- Page 1 100 AC diamond 130 03 2019 Use and maintenance Warning! Please read the instructions before use.
-
Page 3: Table Of Contents
INTRODUCTORY COMMENT Thank you for choosing our machine. This floor cleaning machine is made for the industrial and civil cleaning and is able to clean any type of floor. During its forward movement, the combined action of the brushes and the detergent solution removes the dirt which is the aspirated through the rear suction assembly, giving a perfectly dry surface. -
Page 4: Legend Panel Of Controls
LEGEND PANEL OF CONTROLS DISPLAY VISUALIZATION 14. SELECTOR UP/DOWN BRUSHES PUSH BUTTON VISUALIZATION HOUR METER (DISPLAY) 15. SELECTOR UP/DOWN SQUEEGEE PUSH BUTTON VISUALIZATION BRUSHES PRESSURE SET (DISPLAY) 16. SWITCH SUCTION MOTORS ADJUSTMENT KNOB BRUSHES PRESSURE 17. SIGNAL LAMP PARKING BRAKE ON KEY SWITCH 18. -
Page 5: Machine Symbology
MACHINE SYMBOLOGY Symbol denoting the switch Symbol denoting the selection for the water opening and the Automatic brushes unlocking forward/backward signal lamp that the water is symbol (130 model) movement. open. Symbol denoting the push Symbol denoting the signal button and the signal lamps lamp of the brushes rotation. -
Page 6: Optional Equipments
OPTIONAL EQUIPMENTS 3S “Solution Saving System” Adjustable lights GENERAL RULES OF SAFETY − Do not wash the machine with direct water jets or with high water The rules below have to be followed carefully in order to avoid injury to pressure nor with corrosive material. -
Page 7: Technical Description
diamond TECHNICAL DESCRIPTION diamond 130 100AC 1000 1300 Cleaning width 1175 1550 Squeegee width 7000 9100 Working capacity, up to sqft/h 75347 97951 2x510 4 x 355 Brushes diameter 2x20 4 x 14 Brushes rpm Pressure on the brushes lbs. 2000 1920 Brushes motor... -
Page 8: Before Use
BEFORE USE HANDLING OF THE PACKED MACHINE The machine is supplied with suitable packing foreseen for fork lift The machine and its battery check card foresee the use of traditional truck handling. lead batteries. For the package dimensions please look at the “TECHNICAL CHECK THE SETTING OF THE CHECK CARD (see under paragraph DESCRIPTION”... -
Page 9: Connecting The Batt. Connectors And Switching On Of The Machine
The batteries charge level indicator is digital and remains fixed on the display. The battery charge level starts from 100, which indicates the 100% of the total charge and decreases from 10 to 10. When the charge level reaches 20%, the display starts blinking, so you are about the end of working. -
Page 10: Adjusting The Squeegee
(Version 130) ADJUSTING THE SQUEEGEE In order to have a perfect drying result through the squeegee, the rear rubber must have the lower bending uniformly adjusted in all its length. For the adjustment, it is necessary to put oneself in working condition and therefore the suction motor has to be switched on and the brushes have to function together with the detergent solution. -
Page 11: Detergent Solution Tank
Check that the inspection cap (3) placed on the upper part of the tank is well closed. Finally, verify the correct tightening of the closing lever (5) of the cleaning door (6) placed in the lower part of the tank. DETERGENT SOLUTION TANK The capacity of the detergent solution tank is indicated in the technical data. -
Page 12: Starting Of The Machine
STARTING OF THE MACHINE A safety device avoids the machine’s movement if the operator is not seated correctly on the guiding place. To switch on the machine: 1. Sit on the guiding place. 2. Turn the key switch (5) clockwise to switch on the machine. 3. -
Page 13: Automatic Squeegee Lifting When Going Backwards
WORKING IN MANUAL MODE The manual mode is useful when, in special cases, it is necessary to carry out separately only the washing with the brushes or only the drying of the floor. Activate the machine (see under paragraph “STARTING OF THE MACHINE”) positioning the selector (12) to the right to choose the manual mode (MAN). -
Page 14: Working Adjustments
OVERFLOW DEVICE In order to avoid serious damages to the suction motors, the machine is equipped with a float that intervenes when the recovery tank is full, closing the suction, the switching on of the signal lamp (20) for the signaling of the full recovery tank and consequently to the drying stop. -
Page 15: Daily Maintenance
DAILY MAINTENANCE SUCTION FILTER CLEANING RECOVERY TANK EMPTYING AND CLEANING Rotate the seat platform forward up to the blocking of the support. Hold the exhaust hose (1) placed in the rear part of the machine Take off the upper hose (1). after having taken it off from its fixing support. -
Page 16: Squeegee Cleaning
SQUEEGEE CLEANING Keeping the squeegee clean guarantees always the best drying result. For its cleaning it is necessary to: Take off the squeegee hose (4) from the coupling. Disassemble the squeegee (3) from its support (1) loosening the stud bolts (2) and making them slide inside the slots up to release them. -
Page 17: Troubleshooting Guide
TROUBLESHOOTING GUIDE NOTE: The machine is equipped with a control system of the main functions with indication on the display of a probable malfunction with codified alarms: AL01, AL02 up to AL19. Instead, a problem on the drive functioning foresees a check of the quantity of blinkings to be read on the led placed on the chopper card. -
Page 18: The Machine Does Not Clean Properly
THE SQUEEGEE DOES NOT DRY PERFECTLY Check that the suction function is on and that the recovery tank is not full. Check that the squeegee rubbers are clean (see under paragraph “SQUEEGEE CLEANING”). Check the adjustment of the height and the inclination of the squeegee (see under paragraph “ADJUSTMENT OF THE SQUEEGEE”).
