Section 2 - Familiarization

    Section 2 - Familiarization SJ TB Series 2.1 Familiarization of Telescopic Boom Series WARNING MEWP Familiarization should be given only to individuals who are COMPETENT And TRAINED to operate an MEWP . Do not operate this MEWP without proper authorization and training. Failure to avoid this hazard could result in death or serious injury.

  • Page 12: Component Identification

    This valve is located on the inboard side of the drive pump and can be identified with a yellow paint mark on it. Figure 2-3a. Brake System - SJ45T Figure 2-1. Drive Bypass Valve Drive Bypass Valve with Override Stems...
  • Page 13 Section 2 - Familiarization Control Functions 2.2-5 Differential Lock Switch This switch is located on the platform control console. The differential locking system provides more traction by providing equal drive to each wheel regardless of traction. Differential locks are used to prevent from getting stuck when driving on loose, muddy, or rocky terrain.
  • Page 14 Control Functions Section 2 - Familiarization 2.2-7 Platform Load Sensing System The platform load sensing system is a device that senses for an overload on the platform before the system disables boom and drive functions. This system is active when MEWP is powered on. When the platform is overloaded while in work mode (boom is raised greater than 15 degrees from horizontal or is extended greater than 6 inches), the load sensing system will disable all normal functions and signal the operator with an indicator light and an audible alarm.
  • Page 15 Section 2 - Familiarization Control Functions 2.2-8 Base Control Console This control console is located in the panel mounted in the control compartment. Figure 2-5. Base Control Console Hourmeter - This gauge records accumulated Turret Rotation Switch - This switch controls operating time of engine.
  • Page 16 Control Functions Section 2 - Familiarization 2.2-8 Base Control Console (Continued) Figure 2-5. Base Control Console Platform Leveling Override Switch - This switch Status Indicator Pilot Lights - These lights overrides automatic leveling of platform and indicate operational status and errors in any function in the controls/engine.
  • Page 17 Section 2 - Familiarization Control Functions 2.2-9 Platform Control Console This control console is mounted at front guardrail of the platform. It has the following controls: Figure 2-6. Platform Control Console Engine Start/On/Off Switch - This switch, when B. Chassis Tilt - This light illuminates when the MEWP chassis is at an inclination that held momentarily in “...
  • Page 18 Control Functions Section 2 - Familiarization 2.2-9 Platform Control Console (Continued) Figure 2-6. Platform Control Console Low/High Throttle Switch - This switch allows Fly Boom Extend/Retract Switch - This switch selection between “ ” low and “ ” high controls “ ”...

  • Page 19: Visual & Daily Maintenance Inspections

    Section 2 - Familiarization Visual & Maintenance Inspection Platform Control Console Platform Railing Manuals Platform Assembly Footswitch 2.3 Visual & Daily Maintenance 2.3-2 Electrical Maintaining the electrical components is essential to Inspections good performance and service life of the MEWP . Begin the visual and daily maintenance inspections by checking each item in sequence for the conditions Inspect the following areas for chafed, corroded...
  • Page 20 Visual & Maintenance Inspection Section 2 - Familiarization Typical SJ 45T shown (for model 66T, see note below) Muffler Air Filter High Pressure Hydraulic Filter Pumps Swing Drive Motor Battery Engine Main Power Disconnect Switch 2.3-5 Engine Compartment 1. Check battery cases for damage. Ensure all compartment latches are secure and in proper working order.
  • Page 21 Section 2 - Familiarization Visual & Maintenance Inspection Typical SJ 45T shown (for model 66T, see note below) Muffler Air Filter High Pressure Hydraulic Filter Pumps Swing Drive Motor Battery Engine Main Power Disconnect Switch • Turret Rotation Gear • Engine Oil Level Ensure there are no loose or missing Maintaining the engine components...
  • Page 22 Visual & Maintenance Inspection Section 2 - Familiarization Typical SJ 45T shown Hydraulic Return Hydraulic Tank Brake Manifold Main Manifold Base Control Emergency Power Fuel Tank Console Unit 2.3-6 Control Compartment • Brake and Main Manifolds Ensure all compartment latches are Ensure all fittings and hoses are properly secure and in proper working order.
  • Page 23 Section 2 - Familiarization Visual & Maintenance Inspection Overhead View Tie Rod Oscillating Turret Rotation Limit Switch Cylinder Gear Assembly Drive Axle Wheel/Tire Assembly Rotary Manifold Steer Cylinder Assembly • Fuel Leaks • Oscillating Cylinder Assembly Ensure that there no fuel leaks. Ensure oscillating cylinder assembly is properly secured, there are no loose or missing parts, all fittings and hoses...
  • Page 24 Ensure gate (if equipped) is in good working can adversely affect stability. Therefore, order and automatically closes and latches. replace tires only with the exact Skyjack- Ensure footswitch is in good working order approved type. Failure to operate and has not been modified, disabled or with matched approved tires in good blocked.
  • Page 25 Section 2 - Familiarization Visual & Maintenance Inspection SJ 45T Wear Pad Boom Wear Pad Rotary Actuator Power Track Lift Cylinder 2.3-11 Rotary Actuator 2.3-14 Boom Ensure there are no loose or missing parts Ensure there are no loose or missing parts and there is no visible damage.
  • Page 26 Visual & Maintenance Inspection Section 2 - Familiarization Battery Warmer/ Flashing Amber Light Hydraulic Generator Hydraulic Oil Heater Work Light Welder • Cables (66T) • Battery Warmer/Hydraulic Oil Heater Ensure there are no loose or missing (If Equipped) parts with no signs of visible damage. Ensure battery warmer/hydraulic oil heater cord is properly secured with no Ensure that nuts are not loose and are...

  • Page 27: Function Tests

    Section 2 - Familiarization Function Tests Base Control Console Start/Emergency Power Switch Emergency Stop Base/Off/Platform Key Switch 2.4 Function Tests In engine compartment, turn main power Function tests are designed to discover any malfunctions disconnect switch to “ ” on position. before MEWP is put into service.
  • Page 28 Function Tests Section 2 - Familiarization Base Control Console Start/Emergency Power Switch Emergency Stop Base/Off/Platform Key Switch • Test Function Enable Switch and All • Test Platform Self-leveling Boom Functions 1. Lower boom to stowed position. WARNING 2. Adjust platform to a level position using Ensure that there are no personnel or platform leveling switch.
  • Page 29 Section 2 - Familiarization Function Tests Base Control Console Start/Emergency Power Switch Emergency Stop Base/Off/Platform Key Switch • Test Emergency Power 4. On base control console, turn base/off/ platform key switch to “ ” platform 1. On base control console, push in “ ”...
  • Page 30 Function Tests Section 2 - Familiarization Emergency Stop Drive/Steer Platform Control Controller Console Tie-off Point Tie-off Point Footswitch • Test Base/Off/Platform Switch 7. Select “ ” start position from engine start/on/off switch until engine starts. 1. Ensure both “ ” emergency stop button is pulled out.
  • Page 31 Section 2 - Familiarization Function Tests Emergency Power Emergency Stop Switch Horn Drive/Steer Controller Engine Start/On/ Off Switch Platform Leveling Override Switch 2.4-3 Platform Control Console • Test Load Sensing System WARNING 1. Push in “ ” emergency stop button. Ensure that you maintain three points of 2.
  • Page 32 Function Tests Section 2 - Familiarization Emergency Stop Drive/Steer Platform Control Controller Console Tie-off Point Tie-off Point Footswitch • Test Footswitch NOTE 15-second anti-tiedown feature deactivates footswitch when operator 1. Pull out “ ” emergency stop button. depresses it for 15 seconds without activating any function.
  • Page 33 Section 2 - Familiarization Function Tests Emergency Power Emergency Stop Switch Horn Drive/Steer Controller Engine Start/On/ Off Switch Platform Leveling Override Switch • Test Steering 4. Slowly move drive/steer controller in 1. Pull out “ ” emergency stop button. “ ”...
  • Page 34 Function Tests Section 2 - Familiarization Emergency Power Emergency Stop Switch Horn Drive/Steer Controller Engine Start/On/ Off Switch Platform Leveling Override Switch • Test Emergency Power 4. Depress and hold footswitch. CAUTION 5. Turn “ ” emergency power switch to “...
  • Page 35 Section 2 - Familiarization Function Tests Emergency Power Emergency Stop Switch Horn Drive/Steer Controller Engine Start/On/ Off Switch Platform Leveling Override Switch • Test Brakes 2. On platform leveling override switch, lift and move switch to “ ” upward WARNING position to tilt platform up or “...
  • Page 36 Function Tests Section 2 - Familiarization Oscillating Axle - Unlocked Oscillating Axle - Locked • Test Oscillating Axles • Test Cables (66T) NOTE WARNING Cables have to be tested daily. DO NOT operate any control on platform control console without proper 1.

  • Page 37: Winching And Towing Procedure

    Section 2 - Familiarization Procedures 2.5 Winching and Towing Procedure Position MEWP on a firm and level surface. This section provides the operator with the Winching and Towing procedure, which includes instructions on Chock or block wheels to prevent MEWP from how to manually release the brakes.
  • Page 38 ” off position. CAUTION Do not use hydraulic power with brake Figure 2-9a. Brake Manifold - SJ45T disengaged. Locate the bypass valve on the inboard side of the drive pump. Bypass the drive pump by loosening the valve stem (item 1 - marked with yellow paint) two revolutions counterclockwise.

  • Page 39: Emergency Lowering Procedures

    Section 2 - Familiarization Procedures 2.6 Emergency Lowering Procedures At Platform Control Console: This section guides the operator on how to use Ensure engine is off. emergency lowering system. This system allows platform lowering in the event of an emergency or engine malfunction.
  • Page 40 Notes Telescopic Booms Page 40 December 2007...

  • Page 41: Section 3 - Operation

    Section 3 - Operation General 3.0 Operation • The operator must be sure that the MEWP has This section provides the necessary information needed been properly maintained and inspected before to operate the MEWP . It is important that the user reads using it.

  • Page 42: Major Components

    Major Components Section 3 - Operation 3.2 Major Components Platform Control Console Fly Boom Platform Mid Boom Power Track Main Boom Lift Cylinder Engine Control Compartment Compartment Base Control Console Base Turret SKYJACK Telescopic Boom Telescopic Booms Page 42 December 2007...

  • Page 43: Major Assemblies

    Section 3 - Operation Major Assemblies 3.3 Major Assemblies 3.4 Serial Number Nameplate The MEWP consists of four major assemblies: the base, The serial number nameplate, located at the rear of the turret, boom assembly and platform. MEWP , lists the following: •...
  • Page 44 Component Identification Operation - Section 3 3.5 Component Identification 3.5-3 All Motion Alarm This alarm produces an audible sound when any boom The following descriptions are for identification, function is activated. On MEWPs with certain options, a explanation and locating purposes only. flashing amber light will accompany this alarm.

  • Page 45: Component Identification (Optional Equipment/Attachments)

    Section 3 - Operation Component Identification 3.6 Component Identification (Optional 3.6-2 Welder (If Equipped) The welder is installed on the platform. Refer to Equipment/Attachments) welder’s operating manual for proper operation and The following descriptions are for identification, maintenance. explanation and locating purposes only. 3.6-1 Cold Weather Start (If Equipped) The battery warmer/hydraulic oil heater cord is located on the engine compartment near the battery.
  • Page 46 Component Identification Operation - Section 3 3.6-3 Work Light (If Equipped) 3.6-4 Flashing Amber Light (If Equipped) The work light assembly is mounted on the railings of The flashing amber light is located on top of the turret the platform. of the MEWP .

  • Page 47: Operator's Responsibility

    Section 3 - Operation Operator’s Responsibility 3.7 Operator’s Responsibility Repairs to the MEWP may only be made by a qualified service technician. After repairs are completed, the It is the responsibility of the operator, prior to each work operator must perform visual and daily maintenance shift, to perform the following: inspections &...

  • Page 48: Start Operation

    Start Operation Section 3 - Operation 3.8 Start Operation 3.8-1 To Activate Base Control Console Carefully read and completely understand the Operating Manual and all warnings and instruction labels WARNING (refer to labels section) on the MEWP . Ensure that you maintain three points of contact to mount/dismount the platform.
  • Page 49 Section 3 - Operation Start Operation 3.8-2 To Rotate Platform Using Base Control 3.8-5 To Raise or Lower Main Boom Using Console Base Control Console Activate and hold function enable switch “ ” by Activate and hold function enable switch “ ”...
  • Page 50 Start Operation Section 3 - Operation 3.8-8 To Operate Using Emergency Power Select “ ” start position from engine start/on/off Switch at Base Control Console switch until engine starts. WARNING This is a momentary-type switch. This switch allows all functions except the drive function to operate in the DO NOT over crank the starter.
  • Page 51 Star Opeieoenct3-r Ope Sr-3renct3-r Op 3.8-10 To Drive Forward or Reverse Using 3.8-13 To Extend or Retract Fly Boom Using Platform Control Console Platform Control Console Depress and hold footswitch. CAUTION When you are in the platform and On fly boom extend/retract switch, select “ ”...
  • Page 52 Start Operation Section 3 - Operation 3.8-18 To Rotate Turret Using Platform P u l l d i f f e r e n t i a l l o c k s w i t c h b a c k w a r d Control Console “...

  • Page 53: Refueling Procedure

    Section 3 - Operation Refueling Procedure 3.9 Refueling Procedure 3.9-1 Regular Fuel (Diesel) This section provides the operator with procedure on how to refuel the engine with regular fuel. Ensure engine and all systems are turned off and emergency stop buttons are depressed. IMPORTANT Before using your MEWP ensure there is Open control compartment and remove fuel cap.

  • Page 54: Loading/Unloading

    Loading/Unloading Section 3 - Operation 3.10 Loading/Unloading Turn main power disconnect switch to “ ” off Know and heed all national, state/provincial and local position. rules which apply to transporting of MEWPs. Chock MEWP wheels (if necessary). Only qualified personnel shall operate the MEWP during loading/unloading.
  • Page 55 Section 3 - Operation Loading/Unloading 3.10-2 Locking the Turret Clear platform of all personnel, tools and materials. Ensure that turret is positioned so that turret transportation lock (item 1 - Figure 3-7) is aligned WARNING into one of four turret locking points. When lifting the MEWP, lifting devices must be attached to designated lift points Pull out turret lock retaining pin...
  • Page 56 tnc3ig-Opgrnc3ig-/ Loading/U/l/ Soecding 3.10-3b Lifting (66T) WARNING Rotate the boom and position the MEWP as shown Use chains with load capacity sufficient Figure 3-9 Figure 3-10. to withstand MEWP weight. Refer to the serial plate of the MEWP for specific Turn main power disconnect switch to “...

  • Page 57: Chassis Tilt

    Section 3 - Operation Chassis Tilt 3.11 Chassis Tilt 3.11-1 Counterweight Uphill If the MEWP becomes tilted with the counterweight uphill This section guides the operator with regard to (refer to Figure 3-12) follow the steps below to return to recovering from an inclined position.
  • Page 58 Diagrams Section 3 - Operation Diagram 3.1 Dimension and Reach Diagram - SJ 45T Feet (meters) (15.24) (13.72) (12.19) (10.67) (10.67) (9.14) (7.62) (6.10) (4.57) (3.05) (1.52) (- 1.52) - 10 (- 3.05) - 10 (- 3.05) (- 1.52) (1.52) (3.05) (4.57) (6.10)
  • Page 59 Section 3 - Operation Diagrams Diagram 3.2 Dimension and Reach Diagram - SJ 66T Feet (meters) (22.86) (21.34) (19.81) (18.29) (16.76) (15.24) (13.72) (12.19) (10.67) (9.14) (7.62) (6.10) (4.57) (3.05) (1.52) (-1.52) (-3.05) (-3.05) (-1.52) (1.52) (3.05) (4.57) (6.10) (7.62) (9.14) (10.67) (12.19)
  • Page 60 Diagrams Section 3 - Operation Diagram 3.3 Axle Oscillation Diagram WARNING Do not raise the platform in work mode if it is not on a firm level surface. Axle oscillation free (travel mode) - drive speed 7.2 km/h (4.5 mph) max. Axle oscillation locked (work mode) - drive speed 0.8 km/h (0.5 mph) max.

  • Page 61: Section 4 - Tables

    Section 4 Tables Table 4.1 Standard and Optional Features MODEL SJ 45T SJ 66T S T A N D A R D E Q U I P M E N T   12 Volt DC emergency power   5-foot jib ...

  • Page 62: Table 4.2A Specifications And Features

    Tables Section 4 Table 4.2a Specifications and Features MODEL SJ 45T SJ 66T Total platform length (outside) 182.9 cm / 244 cm 182.9 cm / 244 cm Total platform depth (outside) 91.4 cm 91.4 cm Working 15.7 m 22.1 m Platform elevated 13.7 m 20.1 m...

  • Page 63: Table 4.2B Specifications And Features

    Max. Oil Temp. +93°C (200°F) Limits Alternates HVLP T46 (Summer) (Note: Cold weather starting temperatures can be improved with Skyjack options. Please consult your nearest Skyjack HVLP T42 (Winter) service center.) Tank Capacity 223.3 L Sound Pressure Level (ISO 3744)

  • Page 64: Table 4.3 Owner's Annual Inspection Record

    Tables Section 4 Table 4.3 Owner’s Annual Inspection Record Model Number: _________________ Serial Number:__________________ 20__ 20__ 20__ 20__ 20__ 20__ 20__ 20__ 20__ 1001AB This decal is located on the control compartment cowling. It must be completed after an annual inspection has been completed.

  • Page 65: Table 4.6 Floor Loading Pressure

    Intermixing tires of different types or using tires of types other than those originally supplied with this equipment can adversely affect stability. Therefore, replace tires only with the exact Skyjack- approved type. Failure to operate with matched approved tires in good condition may result in death or serious injury.

  • Page 66: Table 4.7 Maintenance And Inspection Schedule

    B - Perform Scheduled Maintenance Inspection. Refer to Service & Maintenance manual. * - Maintenance must be performed only by trained and competent personnel who are familiar with mechanical procedures. † - Refer to Skyjack's website @ www.skyjack.com for latest service bulletins prior to performing quarterly or yearly inspection.

  • Page 67: Table 4.8 Operator's Checklist

    Model: Hourmeter Reading: Operator's Name (Printed): Date: Time: Operator's Signature: Each item shall be inspected using the appropriate section of the Skyjack operating manual. As each item is inspected, check the appropriate box. INSPECTION FREQUENCY - PASS DAILY - FAIL...
  • Page 68 Notes Telescopic Booms Page 68 December 2007...

  • Page 69: Section 5 - Labels

    Section 5 Labels Label Legend Safety Red Safety Red indicates DANGER. Safety Orange Safety Orange indicates WARNING. Safety Yellow Safety Yellow indicates CAUTION. Safety Green Safety Green indicates emergency lowering. Safety Blue Safety Blue indicates safety information. Telescopic Booms December 2007 Page 69...
  • Page 70 Danger - Crushing hazard Warning - Do Not Alter Do not alter or disable limit switches or other safety devices. Model Number* Product Identifier *Model number will vary, may not be as shown. Skyjack Logo Skyjack Telescopic Booms Page 70 December 2007...
  • Page 71 Section 5 Labels Engine Side (Continued) 139314AA 139314AA Label Pictorial Description Lift Points Only use these points for lifting. Body Crushing Hazard Danger - Body crushing hazard Lift and Tie Down Points Only use these points for lifting or tying down. Wheel Load* Indicates rated wheel load.
  • Page 72 Labels Section 5 Engine Side (Continued) 139314AA 139314AA Label Pictorial Description Sound Power Level Guaranteed maximum sound power level Wheel Specifications Refer to manual for wheel type, offset, pressure and torque. Tie Down Points Only use these points for tying down. Telescopic Booms Page 72 December 2007...
  • Page 73 Section 5 Labels Engine Compartment Label Pictorial Description Winching/Towing/Pushing Procedure Refer to Operating manual. 1. Block or chock wheels to prevent MEWP from rolling. 2. Turn main power disconnect switch to off position. At engine side: 3. Locate bypass valve (marked with yellow colour) on inboard side of drive pump.
  • Page 74 Labels Section 5 Engine Compartment Label Pictorial Description Main Power Disconnect Main power disconnect lever Telescopic Booms Page 74 December 2007...
  • Page 75 Section 5 Labels Front Side Label Pictorial Description 4x4 (If Equipped) Product identifier - 4 wheel drive Warning - Do Not Alter Do not alter or disable limit switches or other safety devices. Serial Plate* Product identification and specifications *Serial plate will vary, may not be as shown. Telescopic Booms December 2007 Page 75...
  • Page 76 Section 5 Control Side Clearance Requirements 139314AA Label Pictorial Description Lift Points Only use these points for lifting. Skyjack Logo Skyjack Diesel Use diesel fuel only. No Smoking Do not smoke near this location. Telescopic Booms Page 76 December 2007...
  • Page 77 Section 5 Labels Control Side (Continued) Clearance Requirements 139314AA Label Pictorial Description Model Number* Product Identifier *Model number will vary, may not be as shown. Body Crushing Hazard Danger - Body crushing hazard Crushing Hazard Danger - Crushing hazard Lift and Tie Down Points Only use these points for lifting or tying down.
  • Page 78 Labels Section 5 Control Side (Continued) Clearance Requirements 139314AA Label Pictorial Description Wheel Load* Indicates rated wheel load. *Wheel load will vary over different MEWPs. Sound Power Level Guaranteed maximum sound power level Wheel Specifications Refer to manual for wheel type, offset, pressure and torque. Tie Down Points Only use these points for tying down.
  • Page 79 Section 5 Labels Control Side (Continued) Clearance Requirements 139314AA Label Pictorial Description Annual Inspection Ensure that work platform has received annual inspection prior to operation. Emergency Lowering Procedure In case of emergency, follow procedure outlined in label to lower the platform. EWPA Clearance Requirements Clearance requirements for operating non-insulated mobile plant, including elevating work platforms near power lines.
  • Page 80 Labels Section 5 Platform (If Equipped) (If Equipped) 18 17 18 17 Label Pictorial Description No Jewelry Caution - Do not wear jewelry. Horizontal Load Rating Apply no more than the indicated side load. Operate below indicated wind speed only. Operator’s Daily Inspection Refer to the Operating manual.
  • Page 81 t5Lablnsn Sectio Control Compartment Label Pictorial Description Base Control Console Push “ ” breaker back in to reset. Select and hold “ ” to enable error blink code for engine control unit (ECU). Read “ ” operating manual. Push and hold “ ”...
  • Page 82 Replace hydraulic fluid with Shell Tellus T46 or approved alternate (see Table 4.2b). (Note: Cold weather starting temperatures can be improved with Skyjack options. Please consult your nearest Skyjack service center.) Hydraulic Oil Level Indicates minimum/maximum oil level. Telescopic Booms...
  • Page 83 t5Lablnsn Sectio Control Compartment (Continued) Label Pictorial Description Winching/Towing/Pushing Procedure Refer to Operating manual. 1. Block or chock wheels to prevent MEWP from rolling. 2. Turn main power disconnect switch to off position. At engine side: 3. Locate bypass valve (marked with yellow colour) on inboard side of drive pump.
  • Page 84 Labels Section 5 Control Compartment (Continued) Label Pictorial Description Diesel Use diesel fuel only. No Smoking Do not smoke near this location. Connect AC Supply Connect AC supply here. Glow Plug Procedure When “ ” glow plug (diesel) light is on, “ ”...
  • Page 85 Section 5 Labels Rear Side Clearance Requirements Label Pictorial Description Warning - No Step No step warning Fall Protection Anchorage Anchor safety belt/harness tethers here. Rated for one (1) person per anchorage. Horizontal Load Rating Apply no more than indicated side load. Operate below indicated wind speed only.
  • Page 86 Labels Section 5 Rear Side (Continued) Clearance Requirements Label Pictorial Description Manual Box Indicates location of operating manual. Hazard Identification Refer to Section 1: Safety Rules. Read and understand outlined risks associated with this work platform prior to operation. Model Number* Product Identifier *Model number will vary, may not be as shown.
  • Page 87 Section 5 Labels Rear Side (Continued) Clearance Requirements Label Pictorial Description 4x4 (If equipped) Product identifier - 4 wheel drive Skyjack Logo Skyjack Telescopic Booms December 2007 Page 87...
  • Page 88 Labels Section 5 Platform Control Console Label Pictorial Description Glow Plugs/Start Engine Select “ ” to energize glow plugs. Push and hold “ ” to start engine and then return to “ ” on position or select “ ” to turn engine off. Select “...
  • Page 89 Section 5 Labels Platform Control Console (Continued) Label Pictorial Description Boom Speed Adjuster Dial Adjust dial to vary speed of fly boom extension/retraction, jib raising/ lowering and platform rotation movements. Boom/Turret Controller Push and hold controller in this direction to rotate turret to “...
  • Page 90 Labels Section 5 Platform Railing Label Pictorial Description Warning - No Step No step warning Crushing Hazard Danger - Crushing hazard Connect AC Supply Connect AC supply here. Warning - Do Not Alter Do not alter or disable limit switches or other safety devices. Footswitch Enable (On/Off) Depress and hold footswitch to enable platform function.
  • Page 91 Section 5 Labels Optional Equipment/Attachments Label Pictorial Description Welder Weight Indicates rated weight of welder. Telescopic Booms December 2007 Page 91...
  • Page 92 Notes Telescopic Booms Page 92 December 2007...
  • Page 94 www.skyjack.com...
