Troubleshooting
How to test a power supply?
Measuring the voltage
After you turn on the mains electrical power,
check voltage 230 V AC between L & N.
Measuring the current in 2-wire system
The switching current between L & V1 should not
exceed 50 mA.
230V
50mA
WARNING! HIGH VOLTAGE
Measuring the current in 3-wire system
The maximum switching current between L & V1
is 2 A.
2A
9
